Description
1. Product Overview
The Reliance Electric 805405-1R is a high-reliability Single-Phase Field Power Module engineered for the AutoMax SF3000 drive series. It serves as a panel-mounted unit designed to provide adjustable-voltage, current-regulated field excitation for DC motors.
Typically integrally mounted within an SD3100 DC Power Module, the 805405-1R works in conjunction with a three-phase armature power module within the same PMI rack to ensure synchronized machinery control. The module’s SCR power bridge is fully managed through the AutoMax Programming Executive software, allowing for precise integration into larger industrial automation environments.
Key Applications:
- DC Motor Excitation: Providing stable field current for high-power DC motors.
- Distributed Power Systems: Functioning as a critical component in SD3100 and SF3000 series power architectures.
- Legacy System Maintenance: Essential for supporting and repairing obsolete Reliance Electric AutoMax PLC systems.
2. Data Sheet
| Feature | Technical Specification |
| Output Current | 15 Amps |
| Output Voltage | 500 VDC |
| AC Input Voltage | 120 to 460 VAC (50/60 Hz) |
| Bridge Configuration | Non-reversing (S2) Full-Wave Bridge |
| Rectifier Type | Four SCRs (Silicon Controlled Rectifiers) |
| Protection Features | Internal AC fuses, dv/dt protection, Self-firing clamp |
| Isolation | Electrically isolated power cube |
3. Procurement Process
- Technical Match: We verify the 805405-1R version against your SF3000 or SD3100 system requirements.
- Formal Quotation: Receive a comprehensive quote including pricing for New Surplus or Certified Refurbished options.
- Order Confirmation: Finalizing technical documentation and shipping preferences.
- Sales Agreement: Issuance of a Proforma Invoice (PI) for secure procurement.
- Secure Payment: Processing via T/T (Bank Transfer) or Western Union.
- Quality Inspection: Verification of internal SCRs, fuse continuity, and physical cleaning (for refurbished units).
- Packaging: Robust, shock-proof packing suitable for sensitive power electronics.
- Logistics Distribution: Fast worldwide shipping via DHL Express or FedEx.
4. Products Showcase (Photos & Video)
5. Related Models
- Reliance Electric 805405-3R (15A, 460V S2R Regenerative version)
- Reliance Electric 805405-5R (60A, 230V/460V high-capacity version)
- Reliance Electric 805405-R (Power block module with integrated transformers)
- Reliance Electric 45C992 (AutoMax Analog Input Module)
6. Warranty & After-Sales
- 12-Month Global Warranty: Full replacement or repair coverage for 1 year (extensions available).
- Authenticity Guaranteed: We specialize in sourcing hard-to-find, original Reliance Electric components.
- Repair Services: Professional repair capabilities for 805405-1R units with typical 1-2 week lead times.
7. FAQ
Q: Is the 805405-1R still in production?
No, production has been stopped by the original manufacturer. We supply this module as high-quality New Surplus (unused original stock) or Certified Refurbished (fully tested) to keep your legacy systems operational.
Q: Does this module require an external transformer?
Yes, the Field Power Module requires a separately-ordered, separately-mounted field isolation transformer for proper operation within the SD3100 system.
Q: What is the “Self-firing clamp” mentioned in the specs?
The self-firing clamp is a protection feature designed to guard the circuit against inductive voltage “kicks” that occur during current interruption, preventing damage to the SCR bridge.
