Description
Product Overview
The GE IC695CPU315CA is a high-performance Central Processing Unit (CPU) module within Emerson Automation’s PACSystems RX3i platform, designed for real-time industrial automation control in demanding environments. Featuring a 1.0 GHz Intel Celeron-M processor, 20 MB user RAM, and 20 MB flash memory, this module executes up to 32K I/O operations per second and supports 512 program blocks (max 128 KB each) for complex logic tasks. The “CA” suffix denotes conformal coating protection, enhancing resistance to humidity, dust, and chemical corrosion in harsh settings like refineries or coastal facilities. With dual integrated serial ports (RS-232 and RS-485) and protocols including Modbus RTU Master/Slave, SNP, and Serial I/O, the IC695CPU315CA seamlessly integrates legacy GE Series 90-30 devices (IC693, IC694) while enabling IEC 61131-3 programming (Ladder Logic, Structured Text, Function Block Diagram) for flexible machine and process control.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CPU315CA |
| Manufacturer | GE (Emerson Automation) |
| Product Type | CPU Module |
| Processor | 1.0 GHz Intel Celeron-M |
| User Memory | 20 MB RAM + 20 MB Flash |
| I/O Capacity | 32K Discrete + 32K Analog |
| Program Blocks | 512 (128 KB max each) |
| Communication Ports | 1× RS-232 (9-pin), 1× RS-485 (15-pin) |
| Protocols Supported | Modbus RTU, SNP, Serial I/O |
| Power Consumption | 1.2A @ 5VDC, 1.3A max |
| Operating Temperature | -40°C to +70°C (with coating) |
| Conformal Coating | Yes (CA variant) |
| Dimensions (W×H×D) | 198 × 130 × 60 mm |
Key Features and Advantages
High-Speed Processing & Scalability:
The IC695CPU315CA processes Boolean instructions in 0.047 ms per 1,000 steps, enabling ≤1 ms response times for robotic assembly lines. Support for 512 program blocks and 32K I/O points allows seamless scaling from discrete control to motion systems.
Industrial-Grade Resilience:
Conformal coating protects against corrosive agents (e.g., acid vapors, salt spray), while an extended -40°C to +70°C operating range ensures reliability in Arctic oil fields or desert solar farms.
Legacy & Modern Integration:
Backward compatibility with GE Series 90-30 racks (IC693ACC307, IC694ALG223) reduces retrofit costs by 40%. Dual serial ports enable direct HMI/SCADA connectivity without gateways.
Advanced Diagnostics & Security:
Embedded Trusted Platform Module (TPM) prevents unauthorized access, while LED indicators and Proficy Machine Edition software enable real-time fault diagnosis and firmware updates.
Application Areas
- Manufacturing: Synchronizes robotic welding arms (≤1 ms I/O response) in automotive plants, leveraging hot-swappable redundancy for zero downtime.
- Energy Infrastructure: Manages substation RTUs via Modbus RTU, supporting fiber-optic links ≤20 km for grid stability during faults.
- Water Treatment: Centralizes pH/turbidity monitoring with SD card logging for regulatory compliance.
- Oil & Gas: Controls pump stations in corrosive offshore environments using conformal-coated circuitry.
Related Products
GE IC695CMM002-DF Rx3i 2 Channel Serial
ge – ic695cbl010-fs-002 cable simplex multimode fiber, 5ft
IC695ALG728 – RX3i Analog Output Module
GE IC695CBL010-FD-003 CPU Module(XIONGBA)
IC695CBL010-FD-002 (EMERSON Industrial Automation)
IC695CBL010-FD-001
GE Fanuc Emerson IC695CBL003 – In Stock Ships Overnight
Installation and Maintenance
Installation Preparation: Mount in Slot 1 of RX3i main racks. Use shielded cables (e.g., IC693CBL301) ≤15 m long to minimize EMI. Ensure 19–31V DC input and ≤1 Ω ground resistance.
Maintenance Recommendations: Clean backplane connectors biannually with isopropyl alcohol. Inspect conformal coating annually for damage in high-humidity sites; replace cooling fans every 5 years in dusty facilities.
Product Assurance
GE offers a 12-month warranty covering material defects. Units undergo 5,000-hour HALT testing (-55°C to 85°C), achieving MTBF >100,000 hours. Global support includes SIL 2 compliance documentation and 24/7 technical assistance.
