Description
Product Overview
The GE IC695CBL010-FD-001 is an Ethernet interface module designed for GE Fanuc 90-70 series PLC systems (now under Emerson Automation). It bridges PLCs (e.g., IC967) to industrial Ethernet networks via three versatile ports: 10Base-T RJ-45, 10Base2 BNC, and AUI, supporting protocols like IEEE 802.2 (LLC Type 1) and IEEE 802.3 (10 Mbps MAC). With integrated RS-232 (RJ-11) and RS-485 (15-pin D-sub) ports for local management and firmware updates, this module simplifies network integration in automation systems. Engineered for harsh industrial environments, the GE IC695CBL010-FD-001 offers redundant communication paths to maintain data flow during primary link failures, ensuring reliability in critical sectors like energy, manufacturing, and process industries.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CBL010-FD-001 |
| Manufacturer | GE (Emerson Automation) |
| Product Type | Ethernet Interface Module |
| Network Ports | 10Base-T RJ-45, 10Base2 BNC, AUI |
| Management Ports | RJ-11 (RS-232), 15-pin D-sub (RS-485) |
| Backplane Current | +5VDC@2A, +12VDC@0.5A |
| Communication Protocols | IEEE 802.2, IEEE 802.3 |
| Data Transfer Rate | 10 Mbps |
| Redundancy Support | Yes (failover capability) |
| Operating Environment | Industrial (IP30 equivalent) |
| Dimensions | Standard RX3i module size (est.) |
Key Features and Advantages
Multi-Protocol Industrial Connectivity:
Triple-network port design enables flexible integration with legacy and modern Ethernet devices (e.g., HMIs, SCADA systems), while RS-232/RS-485 ports streamline on-site diagnostics and updates.
Robust Redundancy & Reliability:
- Dual-path communication ensures continuous operation during network disruptions—critical for safety systems in oil refineries or chemical plants.
- Industrial-grade EMI shielding and IP30-equivalent protection withstand dust, moisture, and electrical noise near motors/VFDs.
Simplified Integration:
- Plug-and-play compatibility with GE 90-70 series PLCs reduces configuration time.
- Centralized data exchange with computers/touchscreens enhances real-time control precision in high-speed applications like CNC machining.
Application Areas
The GE IC695CBL010-FD-001 is deployed in:
- Manufacturing Automation: Synchronizes robotic assembly lines and CNC machines via Ethernet, reducing latency in automotive production.
- Energy Infrastructure: Monitors turbine controls and grid substations, leveraging redundancy to prevent data loss during power fluctuations.
- Process Industries: Manages reactor pressure/temperature valves in chemical plants, utilizing EMI resistance in high-noise environments.
- Heavy Machinery: Ensures real-time response in cranes and injection molding machines through reliable network links.
Related Products
- IC695CPU315: RX3i controller for module integration.
- IC694TBB032: Terminal block for shielded I/O cabling.
- IC697CMM742-HK: Communication co-processor for enhanced data handling.
- IC693ALG391: Analog input module for sensor integration.
- IC695ALG808: 8-channel analog output for actuator control.
Installation and Maintenance
Installation Preparation: Mount to 90-70 series backplane; connect Ethernet cables via RJ-45/BNC/AUI ports. Isolate high-voltage sources ≥15 cm to minimize EMI interference.
Maintenance Recommendations: Biannual inspection of connectors for oxidation; verify network redundancy via diagnostic tools (e.g., PAC Machine Edition). Replace if ports show physical damage or signal degradation.
Product Assurance
The GE IC695CBL010-FD-001 includes a 12-month warranty against defects. Global 24/7 technical support covers firmware updates and integration troubleshooting. Compliant with RoHS and industrial safety standards (UL/CSA).
