Description
Product Overview
The GE IS220PDOAH1A is a high-performance Discrete Output (DO) Control Board designed for GE’s Mark VIe Speedtronic Turbine Control System, specializing in precision relay control and real-time signal management for mission-critical industrial applications. As a core component of the Mark VIe ecosystem, this module acts as a bridge between the control system and field devices (e.g., valves, actuators, solenoids), enabling reliable execution of discrete commands in harsh environments such as oil & gas platforms, power plants, and offshore wind farms 16.
Featuring 12 isolated relay outputs with 32 VDC/3.15 A per channel, the GE IS220PDOAH1A supports hot-swappable redundancy (simplex/DMR configurations) and integrates with GE’s ControlST software for programmable logic control and diagnostics. The board interfaces with dual Ethernet ports (10/100 Mbps) and Ionet communication networks, enabling seamless integration with distributed I/O systems and plant-wide SCADA platforms. Its built-in local processor and advanced filtering capabilities (4 ms hardware filtering) ensure accurate signal acquisition and noise reduction, critical for maintaining system reliability in high-vibration or EMI-prone settings 36.
As part of the Mark VIe HazLoc-certified subseries, the GE IS220PDOAH1A is approved for use in hazardous locations when paired with compatible terminal boards (e.g., IS200TDBSH2A or IS200TDBTH2A). This modular design allows for flexible system expansion, supporting up to three redundant modules in Triple Modular Redundancy (TMR) architectures for SIL-rated safety applications 46.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | GE IS220PDOAH1A |
| Manufacturer | General Electric (GE) |
| Product Type | Discrete Output (DO) Control Board |
| Series | Mark VIe (Turbine Control) |
| PCB Coating | Conformal coating (anti-moisture, dust, EMI) |
| I/O Configuration | 12 relay outputs (32 VDC/3.15 A per channel) |
| Communication | Ionet, Modbus TCP, EtherNet/IP |
| Power Supply | 28 V DC ±2.1% (nominal, 27.4–28.6 VDC) |
| Operating Temperature | -40°C to +70°C (industrial grade) |
| Dimensions | ~8.26 cm (H) x 4.19 cm (W) x 12.14 cm (D) (approximate) |
| Weight | ~0.6 kg (1.32 lbs) |
| Compatibility | GE Mark VIe systems, ControlST v10.0+, terminal boards IS200TDBSH2A/IS200TDBTH2A |
| Redundancy Support | Simplex, Dual Modular Redundancy (DMR), Triple Modular Redundancy (TMR) |
| Certifications | HazLoc-approved for hazardous environments, CE, UL, RoHS |
Key Features & Advantages
High-Density Relay Control:
- 12 isolated relay outputs provide granular control over field devices, supporting applications such as turbine safety interlocks, valve actuation, and equipment status monitoring. The module’s optical isolation (1500 VAC) ensures immunity to ground loops and voltage spikes 68.
- Supports hot-swappable redundancy, allowing seamless replacement of faulty modules without system downtime. Redundant Ethernet ports ensure continuous data transmission even in the event of network failures 36.
Rugged Design for Harsh Environments:
- Conformal-coated circuitry and wide temperature range (-40°C to +70°C) enable reliable operation in offshore, desert, and high-altitude environments. EMI shielding minimizes interference from adjacent equipment, ensuring signal integrity in noisy industrial settings 111.
- HazLoc certification (when paired with compatible terminal boards) makes it suitable for explosive gas or dust environments, critical for oil & gas and chemical processing applications 46.
Scalable System Integration:
- Integrates with GE’s ControlST software for intuitive configuration of relay mapping, filter settings, and diagnostic thresholds. Supports industry-standard protocols (EtherNet/IP, Modbus TCP) for seamless integration with third-party SCADA systems 68.
- Modular design allows expansion of output capacity by daisy-chaining multiple GE IS220PDOAH1A modules, ideal for large-scale power plants or complex industrial automation systems 111.
Cost-Effective Maintenance:
- Built-in self-diagnostics and LED indicators simplify fault isolation, reducing mean time to repair (MTTR). GE-certified refurbishment services extend module lifespan, offering a cost-efficient alternative to replacement 36.
Application Areas
-
Power Generation:
- Gas/steam turbine power plants for fuel valve control, generator breaker management, and turbine safety interlocks. Monitors sensor inputs (e.g., temperature/pressure) and actuates relays to ensure stable operation in combined-cycle plants 68.
- Microgrid applications, regulating power flow between distributed energy resources (DERs) and utility grids through discrete control of circuit breakers and energy storage systems 611.
-
Oil & Gas:
- Offshore platforms for wellhead control, pump monitoring, and flare system activation in hazardous zones. Its HazLoc certification ensures compliance with strict safety standards 46.
- Refineries and petrochemical plants for process valve control, emergency shutdown systems, and equipment status signaling 811.
-
Industrial Automation:
- Manufacturing facilities (e.g., automotive, food processing) for conveyor system control, machine safety interlocks, and quality inspection triggers.
- Water treatment plants for pump control, valve actuation, and alarm signaling in critical infrastructure applications 68.
Related Products
- GE IS220PDIOH1A:
- Combined input/output module with 24 digital inputs and 12 relay outputs, suitable for systems requiring mixed I/O functionality. Backward compatible with IS220PDOAH1A for hybrid configurations 712.
- GE IS200TDBSH2A/IS200TDBTH2A:
- Terminal boards specifically designed for the IS220PDOAH1A, providing field wiring connections and HazLoc certification for hazardous environments 68.
- GE IS220PSUAH1A:
- Power Supply Unit designed for Mark VIe systems, providing stable power to the IS220PDOAH1A and other control modules 68.
- GE IS215WETAH1A:
- Wind Energy Torque Axis Control Board for torque management, complementary to the IS220PDOAH1A in comprehensive turbine control systems 611.
- GE IS215WEMAH1A:
- Wind Energy Main Cabinet Board for central data processing, forming a core trio with IS220PDOAH1A and pitch/torque control boards 611.
Installation & Maintenance
Installation Preparation:
- Verify the installation environment meets temperature (-40°C to +70°C) and humidity requirements. Use GE-approved mounting brackets and shielded cables to minimize EMI interference. Ground the board chassis properly to prevent static discharge 68.
- Configure the board via ControlST software to define relay mapping, filter settings, and redundancy modes. Follow GE’s GEH-6721G manual for wiring diagrams and terminal board compatibility guidelines 68.
Maintenance Recommendations:
- Routine Checks: Inspect for loose connections, corrosion, or thermal stress on components. Clean dust from vents to maintain cooling efficiency. Test redundancy functionality quarterly to ensure fault isolation capabilities 36.
- Firmware Updates: Regularly update firmware to the latest version (available through GE’s support portal) to access new features and security patches. Replace electrolytic capacitors every 5–7 years as part of preventive maintenance 36.
- Component Replacement: Use only GE-certified spare parts (e.g., relays, fuses). Coordinate with GE’s technical support for advanced troubleshooting or hardware repairs 36.
Product Warranty & Support
The GE IS220PDOAH1A comes with a 1-year warranty covering defects in materials and workmanship. For immediate deployment, the module is available in spot inventory and ships within 3–5 business days of payment. Backorders are fulfilled within 1 month, ensuring timely delivery for large-scale projects 618.
GE offers 24/7 technical support through its global network of certified engineers, providing assistance with system integration, troubleshooting, and training. Comprehensive documentation, including datasheets and installation manuals, is accessible via GE Vernova’s official support portal. With a commitment to reliability, GE ensures the GE IS220PDOAH1A delivers long-term performance in the most demanding industrial environments 68.
