Description
Product Overview
The TRICONEX 9100 is an Ethernet TCP port communication module for Tricon triple‑modular‑redundant safety instrumented systems. It establishes high‑speed network connection between Tricon controller and external monitoring systems, HMI workstations and host computers. It transmits real‑time process variables, system diagnostic status, fault alarm information and safety‑loop data. Designed for hot‑swap operation, it supports online replacement without system shutdown. This module is widely used for maintenance and spare‑part replacement of legacy Tricon safety control systems in process industries.
Series
Tricon SIS Series by TRICONEX. This series adopts triple‑modular redundant (TMR) fault‑tolerant architecture for safety‑critical process control. The 9100 communication module is installed in Tricon main rack, cooperates with processor modules and I/O modules to complete safety interlock and network data transmission functions.
Product Features
- 10/100 Mbps auto‑negotiation Ethernet interface, supports TCP/IP and UDP/IP communication protocols
- Hot‑swap supported, allows online module replacement without interrupting SIS system running
- Real‑time upload of system operating data, fault diagnosis and alarm messages to upper monitoring host
- Industrial‑grade anti‑interference design, adapts to harsh cabinet‑site electromagnetic environment
- Rack‑slot installation, perfectly matches Tricon main chassis mechanical structure
- Built‑in hardware self‑diagnosis, reports communication link failure and module internal fault status
- Complies with industrial safety standards for safety‑instrumented‑system network access
Product Parameters
| Item | Parameter |
|---|---|
| Ethernet Rate | 10/100 Mbps auto‑negotiation |
| Supported Protocol | TCP/IP, UDP/IP |
| Power Supply | 24 VDC |
| Installation | Slot‑mount inside Tricon main chassis |
| Hot‑Swap Support | Yes |
| Operating Temperature | 0°C ~ +60°C |
| Storage Temperature | -40°C ~ +70°C |
| Function Diagnosis | Link status detection, internal module fault monitoring |
Product Specifications
- Unit Model：9100
- Brand：TRICONEX (Invensys / Honeywell)
- Series：Tricon SIS Safety Instrumented System
- Weight：Approx.1.8 kg
- Dimensions：260 × 180 × 60 mm
Function
- Provide Ethernet TCP/IP communication channel for Tricon SIS controller
- Real‑time transmit process data, alarm and diagnostic information to upper‑level HMI / monitoring workstation
- Receive configuration commands and parameter downloading from host system
- Detect network link and module internal fault, output fault state of communication channel
- Support hot‑swap maintenance without affecting safety‑system normal operation
Purpose
Realize network data interaction between Tricon safety instrumented system and external monitoring equipment; serve as spare‑part replacement for legacy Tricon system communication channel, guarantee stable network transmission of safety control data.
Application Fields
Oil & gas production, petrochemical refineries, chemical plants, thermal power plants, offshore platforms, fertilizer factories, safety‑interlock‑system data monitoring, legacy Tricon SIS system maintenance & retrofitting.
