  • Model: SAN3-40, SAN3-40M
  • Brand: DAIICHI DENTSU (DDK)
  • Series: AFC3000 Fixed Electric Nutrunner Control Platform
  • Core Function: Executes closed-loop torque and angle fastening algorithms, drives NFT series servo nutrunners and exchanges fastening data with host PLCs
  • Category: Servo Controller / Torque Control Driver Unit
  • Key Specs: 40A rated output, closed-loop transducer feedback, digital I/O + serial communication, multi-program fastening sequence
  • Availability & Condition: New Surplus, In Stock, Ready for immediate dispatch
Get a Quote
Category: SKU: 999 Tags: Brand:
  • Need Help?
  • +86 13313703791
  • +86 13313703791
  • seren@ymgkplc.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

3. Key Technical Specifications

  • Input Power: Three-phase AC200–240 VAC, 50/60 Hz
  • Rated Output Current: 40 A
  • Supported Actuator: NFT series fixed electric nutrunner (NFT-801RM3-S and compatible variants)
  • Control Mode: Torque + angle dual closed-loop control
  • Feedback Interface: Dedicated cable for built-in torque transducer and encoder
  • Digital I/O: Multi-channel programmable input/output for machine interlock
  • Communication: RS232 / RS485 for parameter setup and fastening result upload
  • Program Storage: Multiple fastening recipe sets stored locally
  • Operating Temperature: 0 °C to +45 °C, non-condensing
  • Humidity Tolerance: 5%–85% RH
  • Mounting: DIN rail / cabinet vertical mounting
  • Cooling: Aluminum fin passive heat dissipation
  • Form Factor: Compact aluminum enclosure

4. Product Introduction

When automated bolt assembly stations generate inconsistent fastening results and trigger mass quality inspections, mismatched servo controllers or corrupted torque parameters often create costly production downtime. Operating as the drive and logic core of DDK AFC3000 systems, SAN3-40 and SAN3-40M govern all tightening sequences for fixtured NFT nutrunners.Unlike generic servo drives, these units contain firmware optimized for fastening curve monitoring and joint judgment logic. Honestly, built-in result evaluation removes the need for external PLC calculations to judge OK/NG fastening status.



5. QC, Procurement & Logistics SOP

  1. Inbound Verification: Confirm full SAN3-40 or SAN3-40M marking, inspect power terminals, motor feedback connectors and enclosure heatsink for impact damage. Cross-reference serial identifiers against global procurement portal records.
  2. Live Rig Testing: Complete power-on initialization, actuator communication test, recipe loading validation, and simulated fastening cycle testing to confirm stable torque feedback and status output.
  3. QA & Anti-Static Packaging: Wrap controller inside static shielding bag, add foam padding to protect edge connectors; attach signed bench test report to each shipment.
  4. Global Logistics & Export Compliance: Assign accurate HS classification for industrial servo control equipment. Reinforced carton packaging suitable for air freight or sea freight —though customs clearance in the EU might add 2 days to transit timelines.



6. Technical Pitfalls & Integration Warnings

  1. Firmware Variant Mismatch: SAN3-40 and SAN3-40M use different internal firmware feature sets. A technician loading parameter sets between models will see fastening curve errors or intermittent transducer communication loss.
  2. Feedback Cable Configuration errors: Pin definitions between older and newer nutrunner cables are not interchangeable. Miswired feedback circuits disable torque measurement and force open-loop uncontrolled rotation.
  3. Recipe Migration Risk: Saved fastening programs cannot be copied directly between SAN3-40 and SAN3-40M. All torque thresholds, angle windows and ramp profiles require re-validation after hardware swap.
  4. ESD destruction during unboxing: The feedback port transceiver circuitry is sensitive to static. Hidden damage can cause random fastening NG alarms that only surface under continuous production cycling.

7. Frequently Asked Questions (FAQ)

Q: What global lead times apply if on-hand inventory runs out?A: Standard sourcing lead time runs 5–9 weeks. Expedited sourcing options can shorten delivery to 14–20 working days, subject to upstream stock availability.Q: Can I swap SAN3-40 directly with SAN3-40M without modification?A: Physical dimensions and connector layout match, but internal control logic differs. Direct replacement requires full parameter reconfiguration and trial run verification on production fixtures.Q: Does this controller pair with NFT-801RM3-S electric nutrunner?A: Yes. Both SAN3-40 and SAN3-40M support NFT-801RM3-S; always confirm cable part number matches the actuator variant.Q: Can I disconnect and replace this controller while the machine main power remains energized?A: Hot swap is not supported. Fully isolate three-phase AC input before disconnection to avoid power surge damage to feedback electronics.Q: What shipping options exist for cross-border industrial spare deliveries?A: Air express for urgent production line breakdowns, standard air freight for scheduled maintenance, and sea freight for bulk spare part orders. Complete export documentation accompanies every shipment.Q: What warranty coverage applies to New Surplus units?A: Each unit carries a 12-month limited warranty covering verified bench test failures. Warranty excludes damage caused by wiring shorts, actuator overload, or improper ESD handling.Q: Can fastening result data be automatically transmitted to a supervisory PLC?A: Yes. Digital output signals signal OK/NG status, and serial communication can upload complete torque-angle curve data to upper-level control systems.
