Brand Model: GE IC697CSE784RR Product Name: Redundant Communication Processor Warranty: 1 year Size: 127 mm (W) × 102 mm (H) × 76 mm (D) Weight: 0.85 kg Origin: United States Inventory: Spot Delivery Time: 3 days after payment
Many products are not yet available—feel free to contact us for more options.
If there is a discrepancy between the product model and the displayed image, the model shall take precedence. For specific product photos, please reach out to us, and we will arrange on-site warehouse shots to confirm details.
With an extensive global warehouse network, there may be occasions where it takes a few hours to provide an accurate response. We appreciate your understanding, and rest assured we’ll address your inquiries as promptly as possible.
Product Overview
The GE IC697CSE784RR is an advanced redundant communication processor engineered to deliver uninterrupted data connectivity in high-availability industrial automation systems. As a variant of the GE IC697CSE784 within the PACSystems RX3i series, this module incorporates dual-core processing and redundant communication channels to eliminate single points of failure. Its architecture supports seamless failover between primary and secondary paths, making it ideal for applications where downtime risks catastrophic consequences, such as power generation, oil & gas, and pharmaceutical manufacturing.
The GE IC697CSE784RR features dual-port Ethernet (10/100 Mbps) and serial interfaces (RS-232/485), enabling simultaneous communication over two independent networks. It supports protocols like Modbus TCP/IP, Ethernet/IP, and DNP3, with built-in redundancy management to ensure data integrity during network disruptions. With 128 MB flash memory and 64 MB RAM, the module handles complex configurations while maintaining real-time performance. The 24 VDC dual power input ensures continuous operation even during voltage fluctuations, aligning with IEC 61508 SIL 2 standards for safety-critical environments.
In automation hierarchies, the GE IC697CSE784RR serves as a backbone for redundant control systems, enabling hot-swappable maintenance and zero-downtime upgrades. Its role spans integrating PLCs, HMIs, and SCADA systems in geographically dispersed facilities, where reliable data exchange is essential for compliance with global standards like ISO 22000 and FDA GMP.
Dual-port Ethernet ring topology, automatic failover (<50 ms)
Data Transfer Rate
Up to 100 Mbps (Ethernet), 1 Mbps (serial)
Memory Capacity
128 MB flash, 64 MB RAM
Operating Temperature
-40°C to +70°C
Physical Dimensions
127 mm (W) × 102 mm (H) × 76 mm (D)
Weight
0.85 kg
Certifications
IEC 61508 SIL 2, CE, UL, CSA
Main Features and Advantages
Dual-Core Redundancy: The GE IC697CSE784RR employs two independent processing cores and dual power inputs to ensure continuous operation. In the event of a primary core failure, the secondary core assumes control within milliseconds, maintaining critical processes like turbine speed regulation in power plants.
Ring Topology Support: Its dual Ethernet ports enable self-healing ring networks, where a fiber optic break triggers automatic rerouting within 10 ms, eliminating downtime in distributed systems like smart grids.
Hot-Swappable Design: The module supports live replacement of components without disrupting system operations, reducing maintenance windows by up to 70% compared to non-redundant models.
Enhanced Cybersecurity: Built-in IP filtering and encryption protect against unauthorized access, making it suitable for Industry 4.0 applications requiring secure data exchange with cloud platforms.
Application Areas
The GE IC697CSE784RR excels in industries demanding 99.999% uptime:
Power Generation: Manages redundant communication between gas turbines and grid control systems, ensuring stable energy output during peak demand.
Oil & Gas: Integrates offshore platforms with onshore control centers, supporting real-time monitoring of wellhead pressures and emergency shutdown systems.
Pharmaceuticals: Maintains continuous connectivity in cleanroom environments, ensuring compliance with FDA regulations during sterile production cycles.
Water Treatment: Bridges SCADA systems with sensor networks to optimize pump stations, preventing water supply interruptions in urban infrastructure.
In a case study, a chemical plant deploying the GE IC697CSE784RR reduced unplanned outages by 98% in its ethylene production line, saving over $1.5 million annually in lost output.
Related Products
GE IC697CSE784: Non-redundant base model for non-critical applications.
GE IC697PWR731RR: Redundant power supply module compatible with the GE IC697CSE784RR for dual-power configurations.
GE IC697MDL754: Digital I/O module supporting hot swapping for redundant I/O systems.
GE IC697CHS783: High-speed communication module for time-sensitive redundant control loops.
GE IC697MEM731: Memory expansion module to enhance configuration storage in redundant setups.
Installation and Maintenance
Installation Preparation:
Mount the GE IC697CSE784RR in a 19-inch rack with redundant power cabling. Configure dual Ethernet ports using GE’s Proficy software to establish ring topology.
Use shielded CAT6 cables for Ethernet connections and isolate serial lines to minimize EMI interference.
Maintenance Recommendations:
Perform quarterly diagnostics to verify redundant path latency and power supply health. Replace backup batteries every 3 years to preserve configuration data.
Update firmware bi-annually to access new cybersecurity patches and protocol enhancements, ensuring compatibility with evolving industrial IoT standards.
Product Warranty
The GE IC697CSE784RR comes with a 1-year warranty covering defects in materials and workmanship. GE’s Critical Asset Support (CAS) program offers 24/7 priority technical assistance, guaranteed 4-hour spare parts delivery, and proactive firmware updates for mission-critical installations.
