Description
GE IC697ACC728 is a high-reliability Genius Bus Termination Module designed for GE Fanuc Series 90-70 PLC systems, providing critical signal integrity and network termination in industrial automation environments. As an essential component of the Genius I/O network, the IC697ACC728 ensures proper signal reflection management, preventing data corruption and optimizing communication efficiency between PLC racks and distributed I/O modules. Its compact design and tool-less installation make it ideal for retrofitting existing systems or integrating into new builds, while its rugged construction withstands harsh industrial conditions.
The GE IC697ACC728 features dual termination resistors (120 Ω ±10%) and bypass capacitors (100 nF ±10%) to eliminate signal reflections in Genius Bus networks. It supports 1 Mbps communication speed and is compatible with both coaxial and twisted-pair cabling, ensuring flexibility in network topologies. The module’s IP20-rated enclosure protects against dust and accidental contact, while its operating temperature range of -25°C to +70°C ensures resilience in extreme industrial settings. With a weight of 0.5 kg and dimensions of 150 x 100 x 50 mm, the IC697ACC728 fits seamlessly into standard 19-inch racks, optimizing space utilization in control cabinets.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | GE IC697ACC728 |
| Manufacturer | GE Fanuc |
| Product Type | Genius Bus Termination Module |
| Termination Resistance | 120 Ω ±10% |
| Bypass Capacitance | 100 nF ±10% |
| Communication Speed | 1 Mbps |
| Cable Compatibility | Coaxial (RG-58) and twisted-pair (CAT5e) |
| Insulation Resistance | ≥100 MΩ (500 VDC) |
| Dielectric Strength | 1500 VRMS (1 minute) |
| Operating Temperature | -25°C to +70°C |
| Humidity | 5–95% RH (non-condensing) |
| Vibration Resistance | 5–500 Hz, 2.5 g |
| Shock Resistance | 50 g (11 ms duration) |
| Mounting Method | DIN rail or panel-mount (optional brackets) |
| Weight | 0.5 kg (1.1 lbs) |
Key Features and Advantages
- Signal Integrity Optimization: The IC697ACC728 eliminates signal reflections in Genius Bus networks, ensuring accurate data transmission and reducing system downtime.
- Dual-Termination Design: Supports both coaxial and twisted-pair cabling, making it suitable for diverse network configurations.
- Tool-Less Installation: Requires no additional tools for setup, simplifying maintenance and reducing installation time.
- Wide Compatibility: Works seamlessly with GE Fanuc Series 90-70 PLCs, Genius I/O networks, and third-party devices via standard wiring interfaces.
- Rugged Construction: IP20-rated enclosure and industrial-grade materials ensure reliable operation in dusty, humid, or temperature-fluctuating conditions.
Applications
The GE IC697ACC728 is widely used in industries requiring robust signal management:
The GE IC697ACC728 is widely used in industries requiring robust signal management:
- Manufacturing: Ensuring stable communication in automotive assembly lines, robotics cells, and packaging machinery.
- Oil and Gas: Managing signal integrity in offshore platforms, refineries, and pipeline monitoring systems.
- Power Generation: Optimizing data transmission in turbine control systems and power distribution panels.
- Water Treatment: Ensuring reliable communication in wastewater treatment plants’ motor control centers.
- Pharmaceuticals: Maintaining signal stability in cleanroom automation systems for sterile manufacturing.
Related Products
- GE IC697ACC702: Bus terminator plug for Genius I/O networks, ensuring signal integrity.
- GE IC697CBL700: Power supply extension cable for connecting multiple racks.
- GE IC697CPU731: High-performance PLC processor compatible with IC697ACC728-based systems.
- GE IC697BEM731: Genius Bus Controller module for expanding I/O networks.
- GE IC697CHS750: Rear-mount rack compatible with IC697ACC728, supporting up to 5 I/O modules.
Installation and Maintenance
- Pre-Installation Preparation: Verify network topology and ensure the system power is off. Clean the mounting area to prevent debris ingress.
- Mounting: Secure the IC697ACC728 to a DIN rail or panel using the provided brackets. Connect the termination module to the end of the Genius Bus cable.
- Termination Setup: Adjust the termination resistor and bypass capacitor according to the network requirements (coaxial or twisted-pair).
- Maintenance: Inspect connections quarterly for loose cables or corrosion. Replace damaged modules immediately to avoid signal degradation. Clean the enclosure with a dry cloth to maintain airflow.
Product Warranty and Support
The GE IC697ACC728 comes with a 1-year warranty covering defects in materials and workmanship. GE Fanuc provides global technical support, including firmware updates and troubleshooting guidance. For mission-critical applications, optional extended warranties and priority service plans are available.
The GE IC697ACC728 comes with a 1-year warranty covering defects in materials and workmanship. GE Fanuc provides global technical support, including firmware updates and troubleshooting guidance. For mission-critical applications, optional extended warranties and priority service plans are available.
