Description

Product Overview

The GE IC694ALG223 is a high – density analog input module in the PACSystems RX3i series of programmable automation controllers (PAC)1. It is designed to collect and convert analog signals into digital equivalents for use in industrial automation control systems1.

This module features 16 single – ended analog input channels, each of which can be individually configured to accept input signals of 0 – 20 mA, 4 – 20 mA (standard), and 4 – 20 mA (enhanced)1. With a resolution of 12 bits and a conversion rate of 13 ms, it accurately and quickly acquires analog data1. The IC694ALG223 plays a crucial role in the automation system, serving as a bridge between field – measuring instruments and the control system, providing reliable data support for industrial control processes.

Technical Specifications

Parameter Name	Parameter Value
Product Model	IC694ALG223
Manufacturer	GE
Product Type	Analog Input Module
Input Channels	16 – channel single – ended
Input Current Range	0 – 20 mA, 4 – 20 mA (standard), 4 – 20 mA (enhanced)
Resolution	12 bits
Accuracy	±0.25% of full scale @ 25℃; ±0.5% of full scale over specified operating temperature range
Update Rate	6 ms
Isolation	Photoelectric isolation, withstands 250 V AC continuous voltage, 1500 V AC for 1 minute
Input Impedance	250 Ω
Input Low – Pass Filter Response	19 Hz
External Power Supply Voltage Range	20 – 30 V DC
Internal Power Consumption	120 mA from 5 V DC backplane bus, 65 mA from 24 V DC external user power supply

Main Features and Advantages

High – Density Design: The 16 – channel design of the GE IC694ALG223 allows for the acquisition of a large number of analog signals in a limited space, saving cabinet space and reducing costs3.
Flexible Input Range: It supports multiple current input ranges, which can be flexibly configured according to different types of sensors and field device output signals, improving the adaptability of the module3.
High – Precision Acquisition: With a 12 – bit resolution and high accuracy, it can accurately acquire analog signals, providing reliable data support for industrial control processes3.
Fast Response: The short update rate of 6 ms enables the module to quickly respond to changes in analog signals and promptly transmit new data to the control system, meeting the real – time requirements of industrial scenarios3.
Reliable Isolation Protection: The photoelectric isolation technology effectively prevents field signal interference from entering the control system, enhancing the stability and reliability of the module and the entire system, and enabling it to adapt to complex industrial electromagnetic environments3.

Application Areas

Manufacturing Industry: In the automotive production line, electronic equipment manufacturing, and other fields, the GE IC694ALG223 is used to collect various analog data such as temperature, pressure, flow, and displacement in the production process to achieve the control and monitoring of the production process3.
Energy Industry: In the fields of power control, oil and gas extraction, etc., it can collect analog signals such as voltage, current, and power in the power system, as well as various process parameters in the petrochemical production process, providing guarantee for the safety and operation of energy production3.
Chemical Industry: It is used in chemical process control, reactor monitoring, etc., to monitor parameters such as temperature, pressure, flow, and concentration in the chemical production process in real time, ensuring the stability and safety of the production process and preventing accidents3.
Environmental Protection Field: In water treatment, waste gas treatment, etc., it collects analog data such as water quality parameters and waste gas emission concentration to control environmental protection equipment and achieve energy conservation, emission reduction, and environmental quality improvement3.

Installation and Maintenance

Installation Preparation: Before installing the GE IC694ALG223 module, make sure that the installation environment meets the requirements, and the temperature and humidity are within the specified range. Check the integrity of the module and the connection ports, and ensure that there is no damage or looseness. Prepare the necessary tools and equipment, and follow the installation instructions to install the module in the appropriate slot of the PACSystems RX3i chassis.
Maintenance Recommendations: Regularly check the operating status of the GE IC694ALG223 module, including the power indicator, signal indicator, etc. Clean the module regularly to remove dust and dirt on the surface. Check the connection of the module regularly to ensure that the connection is firm and there is no looseness. If a fault is found, timely check the fault code and relevant information, and contact the professional technical support personnel for maintenance.

Product Warranty

GE provides a quality guarantee for the IC694ALG223 module. The product comes with a one – year warranty. During this period, if there is a quality problem with the product itself, GE will provide free repair or replacement services. In addition, GE also provides comprehensive after – sales service and technical support. If customers have any questions or problems during use, they can contact GE’s professional technical team at any time, and GE will provide timely solutions to ensure the normal operation of the product.

Brand model: IC694ALG223
Product Name: Analog Input Module
Warranty: 1 year
Size: 11.40×11.70×9.00 (unit: cm)4
Weight: 0.261 Kg4
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
