Description
Product Overview
The GE IS215WEPAH2B is a Wind Energy Pitch Axis Control Board designed for GE’s Mark VIe Speedtronic Turbine Control System, specifically engineered to manage critical pitch control functions in wind turbines. As part of the Mark VIe functional safety ecosystem, this module provides precise control over blade pitch angles to optimize energy capture and ensure safe operation in varying wind conditions. Its rugged design with conformal coating protects against moisture, dust, and electromagnetic interference (EMI), making it suitable for offshore and high-vibration environments 310.
Key features include real-time data processing, support for simplex or triple modular redundant (TMR) configurations, and compatibility with GE’s ControlST software for advanced programming. The board interfaces with Ionet switches and distributed I/O modules to enable seamless integration with turbine control systems 1023.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | GE IS215WEPAH2B |
| Manufacturer | General Electric (GE) |
| Product Type | Wind Energy Pitch Axis Control Board |
| Series | Mark VIe (Wind Turbine Control) |
| PCB Coating | Conformal coating for environmental protection |
| Input/Output | 8 analog inputs, 1 incremental encoder input, 20 discrete inputs, 2 discrete outputs, 9 relay outputs, 2 RS-485 interfaces, 2 PWM control outputs 10 |
| Communication | Ionet, UDH (User Datagram Handler) |
| Power Supply | 125 V DC (nominal) 23 |
| Operating Temperature | -30°C to +65°C (industrial grade) |
| Physical Dimensions | ~26.41 cm (height) x 21.33 cm (width) (approximate) |
| Weight | ~0.6 kg (1.32 pounds) |
| Compatibility | GE Mark VIe Wind systems, ControlST software |
| Functional Revision | 1B |
Key Features and Advantages
Precision Pitch Control:
- Optimizes energy production by adjusting blade angles in real-time based on wind speed and turbine load, ensuring maximum efficiency and reducing mechanical stress 1023.
- Supports simplex or TMR redundancy for fault tolerance, with self-diagnostic capabilities to detect and isolate failures 10.
Rugged Environmental Design:
- Conformal coating and robust PCB construction shield against contaminants, while the operating temperature range (-30°C to +65°C) suits extreme industrial conditions 310.
- Factory-drilled mounting holes allow secure rack or panel installation in wind turbine nacelles 10.
Scalable System Integration:
- Works alongside GE’s Mark VIe I/O modules (e.g., IS215WEMAH1A, IS215WEPAH2BB) and UCV-series controllers (e.g., IS215UCVEM09B) for scalable control systems 1023.
- Supports EtherNet/IP, Modbus TCP, and OPC UA protocols for integration with plant-wide control systems 10.
Cost-Effective Solution:
- Offers a cost-effective alternative to CAN bus-equipped boards without compromising performance, making it ideal for systems where CAN functionality is unnecessary 3.
- Backward compatible with the obsolete IS215WEPAH2A, allowing incremental system upgrades without full replacement 3.
Application Areas
The GE IS215WEPAH2B excels in industries requiring reliable wind energy control:
- Wind Energy: Offshore and onshore wind farms for blade pitch control, grid synchronization, and turbine protection 310.
- Renewable Energy: Hybrid systems combining wind and solar power, optimizing energy capture and distribution 10.
- Industrial Automation: High-EMI environments such as manufacturing plants for process control and equipment monitoring 10.
- Oil and Gas: Offshore platforms for pump and compressor control, leveraging its environmental resilience 10.
Related Products
- GE IS215WEPAH2BB: Upgraded version with B-rated functional revision, offering enhanced signal processing and backward compatibility 323.
- GE IS215WEMAH1A: Wind Energy Main Cabinet Board for real-time data processing and grid synchronization 1018.
- GE IS210AEPSG1AFC: Alternative Energy Power Supply Module for stable power distribution in wind turbine control systems 5.
- GE IS215UCVEM09B: VME Controller Board for Mark VI systems, enabling high-speed data communication with the IS215WEPAH2B 10.
Installation and Maintenance
Installation Preparation:
- Verify the installation environment meets temperature (-30°C to +65°C) and humidity requirements.
- Use GE-approved mounting brackets and shielded cables to minimize EMI interference 10.
- Configure the board via GE’s ControlST software to define I/O mapping and safety thresholds 10.
Maintenance Recommendations:
- Routine Checks: Inspect for loose connections, corrosion, or overheating. Clean dust from vents to maintain cooling efficiency.
- Firmware Updates: Regularly update firmware to access new features and security patches (contact GE for updates) 7.
- Redundancy Testing: Simulate signal failures to validate fault isolation capabilities.
- Component Replacement: Replace worn-out relays or fuses with GE-certified parts to ensure compatibility 7.
Product Warranty and Support
The GE IS215WEPAH2B comes with a 1-year warranty covering defects in materials and workmanship. For immediate deployment, the module is available in spot inventory and ships within 3–5 days of payment. Backorders are fulfilled within 1 month 37.
GE offers 24/7 technical support and access to a global network of certified engineers for system integration, troubleshooting, and training. However, due to limited publicly available documentation, detailed technical guidance may require direct consultation with GE Vernova’s Mark VIe support team 710.
