Product Overview
The NI PXI-8186 is a high-performance embedded controller designed for the PXI and CompactPCI systems, serving as a critical computational core in industrial automation and test measurement applications. This module integrates a Mobile Intel Pentium 4 processor operating at 2.2 GHz or 2.5 GHz, supported by up to 1 GB of DDR memory, enabling robust data processing, control logic execution, and communication management within modular instrumentation platforms . As part of NI’s PXI ecosystem, the PXI-8186 aligns with the industry-standard architecture defined by the PXI Systems Alliance (PXISA), ensuring interoperability with a wide range of peripheral modules for applications requiring precise timing, synchronization, and high-speed data acquisition . Its compact, single-unit design consolidates standard PC peripherals—including Ethernet, USB 2.0, GPIB (IEEE 488.2), and serial ports—into a streamlined form factor, eliminating the need for external cabling and reducing system integration complexity .
By leveraging the PXI platform’s built-in triggering and synchronization capabilities, the NI PXI-8186 delivers reliable performance in harsh environments, with extended temperature tolerance and ruggedized construction suitable for aerospace, military, and automotive testing scenarios. The controller optimizes slot usage in PXI chassis by housing peripherals onboard, allowing all active slots to be dedicated to measurement modules such as digitizers, switches, or analog I/O cards . This approach enhances system scalability while maintaining low latency and high throughput, making the NI PXI-8186 a versatile solution for real-time control, data logging, and advanced analysis tasks in research and production settings .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PXI-8186 |
| Manufacturer | National Instruments (NI) |
| Product Type | PXI Embedded Controller |
| Processor | Mobile Intel Pentium 4 (2.2 GHz or 2.5 GHz) |
| Memory | Up to 1 GB DDR |
| Storage | Integrated Hard Drive |
| Front-Panel I/O | 10/100 Ethernet, 2x USB 2.0, GPIB (IEEE 488.2), 2x RS-232, Parallel Port (IEEE 1284 ECP/EPP) |
| Triggering | Internal PXI Trigger Bus Routing |
| Watchdog Timer | Supported |
| Power Supply | PXI Backplane-Powered |
| Operating System Compatibility | Windows, Linux (LabVIEW Real-Time options) |
| Dimensions | Standard PXI Module Size |
| Weight | 2.2 kg |
Key Features and Advantages
Processing Power and Integration: The NI PXI-8186 combines a Pentium 4 processor with extensive I/O connectivity, including GPIB and USB 2.0 ports, enabling direct interfacing with instruments and peripherals without consuming additional slots. This integration reduces system cost and complexity while ensuring high-speed data transfer for demanding applications such as signal analysis and multichannel acquisition .
Modular Flexibility: As a slot-zero controller, the PXI-8186 maximizes the utility of PXI chassis by reserving peripheral slots for instrumentation modules. Its compatibility with both PXI and CompactPCI systems allows seamless integration into legacy and modern setups, while software support for LabVIEW, C/C++, and Python streamlines development for custom automation and test sequences .
Ruggedized Design: Engineered for industrial environments, the controller operates reliably under extended temperature ranges and mechanical stress. The inclusion of a watchdog timer and triggered routing enhances system stability, critical for long-duration operations in manufacturing test or machine monitoring applications .
Application Areas
The NI PXI-8186 is deployed in sectors requiring high-precision measurement and control. In industrial automation, it serves as a controller for robotic systems, production line monitoring, and data acquisition (DAQ) tasks. For test and measurement, it supports applications in structural testing, acoustic analysis, and protocol validation within automotive, aerospace, and electronics industries .
Additionally, the module is used in environmental monitoring, geology, and energy sectors for equipment condition tracking and signal processing. Its GPIB interface facilitates connectivity with legacy instruments, while Ethernet and USB ports enable network-based data sharing and remote system management .
Related Products
NI PXIe-8881: Advanced embedded controller with multi-core Xeon processors for higher computational throughput .
NI PXI-1042: Chassis model compatible with the PXI-8186 for building integrated systems .
NI PCI-6221: Multifunction DAQ card for analog and digital I/O, complementing controller capabilities .
NI PXIe-8301: Remote control module for laptop-based PXI system management .
NI SHC68-68-EPM: Cabling accessories for signal interconnection between PXI modules and external devices .
