Description
Product Overview
The GE IC697ACC702 is an I/O bus terminator plug designed for signal integrity and stability in industrial automation systems, particularly within GE Fanuc Series 90-70 PLC racks. This critical component terminates analog or digital communication buses, preventing signal reflections and data corruption in distributed I/O networks. Constructed with robust plastic housing and corrosion-resistant metal contacts, it ensures reliable performance in harsh environments (e.g., extreme temperatures, dust, humidity). Its active termination technology absorbs signal noise, maintaining data accuracy across long cable runs. Compatible with GE’s modular control platforms, the IC697ACC702 simplifies integration into existing panels while enhancing system resilience for applications like power plants and manufacturing lines.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC697ACC702 |
| Manufacturer | GE (General Electric) |
| Product Type | I/O Bus Terminator Plug |
| Operating Voltage | DC 30 V |
| Current Rating | 50 mA per Pin |
| Operating Frequency | Up to 10 MHz |
| Insulation Resistance | >100 MΩ |
| Operating Temperature | -40°C to +70°C |
| Protection Rating | IP67 |
| Connector Type | M12 |
| Material | Plastic housing, metal contacts |
| Dimensions | Compact panel-mount design |
| Weight | ~0.1 kg (estimated) |
Key Features and Advantages
Signal Integrity Enhancement: The IC697ACC702 actively terminates communication buses (e.g., Profibus, DeviceNet), eliminating signal reflections that cause data errors. This ensures millisecond-level accuracy in control systems.
Robust Environmental Resilience: With IP67-rated sealing and a -40°C to +70°C operating range, it withstands moisture, chemicals, and vibration in industrial settings like foundries or outdoor installations.
Easy Integration: Tool-less M12 connectors and panel-mount design enable quick installation in control cabinets, reducing downtime during maintenance or system upgrades.
Durability: Corrosion-resistant contacts and high-impact plastic extend service life, minimizing replacement costs in high-EMI environments.
Application Areas
- Power Generation: Stabilizes signal buses in turbine control systems, preventing data loss during grid fluctuations.
- Manufacturing: Ensures reliable communication between PLCs and I/O modules in automotive assembly lines, reducing production errors.
- Water Treatment: Maintains signal accuracy in humid pump stations for pH/pressure monitoring.
- Energy Management: Terminates buses in substation automation networks, enhancing grid safety.
Related Products
- IC697CBL700: Cabling kit for simplified wiring to IC697ACC702.
- IC697ACC701: Redundant terminator plug for critical systems.
- IC697CHS791: Cooling fan module, essential for thermal management in racks using terminators.
- IC697PWR711: Power supply unit compatible with termination systems.
- IC697ALG440: Analog input module requiring precise bus termination.
Installation and Maintenance
Installation Preparation: Verify DC 30V power stability (±5%) and allocate panel space with ≥20mm clearance. Use shielded M12 cables routed away from high-voltage sources to prevent EMI.
Maintenance Recommendations: Clean connectors quarterly with isopropyl alcohol. Inspect for physical damage; replace if insulation resistance drops below 100 MΩ or signal errors increase.
Product Assurance
The GE IC697ACC702 includes a 1-year warranty against material defects. GE provides 24/7 technical support and ≤72-hour replacement for validated failures. Units undergo 500-cycle insertion testing to validate connector durability.
