Description
Product Overview
The GE IC693CHS392 is a high-performance 10-slot expansion baseplate designed for GE Fanuc Series 90-30 Programmable Logic Controllers (PLCs), serving as a critical component for scalable I/O expansion in industrial automation systems. As part of the Series 90-30 platform, this module provides a standardized framework for integrating up to 10 I/O or option modules, enabling distributed control across large facilities. The GE IC693CHS392 is ideal for applications requiring extensive sensor/actuator connectivity, such as manufacturing lines, power plants, and process industries, where flexibility and reliability are paramount.
Featuring a 25-pin D-type expansion connector, the GE IC693CHS392 supports daisy-chain configuration with up to 7 expansion baseplates (depending on CPU model), allowing seamless integration with the main CPU baseplate via a shielded cable (max. 15 meters/50 feet)11. Its open enclosure design facilitates easy module installation and maintenance, while the dip switch enables configurable rack addressing for system-wide coordination. The baseplate’s 5V DC power supply slot ensures stable power distribution to connected modules, with 150 mA typical current consumption optimized for energy efficiency in I/O-intensive setups11.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693CHS392 |
| Manufacturer | GE Fanuc (Emerson Automation Solutions) |
| Product Type | 10-Slot Expansion Baseplate for Series 90-30 PLCs |
| Bus Protocol | Series 90-30 I/O Bus (1.5 Mbps data rate) |
| Number of Slots | 10 (1 power supply slot + 9 I/O/option slots) |
| Power Supply | 5V DC (via dedicated slot; external power module required) |
| Current Consumption | 150 mA (internal logic) + module-dependent |
| Expansion Capability | Up to 7 baseplates (CPU 350+); 4 baseplates (CPU 331/340/341) |
| Cable Length | Max. 15 meters (50 feet) between baseplates |
| LED Indicators | Power Status, Bus Communication |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Mounting | Panel-mounted via integrated tabs; DIN rail compatible |
| Compatibility | Series 90-30 CPUs (firmware v5.0+), standard I/O modules (excluding intelligent modules) |
Main Features and Advantages
Scalable I/O Architecture: The GE IC693CHS392 supports 10 I/O/option modules, including digital/analog I/O, communication gateways, and specialty modules (e.g., temperature control), allowing tailored configurations for complex control scenarios. Its daisy-chain expansion capability extends system capacity without compromising performance, making it suitable for large-scale industrial automation11.
Rugged Industrial Design: Built with IP20-rated protection, the baseplate resists dust and accidental contact, ensuring reliable operation in harsh environments. The 1,500V RMS isolation between logic and field circuits safeguards against electrical noise, while the non-volatile memory retains configuration data during power outages11.
Flexible System Integration: The 25-pin expansion connector enables seamless integration with the main CPU baseplate, supporting both local and remote I/O setups. The dip switch configuration simplifies rack addressing, reducing setup time and minimizing errors. Notably, the baseplate does not support intelligent modules (e.g., PCM, ADC), ensuring compatibility with standard I/O devices and reducing complexity11.
Cost-Effective Maintenance: The tool-less module installation and hot-swap capability (when paired with compatible CPUs) enable rapid component replacement without system downtime. The LED diagnostics provide real-time feedback on power and communication status, streamlining troubleshooting.
Energy-Efficient Operation: With 150 mA internal power consumption, the GE IC693CHS392 optimizes energy usage in distributed I/O systems, reducing operational costs while maintaining high performance11.
Application Areas
Manufacturing Automation: The GE IC693CHS392 powers assembly lines by connecting PLCs to robotics, conveyor systems, and quality control sensors. Its scalability allows integration of up to 160 discrete I/O points or 32 analog channels, ensuring synchronized control across multiple production stages11.
Power Generation: In thermal or renewable energy plants, the baseplate interfaces with turbine sensors, generator exciters, and switchgear, enabling real-time monitoring of power output. Its remote I/O support facilitates decentralized control in large-scale power grids, enhancing system reliability8.
Process Industries: Used in chemical and pharmaceutical plants, the GE IC693CHS392 coordinates valve actuators, flow meters, and pH sensors, ensuring precise process control. Its bus error logging feature helps identify and resolve issues in high-purity environments, minimizing production delays11.
Water/Wastewater Management: The baseplate controls pump stations, filtration systems, and level sensors in water treatment plants. Its rack addressing flexibility accommodates expanding infrastructure, while the open enclosure design simplifies maintenance in humid or corrosive environments6.
Related Products
- GE IC693CPU350: High-performance CPU module supporting up to 7 expansion baseplates, ideal for large-scale systems requiring intensive I/O coordination.
- GE IC693PWR330: High-reliability power supply module compatible with the IC693CHS392, ensuring stable 5V DC power for connected modules.
- GE IC693MDL740K: 16-channel digital input module for discrete signal acquisition, commonly paired with IC693CHS392 in manufacturing applications.
- GE IC693ALG223: 16-channel analog current input module for process variable monitoring, expanding the system’s sensor integration capabilities.
- GE IC693CHS391: 10-slot main CPU baseplate (with CPU slot), often used alongside IC693CHS392 in hybrid configurations.
- GE IC693CBL302: Shielded expansion cable (15-meter length) for connecting IC693CHS392 to the main CPU baseplate.
Installation and Maintenance
Installation Preparation:
- Hardware Setup: Mount the GE IC693CHS392 on a stable panel using the integrated tabs. Install a GE IC693PWR330 power supply module in the leftmost slot and connect the IC693CBL302 cable to the 25-pin connector. Configure the dip switch to assign a unique rack address (1–7) and ensure the CPU’s firmware is updated to v5.0 or higher for full compatibility11.
- Software Configuration: Use GE Proficy Machine Edition to define I/O mapping and enable expansion bus communication. Verify cable continuity and module recognition via the PLC’s diagnostic tools.
- Safety Checks: Power on the system and confirm the POWER LED is illuminated. Test communication by polling connected I/O modules and verifying data integrity.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include visual verification of LED status, cleaning dust from the enclosure, and tightening terminal connections to 0.3–0.5 N·m torque.
- Advanced Maintenance: Annually, use GE’s diagnostic software to review bus error logs and replace any faulty cables or connectors. Avoid installing intelligent modules (e.g., PCM, ADC) on the IC693CHS392, as they must be placed on the CPU baseplate11.
- Firmware Management: Periodically download the latest firmware from GE’s support portal to ensure compatibility with newer system components.
Product Guarantee
The GE IC693CHS392 is backed by a 12-month warranty covering manufacturing defects, with GE’s global technical support team available 24/7 for troubleshooting and repair services. In-stock units ensure rapid delivery within 3 business days, while custom configurations or bulk orders are fulfilled within 4 weeks. The product adheres to international standards (UL, CE, CSA), guaranteeing reliability in mission-critical applications.
For detailed installation guides and troubleshooting resources, refer to the GE Fanuc Series 90-30 System Manual or contact our technical support team for personalized assistance.
