Schneider Electric TSXPBY100 | New Surplus Profibus DP Master PCMCIA Module Set Global Shipping

Schneider Electric TSXPBY100 | New Surplus Profibus DP Master PCMCIA Module Set Global Shipping

Original price was: $999.00.Current price is: $888.00.

  • Model: TSXPBY100
  • Brand: Schneider Electric / Modicon
  • Series: Modicon Premium (TSX Premium) PLC Platform
  • Core Function: Complete Profibus DP V0 Master communication kit, inserts into Premium PLC PCMCIA slot, establishes Profibus-DP fieldbus network, exchanges real-time I/O data with DP slaves, supports slave diagnostics.
  • Category: Profibus DP V0 Master Module Kit
  • Key Specs: PCMCIA form factor, RS485 DP interface, max 126 DP slaves, supports Class 1 / Class 2 Master, configured via Unity Pro / EcoStruxure Control Expert
  • Availability & Condition: New Surplus, In Stock, Ready for immediate dispatch
  • Important Note: Obsolete, official discontinued from Jan 23, 2021
Get a Quote
Category: Tags: Brand:
  • Need Help?
  • +86 13313703791
  • +86 13313703791
  • seren@ymgkplc.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

3. Key Technical Specifications

  • Supported PLC: All Modicon Premium TSXP57 CPU series
  • Protocol: Profibus DP V0
  • Function: DP Class 1 Master (cyclic I/O exchange) + Class 2 Master (acyclic diagnostics)
  • Physical Interface: RS485, DB9 via T-junction box
  • Transmission Medium: Shielded twisted pair cable
  • Baud Rate & Distance
    • 12 Mbps: max 100 m (no repeater)
    • 9.6 kbps: max 1200 m (no repeater)
  • Maximum Slaves: 126 nodes
  • Max I/O Capacity: 3872 Inputs / 3872 Outputs
  • Internal Power Consumption: 400 mA @5 VDC
  • Kit Contents
    1. Profibus DP PCMCIA card
    2. 0.6 m integrated connecting cable
    3. Host adapter module
    4. DP T-junction breakout box
  • Operating Temperature: 0 ℃ ~ +60 ℃, non-condensing
  • Storage Temperature: -25 ℃ ~ +70 ℃
  • Humidity: 5%–95% RH non-condensing
  • Protection Class: IP20 (cabinet installation only)
  • Configuration Software: Unity Pro (EcoStruxure Control Expert)

4. Product Introduction

When Premium PLC systems lose communication with remote DP I/O, drives and field instruments, aging Profibus master modules often trigger intermittent communication failures. The TSXPBY100 is a full set Profibus DP master solution designed for Modicon Premium PLC PCMCIA expansion slot.Unlike standard rack plug-in communication cards, this adopts PCMCIA architecture with external T-junction terminal box. It handles cyclic process data exchange and slave fault diagnosis for packaging, metallurgy, water treatment and legacy production lines. As a discontinued legacy part, most users rely on surplus inventory for plant maintenance without full system migration.

5. QC, Procurement & Logistics SOP

  1. Inbound Verification: Confirm full TSXPBY100 marking, verify complete kit (PCMCIA card, cable, host unit, T-box). Inspect connectors for pin damage and housing cracks. Cross-reference serial numbers against procurement records.
  2. Live Rig Testing: Power-on test with Premium CPU, PCMCIA slot recognition, Profibus physical layer continuity, module diagnostic LED verification.
  3. QA & Anti-Static Packaging: Pack all components into anti-static bag with foam protection; attach signed bench test report with shipment.
  4. Global Logistics & Export Compliance: Apply correct HS code for PLC communication spare parts. Reinforced carton suitable for air freight & sea freight —EU customs clearance may require additional 2 working days.



6. Technical Pitfalls & Integration Warnings

  1. Complete Kit Mandatory: TSXPBY100 works only as a full set. Missing T-box, cable or PCMCIA card cannot operate normally. Do not mix separate spare parts from different kits.
  2. Not Hot-Swappable: PCMCIA slot does NOT support hot swap. Power off PLC before plugging/unplugging the module to avoid CPU fault or hardware burnout.
  3. Profibus Termination Rule: Enable termination resistor at the two physical endpoints of DP bus. Improper termination leads to signal reflection, random slave drop-out.
  4. Software Version Matching: Older Unity Pro versions lack device description for TSXPBY100. Update software library before project configuration.
  5. Platform Limitation: Exclusive for Modicon Premium TSX series. Cannot be used in Modicon M340 / M580 / Quantum PLC.
  6. Short Circuit Risk: DP bus short circuit will lock module communication; PLC power cycle is required to reset the module after cable fault cleared.



7. Frequently Asked Questions (FAQ)

Q: What global lead times apply if inventory runs out?A: Standard sourcing lead time runs 6–10 weeks. Expedited sourcing can shorten delivery to 16–24 working days, subject to surplus stock availability.Q: Can TSXPBY100 be used as Profibus DP slave?A: No. It is DP Master only; cannot be configured as slave station.Q: Can I replace TSXPBY100 with other Schneider Profibus modules?A: No direct drop-in replacement for Premium PCMCIA DP master. System upgrade requires CPU migration to M580 + BMXPBY100, which needs program modification.Q: What shipping options exist for cross-border industrial spare deliveries?A: Air express for urgent production line breakdowns, standard air freight for scheduled maintenance, sea freight for bulk spare orders. Complete export documentation available.Q: What warranty coverage applies to New Surplus units?A: Each unit carries a 12-month limited warranty covering verified bench test failures. Warranty excludes connector damage, incomplete kit assembly and damage caused by bus short-circuit.Q: Does TSXPBY100 support Profibus DP V1?A: Only DP V0; no extended DP V1 acyclic functions.
