Description
Product Overview
The Bently Nevada 190027 (1900/27) is a compact single‑channel standalone vibration monitor for rotating‑machinery condition monitoring and basic machinery protection. It receives signal from compatible accelerometer transducers, converts raw acceleration signal into vibration velocity value. It supports local on‑site reading via LCD screen, transmits vibration data to DCS/PLC through 4‑20 mA analog loop, and triggers alert / danger relay outputs when vibration exceeds user‑configured set‑points. Equipped with Modbus RTU RS‑485 interface, it supports centralized remote monitoring. Widely deployed for fans, pumps, compressors and other general‑purpose rotating equipment, used as spare‑part replacement for legacy Bently Nevada monitoring systems.
Series
1900 Series Machinery Condition Monitor from Bently Nevada. This series provides cost‑effective local machinery protection solutions for non‑critical and general‑purpose rotating equipment. The 1900/27 works with accelerometer sensors, can operate standalone or cooperate with Trendmaster 2000 system via optional TIM interface module.
Product Features
- Single‑channel seismic vibration measurement, processes accelerometer input and outputs vibration velocity value
- Built‑in local LCD display, supports English / Metric unit switching for on‑site readingManualsLib
- 4‑20 mA analog output for trending vibration data to plant control system
- Two independent alarm relays: Alert and Danger for machinery protection interlock
- Modbus RTU over RS‑485 communication for remote data acquisition and configuration
- Wide‑range power supply: supports both AC 85‑264 VAC and DC 18‑36 VDC power input
- Front‑panel LED status indicators, supports manual self‑test function for quick troubleshootingManualsLib
- Compact standalone housing, suitable for cabinet‑mount or local field installation for general‑purpose rotating machines
Product Parameters
| Item | Parameter |
|---|---|
| Sensor Input | Single‑channel accelerometer input (Trendmaster 2000 compatible) |
| Analog Output | 4‑20 mA current loop output proportional to vibration value |
| Relay Output | Alert relay, Danger relay (SPST contact) |
| Communication | Modbus RTU, RS‑485 interface |
| Power Supply | 85‑264 VAC (47‑440Hz) / 18‑36 VDC wide‑range power |
| Display | Local LCD display, unit selectable (English / Metric)ManualsLib |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -30°C ~ +90°C |
| Humidity | 5‑95% RH, non‑condensing |
Product Specifications
- Unit Model：190027 (1900/27)
- Brand：BENTLY NEVADA (GE)
- Series：1900 Series Machinery Condition Monitor
- Weight：Approx. 0.4 kg
- Dimensions：132 × 132 × 71 mm
Function
- Collect and condition vibration signal from field accelerometer transducer
- Calculate seismic vibration velocity value for rotating machinery
- Show real‑time vibration readings on local LCD display
- Output 4‑20 mA analog signal to DCS / PLC system for trending
- Trigger Alert and Danger relay outputs when vibration exceeds configured threshold
- Realize remote data reading and parameter configuration via Modbus RTU RS‑485 bus
- Perform built‑in self‑test to verify monitor hardware health statusManualsLib
Purpose
Continuous vibration monitoring and basic machinery protection for general‑purpose rotating equipment; replace failed monitor units on legacy Bently Nevada monitoring installations to prevent unexpected equipment failure and unplanned downtime.
Application Fields
Industrial fans, centrifugal pumps, blowers, small‑size compressors, steam turbine auxiliary equipment, water‑treatment rotating machinery, paper‑mill rotating equipment, legacy Bently Nevada monitoring‑system maintenance & retrofitting.
Image search keyword:
Bently Nevada 1900/27 single‑channel vibration monitor
