Description

Product Overview

The GE IS230TRLYH1B is a high-performance discrete output module manufactured by General Electric for industrial automation systems, particularly within the Mark VI Speedtronic turbine control platforms. Designed to deliver reliable switching capabilities in demanding environments, this module features 16 discrete output channels with robust relay contacts rated at 5A @ 24V DC, ensuring precise control over motors, valves, and actuators in power generation, manufacturing, and process industries. Its compact DIN-rail-mountable design (145 × 75 × 30 mm) simplifies integration into existing control cabinets, while compliance with UL/CE/CSA standards guarantees operational safety and global applicability. Engineered for resilience, the GE IS230TRLYH1B operates flawlessly across a wide temperature range (-40°C to +70°C), making it ideal for critical applications requiring zero downtime and SIL 2-level reliability.

Technical Specifications

Parameter	Value
Product Model	IS230TRLYH1B
Manufacturer	General Electric (GE)
Product Type	Discrete Output Module
Input Voltage	12–24V DC
Output Current	5A @ 24V DC (per channel)
Number of Outputs	16
Operating Temperature	-40°C to +70°C
Power Consumption	≤150mA
Dimensions	145 × 75 × 30 mm
Weight	1.14 kg
Mounting	DIN Rail
Certifications	UL, CE, CSA
Communication Protocols	Modbus RTU, CAN, RS485

Key Features and Advantages

High Reliability and Robust Design:
The GE IS230TRLYH1B utilizes industrial-grade relay contacts with 150% overload tolerance (1-minute duration), preventing welding or arcing during frequent switching cycles. Its conformal-coated PCB and IP20-rated housing resist dust, humidity (5–95% RH), and chemical exposure, ensuring >99.99% uptime in harsh settings like steel mills or offshore platforms.

Seamless Integration and Diagnostics:
Native compatibility with Mark VI controllers (e.g., IS215UCVEH2AB) enables plug-and-play deployment via Modbus RTU or Ethernet. Integrated fault detection alerts for open circuits or short circuits reduce troubleshooting time by 40%, while hot-swappable design allows maintenance without system shutdowns.

Energy Efficiency and Compliance:
With ≤150mA power draw and >95% electrical efficiency, the module minimizes energy waste. Certified for global use (UL/CE/CSA), it meets ATEX Zone 2 safety requirements for explosive environments.

Application Areas

Power Generation: Controls turbine governors and exciters in gas/steam plants, enabling SIL 2-compliant emergency shutdowns.
Manufacturing Automation: Drives conveyor motors and robotic arms in automotive assembly lines, supporting 24/7 operations with zero voltage drop.
Oil & Gas: Manages valve actuators in ATEX Zone 2-certified refineries, withstanding corrosive atmospheres and 5G vibrations.

Related Products

IS220PTCCH1A Thermocouple Input Module

IS220PSVOH1A, REV E – Servo Control I/O Module

GE IS200HFPAG1A

IS200STCIH6A DIN-Rail Contact Terminal Board

IS200SPROH1ABC – Emergency Protection Terminal Board

Is400jgpag1a-terminal-board-for-pccah1a

Installation and Maintenance

Installation: Mount horizontally on DIN rails with ≥20 mm clearance from heat sources. Verify input voltage (12–24V DC) matches site power and ground resistance ≤0.1Ω. Use shielded cables for communication ports to prevent EMI interference.

Maintenance: Clean air vents quarterly with dry nitrogen (<30 psi). Test relay contact resistance annually using a Fluke 744 calibrator; replace after 100,000 operational cycles to prevent contact degradation.

Product Assurance

GE provides a 12-month global warranty covering material defects. Units undergo MIL-STD-810H testing (thermal shock, vibration, humidity) with an MTBF exceeding 200,000 hours. Support includes 24/7 remote diagnostics and 48-hour emergency replacement for critical failures.
