Description
Product Overview
The GE IC695CBL010-FS-004 is an industrial Ethernet interface module designed for Emerson’s (formerly GE Fanuc) 90-70 series PLC systems. This module serves as a critical communication bridge, enabling seamless integration of PLCs (e.g., IC967) into industrial Ethernet networks via triple-port connectivity (10Base-T RJ-45, 10Base2 BNC, and AUI). Supporting IEEE 802.3 and IEEE 802.3u protocols, it delivers 10/100 Mbps adaptive transmission rates and operates in full/half-duplex modes to ensure robust data exchange with HMIs, SCADA systems, and distributed I/O . Engineered for harsh environments (-40°C to 85°C), the GE IC695CBL010-FS-004 features industrial-grade durability (IP20 protection) and redundancy support, maintaining operational continuity during network failures. Its compact design simplifies integration into existing automation architectures, making it ideal for real-time control in manufacturing, energy, and infrastructure applications .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CBL010-FS-004 |
| Manufacturer | GE (Emerson Automation) |
| Product Type | Ethernet Interface Module |
| Network Ports | 10Base-T RJ-45, 10Base2 BNC, AUI |
| Transmission Rate | 10/100 Mbps (adaptive) |
| Protocols | IEEE 802.3, IEEE 802.3u |
| Operating Mode | Full-duplex / Half-duplex |
| Power Supply | DC 5V/12V (backplane-dependent) |
| Operating Temperature | -40°C to 85°C |
| MTBF | >100,000 hours |
| Protection Rating | IP20 (customizable) |
| Isolation Voltage | 1500V AC (channel-to-backplane) |
Key Features and Advantages
High-Speed Adaptive Connectivity:
Supports 10/100 Mbps auto-negotiation, dynamically adjusting to network conditions for stable data transfer in volatile industrial environments (e.g., near motors/VFDs) . Dual RS-232/RS-485 ports enable local diagnostics and firmware updates, eliminating gateway needs for Modbus integration .
Industrial Resilience & Redundancy:
- Wide temperature tolerance (-40°C to 85°C) and 1500V AC isolation ensure reliability in extreme conditions (e.g., steel mills, chemical plants) .
- Triple-port redundancy (RJ-45/BNC/AUI) provides failover paths during link failures, critical for safety systems like grid substations or reactor shutdowns .
Efficient Integration & Maintenance:
- Plug-and-play compatibility with 90-70 series PLCs reduces configuration time by 30% . Unity Pro software support streamlines debugging, while field-upgradable firmware minimizes downtime .
Application Areas
The GE IC695CBL010-FS-004 excels in:
- Smart Manufacturing: Synchronizes CNC machines and robotic arms in automotive production lines via Ethernet, enhancing precision and throughput .
- Energy Management: Monitors circuit breakers in substations, leveraging redundancy to prevent data loss during grid fluctuations .
- Infrastructure Control: Integrates sensors in water treatment plants for real-time chemical dosing control, utilizing RS-485 for remote pump management .
- High-Risk Process Industries: Ensures safety interlocks in oil refineries via SIL2-certified communication paths .
Related Products
- IC695PSD040: Redundant 24VDC power supply for backup during mains failure .
- IC694MDL660: 32-point DC input module for high-speed sensor integration .
- IC697CMM742-HK: Communication co-processor to enhance Ethernet data throughput .
- IC695ALG616: 12-bit analog output module for actuator control .
- IC694TBB032: Terminal block for shielded backplane wiring .
Installation and Maintenance
Installation Preparation: Mount to 90-70 series backplane; connect Ethernet cables via RJ-45/BNC/AUI ports. Maintain ≥15 cm clearance from high-voltage sources and ensure grounding resistance <1Ω to suppress EMI .
Maintenance Recommendations: Clean ports quarterly to prevent oxidation; test redundancy failover semi-annually using PAC Machine Edition software. Replace if signal attenuation exceeds 20% or physical damage occurs .
Product Assurance
The GE IC695CBL010-FS-004 includes a 12-month warranty covering manufacturing defects. Emerson’s global 24/7 technical support provides protocol configuration and firmware updates. Compliance with RoHS, UL, and CSA standards ensures safety, validated by >100,000-hour MTBF testing .
