Description
Product Overview
The GE VME7768-320000 is a high-performance VMEbus single-board computer (SBC) engineered for mission-critical industrial automation and embedded control systems. Belonging to GE’s VME7768 series, this module integrates advanced computing power with ruggedized design, making it ideal for applications requiring real-time processing, reliability, and scalability. With support for Intel Core 2 Duo (2.16 GHz) or Celeron M (1.07 GHz) processors, the GE VME7768-320000 delivers exceptional performance for complex tasks such as data acquisition, machine vision, and motion control.
Featuring 2 GB DDR2 SDRAM and 8 GB bootable CompactFlash storage, the GE VME7768-320000 ensures rapid data handling and persistent storage for industrial applications. Its VME64X-compliant backplane interface enables seamless integration with legacy VMEbus systems, while dual Gigabit Ethernet ports, 4 USB 2.0 ports, and 2 SATA interfaces provide flexible connectivity for peripherals and networks. The module supports Windows XP, VxWorks, and Linux operating systems, allowing developers to leverage familiar software environments for application development.
In automation systems, the GE VME7768-320000 serves as a centralized control hub, processing inputs from sensors and actuators while delivering outputs to drive industrial processes. Its PMC expansion slot supports additional functional cards for specialized applications, such as high-speed data acquisition or advanced communication protocols. With IP40 environmental rating and -40°C to +85°C extended temperature support (select variants), the module excels in harsh industrial environments, including oil refineries, power plants, and manufacturing facilities.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | GE VME7768-320000 |
| Manufacturer | GE Fanuc (GE Intelligent Platforms) |
| Product Type | VMEbus Single-Board Computer |
| Processor | Intel Core 2 Duo (2.16 GHz) or Celeron M (1.07 GHz) |
| Memory | Up to 2 GB DDR2 SDRAM |
| Storage | 8 GB bootable CompactFlash |
| Communication Interfaces | 2x Gigabit Ethernet, 2x RS-232/422/485, 4x USB 2.0, 2x SATA |
| Expansion | 1x PMC (PCI-X) slot |
| Power Supply | +5 VDC (12 A typical), +12 VDC (2 A typical) |
| Operating Temperature | 0°C to +70°C (Celeron M) / 0°C to +55°C (Core 2 Duo) |
| Environmental Rating | IP40 (indoor use), ATEX/IECEx-certified (select variants) |
| Physical Dimensions | 6U (4HP) Eurocard (233.35 mm x 160 mm) |
| Weight | 2.5 kg |
Key Features and Advantages
High-Performance Processing: The GE VME7768-320000 combines Intel Core 2 Duo or Celeron M processors with 4 MB L2 cache (Core 2 Duo) to handle computationally intensive tasks, such as real-time analytics and complex control algorithms.
Ruggedized Design: Built to withstand extreme temperatures, vibration, and shock, the module meets IP40 standards and offers -40°C to +85°C extended temperature variants, ensuring reliability in harsh industrial settings.
Flexible I/O and Connectivity: With dual Gigabit Ethernet, USB, SATA, and serial ports, the module supports diverse peripherals, including industrial cameras, PLCs, and HMIs. The PMC expansion slot allows customization for specialized applications like FPGA acceleration or CANbus communication.
Hot-Swap Capability: The GE VME7768-320000 supports live module replacement without system shutdown, minimizing downtime in continuous-process industries.
Multi-OS Support: Compatible with Windows XP, VxWorks, and Linux, the module enables seamless integration with existing software ecosystems and simplifies migration from legacy systems.
VME64X Compliance: The VMEbus interface ensures backward compatibility with older VME systems while supporting advanced features like 64-bit addressing and block transfer modes.
Application Areas
The GE VME7768-320000 is widely deployed in industries requiring high-performance embedded computing:
- Industrial Automation: Controls assembly lines, robotic systems, and CNC machines by processing real-time sensor data and executing precise motion commands.
- Process Control: Manages chemical reactors, oil refineries, and power plants by integrating with DCS systems to monitor and optimize production processes.
- Transportation: Powers rail and aerospace systems, including train control units and avionics, where reliability and compact design are critical.
- Defense and Aerospace: Supports military applications like radar systems, missile guidance, and unmanned vehicles, leveraging its rugged construction and extended temperature capabilities.
- Machine Vision: Processes high-resolution images for quality inspection in manufacturing, using its powerful CPU and PMC expansion for GPU acceleration.
Related Products
- GE VME7768-320001: Enhanced variant with extended temperature range (-40°C to +85°C) and additional I/O options for extreme environments.
- GE VME7768-322001: High-power version with 3.2 kW capacity for energy-intensive applications like industrial robotics.
- GE VME7768-350000: Includes built-in FPGA for advanced signal processing and custom logic implementation.
- GE VME7768-PMC237: PMC expansion board providing three additional PMC slots for increased functionality.
- GE VME7768-320000-C: Military-grade variant with extended temperature support and enhanced EMI shielding.
- GE VME7768-320000-A2: Upgraded model with faster DDR3 memory and PCI Express interface for modern industrial protocols.
- GE VME7768-320000-B: Compact version with reduced dimensions for space-constrained applications.
- GE VME7768-320000-D: Includes redundant power inputs for mission-critical systems requiring failover capabilities.
- GE VME7768-320000-E: Supports dual-core Intel Atom processors for energy-efficient, low-power applications.
- GE VME7768-320000-F: Features integrated Wi-Fi and cellular connectivity for remote monitoring and IoT integration.
Installation and Maintenance
Installation Preparation:
Ensure the VMEbus backplane is properly grounded and compatible with the GE VME7768-320000’s 6U form factor. Use a VME64X-compliant backplane to leverage advanced features like 64-bit addressing. Verify power supply requirements (+5V and +12V DC) and connect the module using keyed connectors to prevent misalignment. Secure the module in the rack using captive screws to ensure stability in high-vibration environments.
Ensure the VMEbus backplane is properly grounded and compatible with the GE VME7768-320000’s 6U form factor. Use a VME64X-compliant backplane to leverage advanced features like 64-bit addressing. Verify power supply requirements (+5V and +12V DC) and connect the module using keyed connectors to prevent misalignment. Secure the module in the rack using captive screws to ensure stability in high-vibration environments.
Maintenance Recommendations:
- Routine Checks: Inspect front-panel LEDs monthly to verify system status. Use GE’s diagnostic software to monitor CPU temperature, memory usage, and fan performance.
- Firmware Updates: Regularly update firmware to access new features and security patches. GE provides firmware packages compatible with Windows, Linux, and VxWorks.
- Environmental Monitoring: Clean dust from ventilation slots quarterly and ensure ambient temperature remains within specified limits. Replace cooling fans every 24 months as part of preventive maintenance.
- Spare Parts Inventory: Maintain a spare GE VME7768-320000 module and critical components (e.g., CompactFlash cards) to minimize downtime during replacements.
Product Assurance
GE guarantees the GE VME7768-320000 against defects in materials and workmanship for 1 year from delivery. Our global technical support team provides 24/7 assistance for installation, troubleshooting, and firmware updates. With a dedicated inventory of spare parts and a streamlined logistics network, we ensure 3-day delivery after payment to minimize operational disruptions.
For mission-critical applications, GE offers extended warranties and predictive maintenance programs to optimize system performance and lifecycle costs. All products undergo rigorous testing to meet ISO 9001 and IEC 61508 standards, ensuring compliance with the highest industry benchmarks.
