​GE IS220PDIAH1A REV E discrete input module​​(XIONGBA)

​Brand model:​​ GE IS220PDIAH1A REV E
​Product Name:​​ Discrete Input Module
​Warranty:​​ 1 year
​Size:​​ 12.4 × 7.4 × 17.3 cm
​Weight:​​ 0.5 kg
​Origin:​​ USA
​Inventory:​​ Spot
​Delivery time:​​ 3 days after payment

Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description




📌 ​​Product Overview​

The ​GE IS220PDIAH1A REV E​ is a ​​discrete input module​​ within GE’s ​​Mark VIe Speedtronic​​ turbine control system, designed for high-reliability signal acquisition in industrial automation. It interfaces with sensors to digitize discrete signals (e.g., switch status, relay contacts) for real-time monitoring and control in critical environments like power plants and refineries. Key features include:

  • ​Dual Ethernet Ports​​: Support redundant communication via EtherNet/IP and Modbus TCP for seamless integration with Mark VIe controllers.
  • ​High Isolation​​: 1,500 VAC isolation between inputs and system, preventing ground loops in electrically noisy settings.
  • ​Hazardous Area Certification​​: Compliant with ​​Class I, Division 2​​ standards (ATEX/IECEx), ensuring safety in explosive atmospheres.

⚙️ ​​Technical Specifications​

Parameter Value
​Model​ IS220PDIAH1A REV E
​Input Voltage​ 24 V DC (27.4 V min)
​Input Channels​ Up to 24 discrete inputs
​Response Time​ ≤5 ms
​Isolation Voltage​ 1,500 VAC (input-to-system)
​Operating Temp​ ​-30°C to +65°C​​ (extended to ​​-40°C to +70°C​​ per REV H)
​Power Consumption​ 2.5 W
​Dimensions​ 12.4 × 7.4 × 17.3 cm
​Weight​ 0.5 kg
​Communication​ Dual RJ45 ports (10/100 Mbps Ethernet)


💡 ​​Key Features​

  1. ​High-Speed Signal Processing​
    • ≤5 ms response time enables rapid fault detection (e.g., turbine overspeed).
    • ​LED Diagnostics​​: Real-time status indicators (power, fault, network) simplify troubleshooting.
  2. ​Industrial Durability​
    • Extended temperature tolerance (​​-40°C to +70°C​​) and conformal-coated PCB resist humidity/chemical corrosion.
    • ​Hot-Swappable Design​​: Replace modules without system shutdown, minimizing downtime.
  3. ​Seamless Integration​
    • Native compatibility with ​​TSVOH1D terminal boards​​ and Mark VIe controllers.
    • Supports ​​TMR (Triple Modular Redundancy)​​ configurations for safety-critical systems.

🏭 ​​Application Areas​

  • ​Power Generation​​: Monitors turbine valve positions and safety interlocks in gas/steam plants.
  • ​Oil & Gas​​: Detects wellhead pressure switches and emergency shutdown triggers in SIL 2-rated systems.
  • ​Manufacturing​​: Tracks conveyor belt sensors and robotic cell interlocks with ±0.1ms precision.

🔧 ​​Installation & Maintenance​

  • ​Mounting​​: Vertical DIN rail installation via ​​TSVOH1D terminal board​​; ground resistance ≤0.1Ω.
  • ​Wiring​​: Use shielded cables with ≥20 cm separation from AC power lines to avoid EMI.
  • ​Maintenance​​:
    • Annual calibration of input thresholds.
    • Replace electrolytic capacitors after ​​50,000 operational hours​​ (≈5.7 years).

🔗 ​​Related Products​

IS220PTCCH1A Thermocouple Input Module

IS220PSVOH1A, REV E – Servo Control I/O Module

GE IS200HFPAG1A

IS200STCIH6A DIN-Rail Contact Terminal Board

IS200SPROH1ABC – Emergency Protection Terminal Board

Is400jgpag1a-terminal-board-for-pccah1a


🛡️ ​​Product Assurance​

  • ​Warranty​​: 12–18 months global coverage for defects.
  • ​Compliance​​: UL E207685, ATEX Zone 2, IEC 61508 (SIL 2).
  • ​Support​​: 24/7 remote diagnostics + 48-hour on-site response.
