Description

Product Overview

The GE IC694PWR330 is a power supply module belonging to the PACSystems RX3i series of General Electric7. It plays a vital role in providing stable power for the entire automation system. This module has the function of automatically adapting to voltage, eliminating the need for users to select different input voltages through jumpers5. It also features current limiting. In the event of a short – circuit, the power supply module will automatically shut down to prevent hardware damage5. With advanced diagnostic mechanisms and built – in intelligent switching fuses, it can closely cooperate with the CPU performance to achieve single – machine control, fail – safe, and fault – tolerance functions5. In the automation system, the GE IC694PWR330 ensures the reliable operation of various components, providing a solid power foundation for the normal operation of the entire system.

Technical Specifications

Parameter Name	Parameter Value
Product Model	IC694PWR330
Manufacturer	General Electric
Product Type	Power supply module
Input Voltage	120/240 Vac, 125 Vdc6
Output Voltage	24 VDC, 12 VDC, 5 VDC5
Output Power	Total power 30W; 5V at 15W, 24VDC relay 15W, 24VDC isolated power 20W5
Current Limiting	Yes5
Automatic Voltage Adaptation	Yes5
Diagnostic Function	Advanced diagnostic mechanism
Physical Dimensions	N/A
Installation Method	Mounted on the backplane like I/O5
Communication Protocol	N/A
Working Temperature Range	N/A

Main Features and Advantages

Reliable Power Supply: The GE IC694PWR330 has excellent voltage stability and can provide a stable power output, which is crucial for ensuring the normal operation of the automation system. Its automatic voltage adaptation function allows it to adapt to different input voltages, improving the versatility and stability of the power supply.
Over – current Protection: With a built – in current – limiting function, the module can effectively protect the entire system from damage caused by over – current or short – circuit faults. This feature enhances the reliability and service life of the system.
Intelligent Diagnosis: Equipped with advanced diagnostic mechanisms, the power supply module can quickly detect and report power – related faults, facilitating timely maintenance and troubleshooting, and reducing system downtime.
Easy Installation: It can be simply snapped onto the backplane like an I/O module and can work in coordination with any standard RX3i CPU, which simplifies the installation process and saves installation time and effort5.

Application Areas

The GE IC694PWR330 is widely used in various industrial automation fields. In the manufacturing industry, it provides power support for production lines, robotic arms, and CNC machine tools, ensuring the stable operation of these devices and improving production efficiency and product quality. In the field of process control, it is suitable for powering control systems in chemical, petroleum, and other industries, helping to precisely control process parameters and ensure the safety and stability of the production process. In addition, it also has important applications in the power and transportation industries. For example, it provides reliable power for power plant control systems and railway signal control systems, ensuring the normal operation of power generation, transmission, and railway transportation.

Related Products

IC694PWR321: It is a power supply module of the same series as the GE IC694PWR330, but there may be differences in some technical parameters and functions. For example, the output power and current – limiting values may be different.
IC695CPE302: It is a central processing unit of the GE PACSystems RX3i series. It works in conjunction with the GE IC694PWR330 power supply module to form a complete control system, with the CPU responsible for data processing and control, and the power supply module providing power.
IC694MDLxxx (such as IC694MDL241, IC694MDL645, etc.): These are I/O modules of the GE PACSystems RX3i series. They are connected to the GE IC694PWR330 power supply module through the backplane. The power supply module provides power for the I/O modules to ensure their normal operation, and the I/O modules are responsible for collecting and outputting field signals.

Installation and Maintenance

Installation preparation: Before installing the GE IC694PWR330 power supply module, make sure that the backplane and other related components are properly installed and grounded. Check the input voltage of the power supply to ensure that it is within the specified range. Clean the installation site to avoid dust and debris from affecting the normal operation of the module.

Maintenance suggestions: Regularly check the operating status of the GE IC694PWR330 power supply module, including the output voltage, current, and temperature. Check for any signs of overheating, burning, or abnormal noise. Clean the surface of the module regularly to prevent dust from accumulating. If a fault is detected, refer to the product manual for troubleshooting or contact the manufacturer’s technical support team in a timely manner.

Product Warranty

General Electric provides a one – year quality warranty for the GE IC694PWR3307. The company is committed to providing high – quality products and excellent after – sales service. If the product has quality problems during the warranty period, it will be repaired or replaced free of charge. In addition, General Electric also provides comprehensive technical support to help users solve various problems encountered during the use of the product, ensuring the reliable operation of the product in the long term.

Brand model: GE IC694PWR330
Product Name: Power supply module
Warranty: 1 year
Size: N/A
Weight: N/A
Origin: N/A
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment

Contact info

WhatsApp: +86 18030182217
Email: sandydcsplc@gmail.com
Phone: +86 18030182217
Wechat: +86 18030182217
Website: www.xiongbaparts.com
