Description
Product Overview
The GE IC695CPU315 is a high – performance central processing unit belonging to the GE Fanuc PACSystems RX3i series. It is equipped with an Intel Celeron – M microprocessor, which offers a powerful 1 GHz processing speed, enabling efficient computation and data processing6. It has 20 MB of user memory (RAM) and 20 MB of flash memory, providing sufficient space for storing programs and data6. As a programmable controller, the IC695CPU315 can perform up to 32K I/O operations per second, meeting the requirements of complex industrial processes6. It uses a dual – backplane bus to communicate with I/O and intelligent option modules, and is also equipped with various communication interfaces such as Ethernet, RS – 232, and RS – 485, facilitating seamless connection and data exchange with other devices and systems6. In the automation system, it serves as a core controller, playing a crucial role in real – time control and monitoring.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CPU315 |
| Manufacturer | General Electric (GE) |
| Product Type | CPU Module |
| Processor | Intel Celeron – M, 1 GHz |
| User Memory | 20 MB (RAM) |
| Flash Memory | 20 MB |
| I/O Operations | Up to 32K per second |
| Program Blocks | Up to 512, 128 KB each |
| Serial Ports | RS – 232 and RS – 485 |
| Serial Protocols | SNP, Serial I/O, Modbus Master and Slave |
| Power Requirements | 3.3 V DC, 1 A or 5 V DC, 1.2 A |
| Working Temperature Range | 0 – 60°C |
| Physical Dimensions | 7.0 cm x 13.3 cm x 13.3 cm7 |
| Weight | 0.5 kg7 |
Main Features and Advantages
- High – performance processing: The 1 – GHz Intel Celeron – M microprocessor in the GE IC695CPU315 ensures rapid execution of control algorithms and data processing tasks, guaranteeing system real – time performance and accuracy8. It can handle a large number of I/O operations and program blocks, adapting to complex industrial control requirements3.
- Flexible memory configuration: With 20 MB of user memory and 20 MB of flash memory, the IC695CPU315 allows users to configure memory according to their needs, accommodating various complex control algorithms and data storage8. The automatic – positioning symbolic variables can utilize up to 20 MB of user memory, enhancing programming flexibility1.
- Diverse communication interfaces: This module is equipped with Ethernet, RS – 232, and RS – 485 interfaces, facilitating easy connection and data exchange with programming workstations, HMIs, SCADA systems, and other controllers6. It supports multiple serial protocols such as SNP and Modbus, enabling seamless integration into different industrial networks.
- Reliable protection mechanisms: The IC695CPU315 integrates hardware protection mechanisms like over – current protection, over – heat protection, and short – circuit protection, safeguarding the system against power overloads, damage, and other anomalies8. Additionally, its power management function monitors power status and load, providing fault detection and alarm capabilities to ensure stable system operation.
Application Areas
The GE IC695CPU315 is widely used in various fields of industrial automation and control systems6. In the manufacturing industry, it is used to control and monitor production line equipment such as machine tools, packaging machines, and conveyor belts, improving production efficiency and product quality8. In the energy sector, it is employed to regulate and monitor power generation equipment and power distribution systems, ensuring reliable energy supply. In the transportation industry, it is used for traffic signal control and the monitoring of railway transportation systems. Moreover, in chemical plants and refineries, the IC695CPU315 is utilized to adjust process parameters and monitor chemical reaction processes, guaranteeing safe and efficient production.
Related Products
- IC695CPU310: Similar to the IC695CPU315, it is also a CPU module in the GE Fanuc PACSystems RX3i series, but may have differences in processing speed, memory capacity, or communication interfaces.
- IC695ALG708: An analog input/output module in the same series, which works with the IC695CPU315 to complete analog signal acquisition and output in industrial control systems.
- IC695CPE330: A communication processor module that can enhance the communication capabilities of the IC695CPU315, enabling it to connect to more complex industrial networks.
- IC693PWR331: A power supply module that provides stable power for the IC695CPU315 and other modules in the system.
- IC697ACC700: An accessory module that may be used to expand the functionality of the IC695CPU315, such as providing additional storage or communication options.
Installation and Maintenance
- Installation preparation: Before installing the GE IC695CPU315, ensure that the installation environment meets the requirements, with a suitable temperature range and good ventilation. Clean the installation location and check the integrity of the rack and other components. When installing the CPU into the rack, make sure to follow the correct installation steps and firmly fix it. Connect the power supply according to the requirements and check the wiring to ensure it is correct.
- Maintenance suggestions: Regularly check the operating status of the IC695CPU315, including the power indicator, communication status, and error alarms. Clean the module regularly to prevent dust from affecting its performance. Check the connection of the communication cable and power cable to ensure they are not loose. When upgrading the firmware, follow the official upgrade procedures to avoid system failures. Additionally, it is recommended to back up the program and data regularly to prevent data loss in case of emergencies.
Product Guarantee
GE provides a quality – assured guarantee for the IC695CPU315. The product comes with a one – year warranty. During this period, if there are any quality problems with the product, GE will provide free repair or replacement services. GE also offers comprehensive after – sales service and technical support. Professional technical personnel are available to provide users with timely technical consultation and problem – solving services, helping users install, configure, and maintain the IC695CPU315 to ensure its stable operation in the automation system.
