Description
Product Overview
The GE IS220PTURH1A is a primary turbine trip pack designed for GE Energy’s Mark VIe turbine control system series1. It serves as a vital component in turbine control systems, providing critical protection and emergency shutdown functions4. This module interfaces directly with turbine control terminal boards, ensuring safe operation by detecting fault conditions and initiating trips to prevent damage4. It offers an electrical interface between a turbine control terminal board and one or two Ethernet networks, and its outputs are transmitted through a DC – 62 pin connector that links to an associated terminal board1.
Technical Specifications
Parameter Name | Parameter Value |
---|---|
Product Model | IS220PTURH1A |
Manufacturer | GE |
Product Type | Primary turbine trip pack |
Series | Mark VIe |
Power Supply Voltage | 27.4 – 28.6 V DC |
TRPA Voltage Detection Inputs Voltage | 16 – 140 V DC |
TRPA E – stop Input Voltage | 18 – 140 V DC |
TRPA Speed Inputs Voltage | – 15 – 15 V DC |
E – stop Power Output Voltage | 28 V DC O.C., 17 mA DC S.C. |
TRPA Contact Out Voltage | 24 V DC |
Ethernet Networks | 1 – 2 |
Speed Sensor Inputs | 4 |
Application Type | Simplex, TMR |
Installation | Direct |
Operating Temperature | – 40 °C to 85 °C |
Humidity | 5 % – 95 % RH, non – condensing |
Main Features and Advantages
Turbine protection: The GE IS220PTURH1A ensures the safe operation of turbines by providing primary trip functions to prevent damage during fault conditions4. Mark VIe series compatibility: It is designed specifically for integration with Mark VIe turbine control systems, enhancing system performance and reliability4. Emergency shutdown capability: This module can detect abnormal operating conditions and initiate immediate shutdowns to protect critical turbine components4. It also has auto – reconfiguration functionality, which can automatically download from the controller to the I/O pack, including baseload, boot load, firmware, and parameters1. In addition, it is equipped with LED indicators for network status, power, and attention, as well as an internal temperature sensor and a reset circuit3.
Application Areas
The GE IS220PTURH1A is primarily used in Mark VIe – based turbine control systems4. In power generation plants, it plays a critical role in ensuring the safe shutdown of turbines used for electricity generation in the event of system faults or malfunctions4. It is also suitable for high – demand industrial environments where turbines require real – time protection to prevent failures and ensure continuous operation4. Moreover, it can be applied in various industrial automation scenarios related to turbine control, providing reliable protection and control for the entire system.
Related Products
- IS210AEBIH1B: May be a related module in the same Mark VIe series, perhaps with different functions or interface requirements, but working together with GE IS220PTURH1A in the overall turbine control system.
- IS215WEPAH2B: Likely another component that has some compatibility or connection with the Mark VIe system, potentially involved in power supply or communication functions to support the operation of GE IS220PTURH1A.
- IS200TRLYS1B: Possibly a module with similar application scenarios in the turbine control field, but may have different technical characteristics and functions compared to GE IS220PTURH1A.
- TURBINE CONTROL TERMINAL BOARDS: Such as the TTUR board, which is directly connected to the GE IS220PTURH1A to form a complete turbine control system, providing interface and connection functions for the module.
- VTUR BOARD: It is often used in combination with the GE IS220PTURH1A and other boards to achieve more comprehensive turbine control functions, enhancing the overall performance of the control system.
Installation and Maintenance
Installation pre – preparation: Before installing the GE IS220PTURH1A, make sure to check the compatibility of the equipment and confirm that the installation environment meets the requirements, including the appropriate temperature, humidity, and vibration conditions. Also, prepare the necessary tools and ensure a proper grounding system. The module should be installed on the designated TTUR terminal board according to the installation instructions.
Maintenance suggestions: Regularly check the status of the GE IS220PTURH1A through the LED indicators to monitor network status, power, and any attention – required signals. Clean the module regularly to prevent dust and debris from affecting its performance. Check the connection of the DC – 62 pin connector to ensure it is secure. Refer to the product manual for detailed troubleshooting and maintenance procedures.
Product Guarantee
GE provides a quality – assured guarantee for the GE IS220PTURH1A. There is a one – year warranty period, during which any quality – related issues will be addressed by the manufacturer. Professional technical support is also available to help customers solve problems encountered during use. GE is committed to ensuring the reliable operation of the product and providing customers with comprehensive after – sales service to enhance customer satisfaction.
Brand model: GE IS220PTURH1A
Product Name: Primary Turbine Trip Pack
Warranty: 1 year
Size: N/A
Weight: 0.84 lbs (approx.)4
Origin: USA4
Inventory: Spot/Futures (depending on the supplier)
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
Product Name: Primary Turbine Trip Pack
Warranty: 1 year
Size: N/A
Weight: 0.84 lbs (approx.)4
Origin: USA4
Inventory: Spot/Futures (depending on the supplier)
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
