Description
Product Overview
The Allen‑Bradley 1747‑ASB is a single‑slot remote I/O slave adapter module for SLC 500 and PLC‑‑5 automation systemsRockwell A…. Installed in slot 0 of a 1746 remote chassis, it acts as gateway between RIO scanner hardware and local 1746‑series I/O modules inside the remote chassis and expansion racksRockwell A…. It transfers input signals from field I/O back to the main scanner and writes output data received over the RIO link onto chassis backplane without extra user programming workRockwell A…. Equipped with 3‑digit 7‑segment status display plus COM / FAULT LED indicators for fast on‑site troubleshooting, this module is widely used for legacy Rockwell system maintenance and spare‑part replacement projects.
Series
SLC 500 control platform, including SLC controllers, 1746 I/O racks and multiple communication modules for classic PLC distributed‑I/O automation.
Product Features
- Works as RIO slave adapter for remote 1746 I/O chassis, occupies slot 0 of remote rackRockwell A…
- Supports multiple RIO baud‑rate options: 57.6K, 115.2K, 230.4 K baud; long‑distance field wiring up to 3048 m
- Compatible with mixed 1746 discrete input/output and analog I/O modules; supports up to 30 slots via expansion chassis
- Built‑in three‑digit 7‑segment display plus COM / FAULT LED for real‑time communication and fault diagnosis
- DIP‑switch configuration for logical rack number, addressing mode and operation parametersManualsLib
- Non‑volatile memory for I/O slot keying; output hold‑last‑state function upon communication failure
- Industrial‑grade vibration & EMI resistance for continuous cabinet‑based operation
- No dedicated programming required; maps remote I/O data directly into controller processor image tableRockwell A…
Product Parameters
| Item | Parameter |
|---|---|
| Model | 1747‑ASB |
| Module Type | Remote I/O Adapter Module |
| Slot Requirement | Single slot (must be slot 0 of remote chassis) |
| RIO Baud Rate | 57.6K / 115.2K / 230.4 K baud |
| Max Communication Distance | 3048 m @57.6K baud; 762 m @230.4K baud |
| Backplane Current Draw | 375 mA @5 VDCManualsLib |
| Compatible I/O | 1746 series discrete & analog I/O modules |
| Diagnostic Interface | 7‑segment display, COM / FAULT status LED |
| Operating Temperature | 0 ℃ ~ +60 ℃ManualsLib |
| Mounting | Installed inside 1746‑series PLC chassis |
Product Specifications
- Physical form: Single‑slot plug‑in module for Allen‑Bradley 1746 chassis
- Condition: New surplus / Tested used (stock subject to real‑time confirmation)
- Warranty: 365‑day warranty for supplied units
- Shipment: In‑stock goods ship within 3 working days after payment
Function
Serves as slave node on Remote I/O link. Receives output data from RIO scanner and distributes data to local 1746 output modules via chassis backplane; collects input status from local I/O modules and transmits data back to main scanner; provides visual fault diagnosis for communication link and rack hardware faultsRockwell A….
Purpose
Extend SLC500 / PLC‑‑5 control system I/O capacity to remote field locations; realize distributed signal collection and control output over long‑distance RIO communication cable.
Application Fields
‑ Factory production‑line PLC automation retrofits‑ Material‑handling & conveyor control systems‑ Water‑wastewater process control cabinets‑ Oil & gas field legacy Rockwell automation systems‑ Pulp & paper plant SLC 500 spare‑part replacement‑ General‑purpose industrial legacy‑PLC system maintenance
