Product Overview
The GE IC670MDL740K is a high-performance 16-point positive logic sourcing output module designed for industrial automation applications, engineered for GE Fanuc’s Field Control Series. This module provides reliable discrete control for actuators, valves, and motors in manufacturing, power generation, and water treatment systems. It supports 12/24VDC output signals with 0.5A per channel current capacity, ensuring robust operation in harsh industrial environments. The module’s positive logic design switches loads to the positive side of the DC supply, delivering precise control over equipment such as pumps, conveyors, and solenoids.
Engineered for durability, the GE IC670MDL740K features 250VAC continuous isolation between user inputs and logic circuits, protecting against electrical noise and ground loops. LED indicators on the module provide real-time status updates for power, communication, and individual output channels, enabling quick visual diagnostics. The module operates on 18–30VDC power from the Bus Interface Unit (BIU) and requires an external 9.2–29.5VDC power supply for load switching, with a 5A fuse to safeguard against overcurrent conditions.
As part of GE Fanuc’s Field Control Series, the GE IC670MDL740K interfaces with a Bus Interface Unit (BIU) (e.g., IC670GBI002) to communicate with host PLCs or computers via the Genius Bus protocol. This modular design allows seamless integration into distributed control systems, supporting applications such as motor control, process automation, and building management. The module’s 200-microsecond response time ensures rapid actuation, critical for time-sensitive industrial processes.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC670MDL740K |
| Manufacturer | GE Fanuc (now part of Emerson Automation Solutions) |
| Product Type | Discrete Output Module (Positive Logic Sourcing) |
| Output Channels | 16 channels (single group) |
| Output Voltage Range | 9.2–29.5VDC |
| Output Current | 0.5A per channel (4A maximum per module) |
| Isolation | 250VAC continuous (user input to logic/ground); 1,500VAC for 1 minute |
| Response Time | 200 microseconds (on/off with 0.5A resistive load) |
| Power Supply (BIU) | 18–30VDC (111mA typical current draw) |
| External Power Supply | 9.2–29.5VDC (5A fuse-protected) |
| LED Indicators | Power (PWR), channel status (16 LEDs) |
| Operating Temperature | 0°C to +60°C |
| Weight | 0.9 kg |
| Mounting | DIN rail or panel-mounted via terminal block (e.g., IC670CHS002E) |
Main Features and Advantages
High-Reliability Control: The GE IC670MDL740K delivers 0.5A per channel current capacity and 250VAC isolation, ensuring reliable operation in high-noise environments. Its positive logic sourcing design minimizes voltage drop and supports a wide range of industrial loads, from small solenoids to motor starters.
Advanced Diagnostics: Built-in LED indicators provide real-time feedback on channel status, power supply health, and fuse integrity. The module’s open-wire detection and overcurrent protection alert operators to 异常 conditions, reducing downtime and maintenance costs.
Flexible Configuration: Each channel supports user-configurable output voltage (9.2–29.5VDC) and can be individually activated/deactivated via software. The module’s grouped single-ended output architecture simplifies wiring for cost-effective system designs, while Genius Bus compatibility enables seamless integration with distributed control networks.
Fast Response Time: With a 200-microsecond response time, the GE IC670MDL740K ensures rapid actuation of valves, motors, and other equipment, critical for applications requiring tight control loops. This speed makes it ideal for process automation and machine control systems.
Scalable System Integration: As part of the Field Control Series, the GE IC670MDL740K works with Genius Bus-compatible BIUs (e.g., IC670GBI002) to support distributed control networks. This scalability allows users to expand I/O capacity incrementally, making it suitable for small-scale machinery to large industrial plants.
Application Areas
Manufacturing: The GE IC670MDL740K controls conveyor belts, robotics, and assembly line actuators, ensuring efficient production line operations. Its high-current capacity supports motor starters and solenoids, while Genius Bus connectivity enables real-time monitoring and adjustments.
Power Generation: In power plants, this module manages turbine bypass valves, generator exciters, and switchgear control. Its isolation design safeguards against electrical noise in high-voltage environments, while fast response time ensures reliable operation during transient conditions.
Water/Wastewater Treatment: The GE IC670MDL740K actuates pump relays, valve solenoids, and chemical dosing systems in treatment facilities. Its open-wire detection prevents process disruptions caused by sensor failures, ensuring continuous water supply and wastewater management.
Building Automation: Integrating with HVAC systems, the module controls damper actuators, lighting relays, and energy distribution panels. Its wide voltage range accommodates diverse building systems, while LED diagnostics simplify maintenance in commercial and industrial buildings.
Related Products
- GE IC670GBI002: Bus Interface Unit (BIU) for connecting GE IC670MDL740K to Genius Bus networks, enabling communication with host PLCs or computers.
- GE IC670MDL240: 16-point discrete input module, complementing the GE IC670MDL740K in hybrid control systems requiring both input and output capabilities.
- GE IC670CHS002E: I/O terminal block for GE IC670MDL740K, providing secure wiring connections for discrete outputs.
- GE IC670ALG310: 8-channel analog voltage output module, expanding the system’s capability to handle analog control signals alongside discrete outputs.
- GE IC670MDL730: 16-point positive output module with 2A per channel current capacity, ideal for high-power applications requiring increased load support.
Installation and Maintenance
Installation Preparation:
- Hardware Setup: Mount the GE IC670MDL740K on a DIN rail using the terminal block (e.g., IC670CHS002E). Connect 18–30VDC power from the BIU and wire 9.2–29.5VDC external power to the module’s load terminals. Connect output signals to actuators or loads using shielded cables.
- Configuration: Use Proficy Machine Edition (PME) or Genius Handheld Monitor (HHM) to configure output logic and enable/disable channels. Verify Genius Bus communication parameters with the BIU.
- Safety Checks: Ensure grounding is properly established and cable connections are secure. Test the module’s fuse integrity and verify LED indicators for power and communication status.
Maintenance Recommendations:
- Monthly Inspections: Clean dust from the enclosure and inspect LED indicators for power and channel status. Tighten terminal connections to 0.37–0.45 lb·ft torque if loose.
- Annual Checks: Test output signals using a calibrated voltage source and verify isolation resistance between channels and ground. Replace the BIU backup battery (if applicable) every 5 years to maintain data retention.
- Firmware Updates: Download the latest firmware from GE’s support portal to address compatibility issues and enhance functionality. Regular updates ensure optimal performance with newer software versions.
Product Guarantee
The GE IC670MDL740K is backed by a 12-month warranty covering defects in materials and workmanship. GE’s global technical support team provides 24/7 troubleshooting and replacement parts, ensuring minimal downtime. In-stock units typically ship within 3 business days, while custom configurations require 2–4 weeks. The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
For detailed wiring diagrams, programming guides, and safety information, refer to the GE Fanuc Field Control User Manual or contact GE’s technical support. Always verify compatibility with your specific application requirements before deployment.
