Description
Product Overview
The GE IC693BEM331 is a high-performance Genius Bus Controller designed for GE Fanuc Series 90-30 Programmable Logic Controllers (PLCs). Serving as a critical interface between the PLC and Genius I/O devices, this module enables seamless communication and data exchange in industrial automation systems. With support for up to 31 field devices and 128 bytes of bidirectional data transfer, the IC693BEM331 is ideal for applications requiring scalable and reliable I/O expansion, such as manufacturing lines, power plants, and water treatment facilities.
Engineered for real-time control, the GE IC693BEM331 facilitates connectivity with discrete sensors, analog transmitters, and specialized field devices through the Genius Bus protocol. Its hot-swap capability allows module replacement without disrupting system operation, minimizing downtime. The module features LED indicators for power, communication status, and fault detection, ensuring quick diagnostics. Compatible with Series 90-30 CPUs (e.g., IC693CPU311K, IC693CPU321K) and requiring 5V DC power from the PLC backplane, the IC693BEM331 integrates seamlessly into existing GE automation architectures, supporting both local and remote I/O configurations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693BEM331 |
| Manufacturer | GE Fanuc (now part of Emerson Automation Solutions) |
| Product Type | Genius Bus Controller Module |
| Bus Interface | Genius Bus |
| Max. Devices per Bus | 31 |
| Data Transfer Rate | 128 bytes |
| Power Supply | 5V DC (from Series 90-30 backplane) |
| Current Consumption | < 300 mA |
| LED Indicators | 2 (OK and COMM OK) |
| IP Rating | IP20 |
| Operating Temperature | 0°C to +60°C |
| Compatibility | Series 90-30 PLCs (firmware 5.0 or later) |
| Mounting | Series 90-30 5-slot or 10-slot baseplate |
Main Features and Advantages
High-Speed Communication: The GE IC693BEM331 delivers real-time data exchange over the Genius Bus, ensuring precise coordination between the PLC and distributed I/O devices. Its 128-byte data capacity supports complex control algorithms and large-scale I/O systems, making it suitable for demanding industrial environments.
Scalable Architecture: With the ability to connect up to 31 devices on a single bus, the module allows seamless expansion of I/O capabilities. It supports remote I/O racks (e.g., Series 90-70) and field control stations, enabling distributed control in large-scale automation setups.
Reliable Performance: Built with 1,500V isolation and IP20 protection, the IC693BEM331 withstands electrical noise and environmental contaminants. Its LED diagnostics and open-wire fault detection enhance system reliability by providing instant feedback on communication status and device health.
Flexible Configuration: The module is configurable via GE’s handheld monitor or programming software (e.g., Proficy Machine Edition), allowing users to define input/output data lengths and device parameters. It supports multiple communication modes, including global data and datagrams, for integration with diverse industrial networks.
Easy Maintenance: The hot-swap design enables module replacement without powering down the PLC, reducing downtime. GE’s global technical support and 1-year warranty ensure long-term operational stability.
Application Areas
Manufacturing: The GE IC693BEM331 controls conveyor systems, robotics, and quality inspection equipment by connecting PLCs to sensors and actuators. Its high-speed data transfer ensures real-time adjustments in assembly lines, optimizing productivity.
Power Generation: In power plants, the module monitors turbine performance and generator load by interfacing with analog transmitters and discrete switches. Its rugged design suits high-voltage environments, providing critical data for predictive maintenance.
Water/Wastewater Treatment: The IC693BEM331 manages pump stations, chemical dosing systems, and level sensors, ensuring efficient treatment processes. Its wide temperature range (-40°C to +85°C) and IP20 rating make it suitable for outdoor and harsh industrial settings.
Oil and Gas: Used in refineries and pipelines, the module facilitates communication between PLCs and flow meters, valves, and safety systems. Its scalability supports distributed control in large-scale facilities, enhancing operational flexibility.
Related Products
- GE IC693CPU311K: High-performance CPU module compatible with the IC693BEM331 for advanced automation systems.
- GE IC693CMM301: Genius Bus communication module for network integration with host systems.
- GE IC693PWR330: High-capacity power supply module ensuring stable operation for I/O-intensive applications.
- GE IC693MDL740K: 16-channel digital input module for discrete signal monitoring.
- GE IC693ALG223: 16-channel analog current input module for process control.
- GE IC693CHS397: Terminal block kit for secure wiring connections to field devices.
Installation and Maintenance
Installation Preparation:
- Hardware Setup: Mount the GE IC693BEM331 in a Series 90-30 baseplate and connect 5V DC power to the backplane. Configure the Genius Bus network using shielded cables to minimize interference. Ensure the PLC firmware is version 5.0 or later for compatibility.
- Software Configuration: Use Proficy Machine Edition to define the module’s input/output data lengths and device addresses. Verify communication parameters and test connectivity with field devices.
- Safety Checks: Inspect LED indicators for power and communication status. Test each device on the Genius Bus using a handheld monitor to confirm proper functionality.
Maintenance Recommendations:
- Monthly Inspections: Clean dust from the module and check LEDs for channel status. Tighten terminal connections to 0.37–0.45 lb·ft torque if loose.
- Annual Checks: Calibrate the module using GE’s IC641 Configurator software to maintain accuracy. Replace the BIU backup battery (if applicable) every 5 years.
- Firmware Updates: Download the latest firmware from GE’s support portal to address compatibility issues with newer PLC software versions.
Product Guarantee
The GE IC693BEM331 is backed by a 12-month warranty covering defects in materials and workmanship. GE’s 24/7 technical support provides troubleshooting assistance and replacement parts, ensuring minimal downtime. In-stock units typically ship within 3 business days, while custom configurations require 2–4 weeks. The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
For detailed wiring diagrams, programming guides, and safety information, refer to the GE Fanuc Series 90-30 User Manual or contact GE’s technical support. Always verify compatibility with your specific PLC model and application requirements before deployment.
