Description
Product Overview
The GE IC695CBL010-FD-003 is a high-performance 1 GHz Intel Celeron-M CPU module designed for Emerson’s PACSystems RX3i platform (formerly GE Fanuc). As a central processing unit, it targets real-time control of industrial systems such as machinery, material handling, and process automation. Equipped with 20 MB RAM and 20 MB flash memory, the module executes up to 32K I/O operations per second, supporting complex algorithms like PID control and motion planning. It features dual serial ports (RS-232 and RS-485) for seamless integration with distributed I/O, HMIs, and SCADA via protocols like Modbus RTU and SNP. Operating in harsh industrial environments (-20°C to +60°C), the GE IC695CBL010-FD-003 ensures robust performance in high-noise settings near motors or VFDs. Its IEC 61131-3-compliant programming (ladder logic, structured text) simplifies development, while field-upgradable firmware minimizes downtime. This module is ideal for applications demanding high-speed local control without Ethernet dependency, solidifying its role as a core component in scalable automation architectures.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CBL010-FD-003 |
| Manufacturer | GE (Emerson Automation) |
| Product Type | CPU Module |
| Processor | 1 GHz Intel Celeron-M |
| Memory | 20 MB RAM + 20 MB Flash |
| I/O Throughput | 32K operations/second |
| Program Capacity | 512 blocks (128 KB each) |
| Serial Ports | RS-232 (9-pin), RS-485 (15-pin) |
| Supported Protocols | Modbus RTU Master/Slave, SNP, Serial I/O |
| Power Requirements | +5VDC@1.2A, +3.3VDC@1A |
| Operating Temperature | -20°C to +60°C |
| Isolation | 1500 VDC (port-to-backplane) |
| Compliance | EU RoHS Directive 2002/95/EC |
Key Features and Advantages
High-Speed Control & Flexibility:
The 1 GHz processor and 32K I/O operations/sec enable real-time responses in high-speed applications like CNC synchronization or robotic assembly lines. Support for IEC 61131-3 programming languages (ladder logic, structured text) allows efficient development of complex logic, while symbolic variable allocation optimizes memory usage for large-scale projects.
Industrial Resilience & Compatibility:
Designed for harsh environments, the module withstands EMI from motors/VFDs via 1500 VDC isolation and operates reliably in -20°C to +60°C temperatures. Backward compatibility with GE Series 90-30 modules simplifies system retrofitting, reducing integration costs.
Streamlined Diagnostics & Updates:
Dual serial ports enable on-site firmware upgrades without system shutdowns. Integrated protocols like Modbus RTU directly interface with drives and sensors, eliminating additional gateways and streamlining data flow in energy grids or water treatment plants.
Application Areas
The GE IC695CBL010-FD-003 excels in:
- Manufacturing Automation: Coordinates welding robots and conveyor belts in automotive production, using RS-485 for multi-device command distribution.
- Energy Infrastructure: Monitors transformer parameters in substations, leveraging Modbus for real-time SCADA data transmission.
- Process Industries: Manages reactor valve sequences in chemical plants, utilizing wide-temperature tolerance for reliability near high-heat equipment.
- Water Treatment: Controls dosing pumps via analog I/O modules (e.g., IC695ALG616), ensuring precise chemical dosing during power fluctuations.
Related Products
- IC695PSD040: Redundant 24VDC power supply for CPU backup.
- IC694MDL660: 32-point DC input module for high-speed sensor integration.
- IC695ALG616: 12-bit analog output module for actuator control.
- IC695CRU320: Redundant CPU for high-availability systems.
- IC694TBB032: Terminal block for shielded backplane wiring.
Installation and Maintenance
Installation Preparation: Mount to RX3i backplane using IC694TBB032 terminal blocks. Ensure power input (19.2–30VDC) and maintain ≥15 cm clearance from high-voltage cables to prevent EMI interference. Verify grounding integrity before startup.
Maintenance Recommendations: Clean RS-232/RS-485 connectors quarterly to prevent oxidation. Monitor CPU load via PAC Machine Edition software; optimize programs if exceeding 80%. Test backup duration annually and replace if flash memory errors occur.
Product Assurance
The GE IC695CBL010-FD-003 includes a 12-month warranty covering manufacturing defects. Emerson’s global 24/7 technical support provides firmware updates and integration troubleshooting. Compliance with RoHS, UL, and CSA standards ensures safety, validated by 100,000-hour MTBF testing.
