Description
Product Overview
The Allen‑Bradley 1786‑RPFPXLB is a ControlNet single‑mode fiber repeater module for Rockwell automation control networks. It converts electrical ControlNet copper‑cable signals into optical signals for long‑distance transmission over single‑mode fiber cables, and performs reverse optical‑to‑electrical conversion at the receiving end. This device supports ControlNet ring‑redundant topology to improve network anti‑interference capability and system reliability. It requires external 24 VDC power supply and adopts ST‑type fiber connectors. Widely deployed in large‑scale manufacturing, process‑industry sites for legacy ControlNet network reconstruction, expansion and spare‑part replacement.
Series
ControlNet industrial communication series, including repeaters, taps, cables and adapters, providing deterministic real‑time control‑level network for Rockwell‑brand PLC and I/O devices.
Product Features
- Single‑mode fiber repeater for ControlNet network, realizes copper‑to‑fiber signal conversion
- ST‑type fiber optic connector for stable single‑mode fiber connection
- Supports ControlNet ring‑redundant topology, automatic link recovery when single‑fiber link fails
- Greatly extends ControlNet communication transmission distance for cross‑workshop long‑distance networking
- Fiber‑optic transmission effectively isolates ground‑loop interference and electromagnetic noise in heavy‑EMI industrial environments
- External 24 VDC DC power supply, independent power supply design
- LED indicator lights for power, network link and fault status for quick‑on‑site diagnosis
- Compatible with standard ControlNet communication protocol, no extra protocol configuration required
Product Parameters
| Item | Parameter |
|---|---|
| Model | 1786‑RPFPXLB |
| Module Type | ControlNet Single‑mode Fiber Repeater |
| Fiber Type | Single‑mode fiber |
| Fiber Connector | ST connector |
| Network Protocol | ControlNet |
| Topology Support | Point‑to‑point, redundant ring topology |
| Power Supply | 24 VDC external power supply |
| Diagnosis | Power / Link / Fault status LED indicators |
| Operating Temperature | 0 ℃ ~ +60 ℃ |
| Installation | Cabinet wall‑mount or DIN‑rail installation |
Product Specifications
- Physical form: Stand‑alone fiber repeater unit
- Condition: New surplus / Tested used (stock subject to real‑time confirmation)
- Warranty: 365‑day warranty for supplied units
- Shipment: In‑stock goods ship within 3 working days after payment
Function
Converts electrical ControlNet signals into optical signals for long‑distance fiber transmission; converts received optical signals back into ControlNet electrical signals; implements physical‑layer signal regeneration; supports ring‑network redundancy and link fault self‑recovery; provides visual status indication for network operation.
Purpose
Extend ControlNet network transmission distance; resist strong electromagnetic interference on‑site; build redundant ring‑network structure to enhance ControlNet communication reliability for automation control systems.
Application Fields
‑ Large‑scale automobile manufacturing production‑line ControlNet network‑ Petrochemical and chemical plant automation control network‑ Metallurgy heavy‑industry anti‑EMI communication cabinet‑ Cross‑workshop long‑distance ControlNet networking project‑ Legacy Rockwell ControlNet system upgrade & spare‑part replacement‑ Water‑treatment large distributed‑control network
