Honeywell TC-CCR014 | C200 Redundant Network Interface Module

Description

Honeywell documentation identifies TC-CCR014 as a Dual-Media (Redundant) ControlNet Interface. It supersedes the earlier TC-CCR013, TC-CCR012, and TC-CCR011 models and supports redundant controllers and optional Fieldbus communications.

3. Key Technical Specifications

The TC-CCR014 is specifically the redundant version of Honeywell’s ControlNet interface. Honeywell’s hardware planning documentation distinguishes the R configuration from the N configuration: TC-CCR014 is intended for redundant ControlNet cable arrangements, while TC-CCN014 is the non-redundant version.

4. Product Introduction (Anti-Template)

When a Honeywell C200 control system depends on redundant ControlNet communication, the TC-CCR014 provides the network interface required for the dual-media architecture. Honeywell classifies it as a Dual-Media (Redundant) ControlNet Interface, and the Series E version supersedes earlier CCR012/CCR013/CCR011 modules.

The distinction between CCN014 and CCR014 is critical. These are not simply two cosmetic versions of the same board. The CCR014 is intended for redundant ControlNet arrangements, so the existing network topology and controller configuration should be checked before procurement. Honestly, confirming whether the customer’s cabinet is wired for redundant ControlNet can save an expensive replacement mistake.

5. QC, Procurement & Logistics SOP

1. Inbound Verification
   Verify the complete identification as TC-CCR014 / 97197975-A01. Check the Honeywell label, hardware revision, front-panel connectors, chassis interface, and overall PCB condition. The exact revision should be recorded before shipment.
2. Live Rig Testing
   Where a compatible C200 test environment is available, verify module initialization, ControlNet communication, redundant-media status, controller recognition, and diagnostic indications. A power-on test alone does not establish network functionality.
3. QA & Anti-Static Packaging
   The module is handled under ESD precautions and placed in anti-static packaging. The ControlNet connectors and backplane connector receive additional protection against impact. The module should be immobilized inside the carton during transportation.
4. Global Logistics & Export Compliance
   Export documents should identify the item as a Honeywell TC-CCR014 97197975-A01 Redundant ControlNet Interface Module. HS classification should be reviewed against the actual function and destination customs requirements. Air freight is normally preferable for urgent control-system repairs; sea freight can be used for planned consolidated shipments.

6. Technical Pitfalls & Integration Warnings

1. Redundant vs. Non-Redundant Network Mismatch
   The biggest trap is confusing TC-CCR014 with TC-CCN014. Honeywell specifies the CCR014 for redundant ControlNet cable configurations, while CCN014 is the non-redundant configuration. Installing the wrong type can leave the expected network redundancy unavailable.
2. Hardware Revision Compatibility
   Legacy Honeywell control systems can contain different generations of ControlNet interfaces. Before replacing the module, record the existing hardware revision and verify compatibility with the installed controller and system release.
3. ControlNet Cable / Termination Errors
   A healthy interface module cannot compensate for incorrect redundant-media wiring. Check both ControlNet paths, connectors, cable routing, and termination before blaming the replacement module for communication faults.
4. ESD During Unboxing
   The TC-CCR014 contains network-interface electronics that are sensitive to electrostatic discharge. Keep the module in its anti-static packaging until installation and avoid touching connector contacts or exposed circuitry.

7. Frequently Asked Questions (FAQ)

Q1: “What is Honeywell TC-CCR014 used for?”

TC-CCR014 is a redundant ControlNet interface module used in Honeywell Experion C200 controller architectures. It provides dual-media ControlNet communication for redundant configurations.

Q2: Is TC-CCR014 the same as TC-CCN014?

No. TC-CCR014 is the redundant version, while TC-CCN014 is the non-redundant ControlNet interface. Honeywell specifically uses the R designation for redundant ControlNet cable configurations.

Q3: “Does 97197975-A01 belong to TC-CCR014?”

Yes. The supplied ordering number 97197975-A01 is associated with the TC-CCR014 model in available product records. For procurement, it is best to use both identifiers together: TC-CCR014 / 97197975-A01.

Q4: Can I hot-swap the TC-CCR014?

Do not assume that it can be removed while energized. Network-interface replacement can affect controller communication and redundancy status. The chassis should be handled according to the applicable Honeywell maintenance procedure, with the process placed in an appropriate maintenance state first.

Q5: “Our existing module is TC-CCR013. Can I replace it with CCR014?”

Honeywell documentation states that TC-CCR014 supersedes TC-CCR013, TC-CCR012, and TC-CCR011. However, replacement should still be checked against the installed system release, controller architecture, and network configuration before installation.

Q6: What are the approximate dimensions and weight?

Available technical data gives approximately 172 × 140 × 35 mm and 0.45 kg. Allow additional weight for anti-static protection, cushioning, carton, and export packaging.

Q7: “What should I send before ordering?”

Please provide:

• Existing TC-CCR014 nameplate photo
• Full order number
• Hardware revision
• C200 controller model
• Existing ControlNet topology
• Redundant/non-redundant network configuration
• Cable and connector arrangement
• Quantity required
• Destination country
• Required delivery date

For this module, the existing network topology is just as important as the part number. If the customer’s system uses redundant ControlNet, make sure the replacement is the CCR configuration rather than the non-redundant CCN version.
