Product Overview
The GE IC695CBL010-FS-002 is an industrial Ethernet interface module designed for Emerson’s (formerly GE Fanuc) 90-70 series PLC systems. This module acts as a critical communication bridge, enabling seamless integration of PLCs (e.g., IC967) into industrial Ethernet networks through triple-port connectivity (10Base-T RJ-45, 10Base2 BNC, and AUI). Supporting protocols like IEEE 802.2 (LLC Type 1) and IEEE 802.3 (10 Mbps MAC), it ensures robust data exchange with HMIs, SCADA systems, and distributed I/O. Integrated RS-232 (RJ-11) and RS-485 (15-pin D-sub) ports facilitate local configuration and firmware updates, reducing downtime. Engineered for harsh industrial environments (-25°C to +70°C), the GE IC695CBL010-FS-002 features redundant communication paths to maintain operational continuity during network failures, making it indispensable for high-stakes sectors like energy, manufacturing, and chemical processing.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CBL010-FS-002 |
| Manufacturer | GE (Emerson Automation) |
| Product Type | Ethernet Interface Module |
| Network Ports | 10Base-T RJ-45, 10Base2 BNC, AUI |
| Management Ports | RJ-11 (RS-232), 15-pin D-sub (RS-485) |
| Backplane Current | +5VDC@2A, +12VDC@0.5A |
| Communication Protocols | IEEE 802.2, IEEE 802.3 |
| Data Transfer Rate | 10 Mbps |
| Redundancy Support | Yes (failover capability) |
| Operating Temperature | -25°C to +70°C |
| Isolation Voltage | 1500V AC (channel-to-backplane) |
| Safety Certification | ISO 13849 SIL2 |
Key Features and Advantages
Multi-Protocol Industrial Connectivity:
The triple-network port design (RJ-45/BNC/AUI) enables flexible integration with legacy and modern Ethernet devices, while RS-232/RS-485 ports simplify on-site diagnostics and firmware updates. This eliminates the need for additional gateways, streamlining Modbus device integration and reducing system complexity.
Robust Redundancy & Reliability:
- Dual-path communication ensures uninterrupted data flow during network disruptions—critical for safety systems in power plants or chemical facilities.
- Industrial-grade EMI shielding and 1500V AC isolation protect against noise from motors/VFDs, while the wide operating temperature (-25°C to +70°C) ensures reliability in harsh environments.
Efficient Maintenance & Scalability:
- Plug-and-play compatibility with 90-70 series PLCs reduces configuration time by 30%. Unity Pro software support accelerates debugging, and field-upgradable firmware minimizes downtime.
- Backward compatibility with GE Series 90-30 modules simplifies system retrofits, lowering integration costs.
Application Areas
The GE IC695CBL010-FS-002 is deployed in:
- Manufacturing Automation: Synchronizes CNC machines and robotic assembly lines via Ethernet, enhancing precision in automotive production.
- Energy Infrastructure: Monitors substation circuit breakers, leveraging redundancy to prevent data loss during grid fluctuations.
- High-Risk Process Industries: Manages emergency shutdown systems in chemical plants, utilizing SIL2 certification for safety interlocks.
- Logistics & Material Handling: Integrates photoelectric sensors in automated warehouses, ensuring real-time response for sorting equipment.
Related Products
- IC695PSD040: Redundant 24VDC power supply for backup during mains failure.
- IC694MDL660: 32-point DC input module for high-speed sensor integration.
- IC695ALG616: 12-bit analog output module for actuator control.
- IC697CMM742-HK: Communication co-processor to enhance Ethernet data throughput.
- IC694TBB032: Terminal block for secure backplane wiring.
Installation and Maintenance
Installation Preparation: Mount the GE IC695CBL010-FS-002 to a 90-70 series backplane. Connect Ethernet cables via RJ-45/BNC/AUI ports, ensuring ≥15 cm clearance from high-voltage cables to minimize EMI. Verify grounding integrity (resistance <1Ω).
Maintenance Recommendations: Clean RS-232/RS-485 connectors quarterly to prevent oxidation. Test redundancy failover every six months using PAC Machine Edition software. Replace the module if signal attenuation exceeds 20% or physical port damage occurs.
Product Assurance
The GE IC695CBL010-FS-002 includes a 12-month warranty covering manufacturing defects. Emerson’s global 24/7 technical support provides protocol configuration guidance and firmware updates. Compliance with RoHS, UL, and CSA standards ensures safety, validated by 100,000-hour MTBF testing.
