Description

Product Overview

The GE IC695PSD140B is a high – performance power supply module from GE, designed specifically for use within the PACSystems™ RX3i series. As a critical component in industrial automation systems, it plays a pivotal role in providing stable and reliable power to ensure seamless operation of connected devices.

This multi – purpose 40W power supply is engineered to operate with a 24VDC input. It features advanced circuitry that enables it to support various applications, including redundancy and load – sharing scenarios. With multiple output points, such as a 5.1V DC output, a 24V DC relay output for powering relevant circuits, and a 3.3V DC output for internal use within RX3i modules, the GE IC695PSD140B caters to diverse power requirements of the system. Its design allows for easy integration into the universal backplane of the RX3i PACSystems, occupying just a single slot, which simplifies the overall system architecture.

Technical Specifications

Parameter Name	Parameter Value
Product Model	IC695PSD140B
Manufacturer	GE
Product Type	Power Supply Module
Input Voltage	24VDC (nominal), input range 18 – 30VDC
Output Voltages	5.1VDC, 24VDC (relay output), 3.3VDC (internal use)
Output Power	40W
Input Power	60W
Load Capacity	40W
Module Type	Expansion Power Supply
Backplane Support	Universal backplane of RX3i PACSystems (remote bases only)
LED Indicators	Yes, for power on, power good, and fault conditions
Operating Temperature Range	– 25°C to + 70°C (- 13°F to + 158°F)
Storage Temperature Range	– 40°C to + 85°C (- 40°F to + 185°F)
Relative Humidity	5% to 95%, non – condensing
Dimensions (H×W×D)	139 mm (5.47 in)×118 mm (4.65 in)×120 mm (4.72 in)
Weight	1.2 kg (2.65 lbs)
Mounting	Backplane mounting; din rail mounting option with adapters (sold separately)
Compliance	CE, UL, CSA, ROHS

Main Features and Advantages

Versatile Power Provision

The GE IC695PSD140B offers multiple output voltages, making it suitable for powering different types of components within the industrial automation system. Whether it’s powering output relay modules with its 24V DC relay output or providing internal power to RX3i modules with the 3.3V DC output, it can handle a wide range of power needs.

High – Efficiency Operation

With a high – efficiency rating (typically 90% or higher), this power supply module minimizes energy consumption and heat generation. This not only helps in reducing operational costs but also ensures stable operation in environments where heat management is crucial.

Reliable Protection Mechanisms

Built – in overload and short – circuit protection safeguard the module and connected devices from potential damage due to electrical faults. This enhances the overall reliability of the industrial automation system, reducing the risk of unplanned downtime.

Easy Integration

Designed to be directly mounted onto the series 90 – 30 backplane or on din rails (with adapters), the GE IC695PSD140B allows for straightforward integration into existing or new automation setups. The LED status indicators provide real – time information about the power supply’s condition, simplifying troubleshooting and maintenance.

Application Areas

Automated Manufacturing

In manufacturing plants, the GE IC695PSD140B powers programmable logic controllers (PLCs), sensors, and actuators that are integral to production lines. For example, it can ensure a stable power supply to robotic arms, conveyor systems, and automated assembly equipment, enabling precise and continuous operation, which is essential for high – volume production.

Process Control Systems

In industries such as chemical, oil & gas, and food & beverage, where process control is critical, this power supply module provides reliable power to control systems. It can power the equipment that monitors and adjusts process variables like temperature, pressure, and flow, ensuring that the production processes adhere to strict quality and safety standards.

Material Handling

In warehouses and distribution centers, automated material handling systems rely on stable power. The GE IC695PSD140B can power automated guided vehicles (AGVs), sorting systems, and lifting equipment, ensuring smooth and efficient movement of goods.

Energy Management

In energy – related applications, such as power generation plants or smart grid systems, this power supply module can provide power to monitoring and control devices. It ensures that equipment responsible for managing energy distribution, monitoring power quality, and controlling power generation processes operate without interruption.

Installation and Maintenance

Installation Preparation

Before installing the GE IC695PSD140B, ensure that the power to the entire system is switched off to avoid electrical hazards. Check the compatibility of the module with the existing backplane or din rail mounting system. Clean the installation area to prevent dust or debris from interfering with the electrical connections. Verify that the input voltage source is within the specified range of 18 – 30VDC. Mount the GE IC695PSD140B in the appropriate slot on the backplane or attach it to the din rail using the provided or separately – purchased adapters. Make sure all wiring connections are secure and properly insulated.

Maintenance Advice

Regularly inspect the GE IC695PSD140B for any signs of physical damage, such as cracks or discoloration on the casing. Monitor the LED status indicators to quickly identify any power – related issues, such as power loss, overloading, or faults. Clean the module periodically using a dry, non – conductive cloth to remove dust, which can affect heat dissipation and potentially lead to overheating. Check the input and output voltages regularly to ensure they are within the specified limits. In case of any abnormal behavior, refer to the product manual for troubleshooting steps. If necessary, replace the module with a new one to maintain the reliability of the automation system.

Product Guarantee

GE offers a 1 – year warranty for the GE IC695PSD140B. This warranty covers any defects in materials and workmanship that occur during normal use. In the event of a problem within the warranty period, GE’s dedicated technical support team is available to provide assistance. They can offer remote diagnostics or, if required, arrange for on – site service. Additionally, GE provides access to comprehensive product documentation, including user manuals and technical specifications, to help users with installation, operation, and maintenance. With GE’s global network of service centers, customers can be confident in receiving prompt and effective support for their GE IC695PSD140B power supply module, ensuring long – term reliable operation of their industrial automation systems.

Brand model: GE IC695PSD140B
Product Name: PACSystems™ RX3i Universal Backplane 40W Multi – Purpose Power Supply
Warranty: 1 year
Size: 139 mm (H)×118 mm (W)×120 mm (D)
Weight: 1.2 kg
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
