Description
Product Overview
The GE IC693CPU374 is a single-slot CPU module designed for GE Fanuc Series 90-30 Programmable Logic Controllers (PLCs), offering high-performance processing and advanced communication capabilities. Equipped with a 133 MHz AMD SC520 processor and 240 KB of configurable user memory, the module supports complex control logic and real-time data processing in industrial automation environments. Its dual embedded Ethernet ports (10/100 Mbps) enable seamless integration with HMIs, SCADA systems, and cloud platforms, while the RS-485 port (via power supply) supports SNP/SNPX protocols for legacy system connectivity.
Key features include floating-point math hardware for precision calculations, battery-backed real-time clock for time-sensitive operations, and hot-swap capability (with compatible CPUs) for reduced downtime. The non-volatile memory retains configuration data during power outages, while 1,500V RMS isolation ensures immunity to electrical noise. The IC693CPU374 is optimized for CPU baseplate installation (Slot 1 recommended) and supports up to 7 expansion/remote baseplates for scalable I/O configurations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693CPU374 |
| Manufacturer | GE Fanuc (Emerson Automation Solutions) |
| Product Type | Single-slot CPU module for Series 90-30 PLCs |
| Processor | AMD SC520 (133 MHz) |
| User Memory | 240 KB (configurable for %R, %AI, %AQ registers) |
| Communication Interfaces | 2 × Ethernet (10/100 Mbps), 1 × RS-485 (via power supply) |
| Protocol Support | SRTP, Ethernet Global Data (EGD), Modbus TCP (v3.10+ firmware) |
| I/O Capacity | 2,048 discrete I/O points (fixed) |
| Power Supply | 5V DC (7.4W typical via backplane) |
| LED Indicators | OK (green), RUN (amber), FAULT (red) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Compatibility | Series 90-30 CPUs (v6.50+ firmware), CPU/expansion/remote baseplates |
Main Features and Advantages
High-Speed Processing: The 133 MHz AMD SC520 processor delivers a 0.15 µs/boolean instruction execution time, making it suitable for high-speed control tasks in manufacturing and process industries. Its floating-point math hardware enables precision calculations for analog control and motion applications.
Flexible Communication: The dual Ethernet ports support SRTP, EGD, and Modbus TCP protocols, allowing simultaneous data exchange with multiple devices. The RS-485 port (via power supply) supports SNP/SNPX for integration with legacy Genius I/O systems.
Scalable Memory Configuration: The 240 KB user memory can be allocated dynamically to register memory (128–32,640 words), analog inputs (128–32,640 words), and analog outputs (128–32,640 words), accommodating diverse application requirements.
Industrial-Grade Reliability: Built with IP20-rated protection, the module resists dust and accidental contact. Its -40°C to +85°C storage temperature range ensures long-term reliability in extreme environments, while 1,500V RMS isolation safeguards against voltage spikes.
Cost-Effective Maintenance: The tool-less design and hot-swap capability enable rapid module replacement without system downtime. The LED diagnostics provide immediate feedback on power, communication status, and fault conditions.
Application Areas
Manufacturing Automation: The IC693CPU374 coordinates robotics, conveyor systems, and vision inspection sensors in automotive assembly lines. Its Modbus TCP support enables integration with ERP systems for real-time production monitoring.
Power Generation: Used in thermal and renewable energy plants, the module interfaces with turbine sensors, generator exciters, and grid-connected switchgear. Its remote I/O support enhances grid stability and fault detection in distributed energy systems.
Process Industries: In pharmaceutical and chemical plants, the IC693CPU374 monitors valve actuators, pH sensors, and flow meters for precise batch processing. The bus error logging feature ensures regulatory compliance by tracking deviations in high-purity environments.
Water/Wastewater Management: The module controls pump stations, chlorination systems, and level sensors in water treatment facilities. Its rack addressing flexibility accommodates expanding infrastructure, while the IP20-rated enclosure simplifies maintenance in humid or corrosive environments.
Related Products
- GE IC693CHS397: 5-slot CPU baseplate for compact systems, often paired with IC693CPU374 for modular control.
- GE IC693PWR330: High-reliability power supply module ensuring stable 5V DC power for IC693CPU374 and connected I/O modules.
- GE IC693CMM321: Ethernet interface module supporting TCP/IP and Modbus TCP, ideal for integrating legacy systems with modern industrial networks.
- GE IC693BEM330: FIP remote I/O scanner module for distributed control in oil/gas applications.
- GE IC693CBL302: 15-meter shielded expansion cable for connecting IC693CPU374 to expansion baseplates.
Installation and Maintenance
Installation Preparation:
- Hardware Setup: Install the IC693CPU374 in a CPU baseplate slot (Slot 1 recommended) and secure it with the module clamp. Connect the GE IC693CBL302 expansion cable to the Genius bus port. Configure the DIP switch for unique rack addressing (1–7) and ensure the CPU’s firmware is updated to v6.50+ for full functionality.
- Software Configuration: Use GE Proficy Machine Edition to define Ethernet parameters (IP address, subnet mask) and map global data registers. Verify module recognition via the PLC’s diagnostic tools.
- Safety Checks: Power on the system and confirm the OK LED is illuminated. Test communication by pinging the module’s IP address and monitoring LAN/SER LEDs for activity.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include visual verification of LED status, cleaning dust from the enclosure, and tightening terminal connections to 0.3–0.5 N·m torque.
- Advanced Maintenance: Annually, use GE’s diagnostic software to review bus error logs and replace any faulty cables or connectors. Avoid installing intelligent modules (e.g., PCM, ADC) on the IC693CPU374, as they must be placed on the CPU baseplate.
- Firmware Management: Periodically download the latest firmware from GE’s support portal to ensure compatibility with newer system components.
Product Guarantee
The GE IC693CPU374 is backed by a 12-month warranty covering manufacturing defects, with GE’s global technical support team available 24/7 for troubleshooting and repair services. In-stock units ensure rapid delivery within 3 business days, while custom configurations or bulk orders are fulfilled within 4 weeks. The product adheres to international standards (UL, CE, CSA), guaranteeing reliability in mission-critical applications.
For detailed installation guides and troubleshooting resources, refer to the GE Fanuc Series 90-30 System Manual or contact our technical support team for personalized assistance.
