Honeywell CC-PAIN01 | 16-Channel HLAI Module for Experion PKS C300 System

Description

1. Product Overview

The Honeywell CC-PAIN01 is a high-density Analog Input Module designed for the Experion PKS C300 controller environment. It provides 16 input channels for collecting 4-20mA analog signals from field transmitters, such as pressure, temperature, and level sensors.

As a part of the “Series C” I/O family, the CC-PAIN01 features the iconic slanted design for optimized heat dissipation and efficient cabinet space utilization. While this module does not include HART digital communication, it offers a reliable and cost-effective solution for standard analog signal monitoring where advanced instrument diagnostics are not required. It is fully integrated into the Honeywell Experion PKS architecture, providing fast and accurate data updates to the C300 controller.

Key Applications:

• Process Monitoring: Reliable data collection for standard 4-20mA control loops.
• HVAC & Utility Control: Monitoring environmental and utility parameters in industrial facilities.
• Water & Wastewater Treatment: Interfacing with standard flow and level sensors.
• General Industrial Automation: Cost-effective analog input for non-critical or legacy field devices.

2. Technical Features

3. Procurement Process

1. Technical Match: We verify the CC-PAIN01 hardware revision to ensure it is compatible with your existing IOTA and C300 software release.
2. Formal Quotation: Receive a detailed quote including tiered pricing, current stock availability, and global express shipping options.
3. Order Confirmation: Finalizing quantities and any required documentation (e.g., Certificate of Origin, CoC).
4. Sales Agreement: Issuance of a Proforma Invoice (PI) for secure transaction management.
5. Secure Payment: Payment accepted via T/T (Bank Wire Transfer).
6. Quality Inspection: 100% verification of Honeywell factory seals, serial numbers, and physical connector integrity.
7. Professional Packaging: Anti-static and shock-proof packaging designed for safe international air freight.
8. Global Distribution: Fast worldwide shipping via DHL, FedEx, or UPS to ensure your project stays on schedule.

4. Products Showcase (Photos & Video)

5. Related Models

• Honeywell CC-PAIH02 (16-Channel Analog Input with HART)
• Honeywell CC-PAOH01 (16-Channel Analog Output with HART)
• Honeywell CC-PDIL01 (Digital Input 24V)
• Honeywell CC-TCNT01 (Control Network Module)
• Honeywell 8C-TAIX11 (Standard IOTA for Analog Input)

6. Warranty & After-Sales

• 12-Month Global Warranty: Full 1-year coverage against any manufacturing or functional defects.
• 100% Authenticity Guaranteed: We supply only genuine, factory-new Honeywell parts; no refurbished or used units.
• Technical Support: Access to technical datasheets and guidance on I/O channel configuration in the Experion environment.

7. FAQ

Q: What is the difference between CC-PAIN01 and CC-PAIH01?

The CC-PAIN01 is a standard analog input module, whereas the CC-PAIH01/02 includes HART capability. If your field transmitters are “Smart” and you need to access their internal diagnostics, you should choose the PAIH version.

Q: Can the CC-PAIN01 be hot-swapped?

Yes, the Series C I/O modules are designed to be hot-swapped while the system is powered, provided that the proper procedural steps are followed to avoid accidental process trips.

Q: Does this module require an IOTA to function?

Yes, the CC-PAIN01 must be plugged into an IOTA (Input Output Termination Assembly) to connect to the field wiring and the C300 controller. Common compatible IOTAs include the 8C-TAIX11.
