Product Overview
The ABB PFEA113-20 is a high-performance tension electronics module engineered for precision control in industrial 卷材处理（web handling）applications. As part of ABB’s advanced automation portfolio, this module serves as a critical component for maintaining consistent tension in materials such as paper, film, textiles, and metal strips during manufacturing processes. With its robust design and versatile functionality, the ABB PFEA113-20 ensures optimal performance in demanding environments, from high-speed packaging lines to complex printing presses.

Featuring dual analog inputs (AI) and six configurable analog outputs (AO), the ABB PFEA113-20 supports real-time tension monitoring and closed-loop control. Its integrated PROFIBUS DP interface enables seamless integration with higher-level control systems, while the multi-language digital display and configuration keys simplify parameter adjustment and diagnostic analysis. The module’s ability to handle up to four load cells and its selectable filter options (15–1500 ms) make it suitable for both static and dynamic tension applications.

Designed for reliability, the ABB PFEA113-20 operates within a wide temperature range (+5°C to +55°C) and complies with industrial standards for electromagnetic compatibility (EMC). Its modular architecture allows for easy expansion with additional I/O modules, while the detachable screw terminals and built-in earth point facilitate quick installation and maintenance. By integrating the ABB PFEA113-20, manufacturers can achieve reduced material waste, improved product quality, and enhanced operational efficiency.

Key Features and Advantages
The ABB PFEA113-20 stands out for its precision and adaptability. Its advanced signal processing algorithms ensure accurate tension measurement, with support for multiple units (N, kN, kg, lbs) and programmable scaling functions. The module’s six analog outputs can be configured as voltage or current signals, enabling flexible integration with actuators such as brakes, clutches, and drives.

Reliability is enhanced by the ABB PFEA113-20’s redundant design and diagnostic capabilities. The built-in LED indicators provide real-time status updates, while the PROFIBUS DP interface allows remote monitoring and fault reporting. For harsh environments, an IP65-rated version is available, offering dust and water resistance without compromising performance.

Ease of use is another core strength. The intuitive menu-driven interface and step-by-step commissioning guide reduce setup time, while the removable terminal blocks simplify wiring. The module’s compatibility with ABB’s Compact Control Builder software enables seamless integration with existing automation systems, supporting IEC 61131-3 programming languages for custom logic development.

Applications
The ABB PFEA113-20 excels in industries requiring precise tension control:

Its ability to handle both single-roll and multi-roll configurations makes it ideal for applications ranging from small-scale machinery to large-scale production lines.
