GE IC660ELB912G: MicroGENI Daughterboard for Genius I/O Industrial Control Systems
Product Overview
The GE IC660ELB912G is a MicroGENI daughterboard designed for high-performance industrial automation and control systems, specifically within GE’s Genius I/O platform . As part of the discontinued GE Fanuc product line (now under Emerson Automation), it serves as a critical component for connecting remote I/O devices and enabling real-time data communication in manufacturing, process control, and infrastructure applications. The “G” suffix denotes a specific variant optimized for backward compatibility and extended functionality within legacy Genius I/O networks .
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | GE IC660ELB912G |
| Manufacturer | General Electric (GE Fanuc, now Emerson Automation) |
| Product Type | MicroGENI Daughterboard (Network Interface Module) |
| Compatibility | GE Genius I/O systems, PCIM (PC Interface Modules) like IC660ELB921/922 |
| Function | Remote I/O control, data communication, bus management |
| Power Requirement | 5 VDC, 400 mA (logic power) |
| Supported Devices | Up to 30 Genius I/O devices per daughterboard |
| Communication Rates | 38.4K, 76.8K, 153.6K (standard) or 153.6K (extended) baud rates |
| Physical Dimensions | ~120mm × 80mm × 40mm (compact design for DIN rail or PCIM integration) |
| Weight | ~0.3 kg |
| Processor | 6303 microprocessor for efficient data buffering and protocol handling |
| Memory | 16 KB shared RAM for I/O data and configuration |
| Warranty | 30 days to 1 year (third-party suppliers, e.g., DO Supply, Triconex1) |
Key Features and Advantages
Genius I/O Network Integration:
The IC660ELB912G acts as a bridge between host controllers (e.g., PLCs, industrial PCs) and Genius I/O devices, enabling seamless data exchange across distributed systems. It supports redundant configurations when paired with dual-slot PCIM modules (e.g., IC660ELB922), ensuring high availability in critical applications 79.
The IC660ELB912G acts as a bridge between host controllers (e.g., PLCs, industrial PCs) and Genius I/O devices, enabling seamless data exchange across distributed systems. It supports redundant configurations when paired with dual-slot PCIM modules (e.g., IC660ELB922), ensuring high availability in critical applications 79.
Flexible Communication:
With configurable baud rates and support for multiple communication protocols (e.g., Profibus-DP, DeviceNet), the module adapts to diverse industrial networks. Its 6303 microprocessor handles real-time data processing, ensuring low-latency control and diagnostics 78.
With configurable baud rates and support for multiple communication protocols (e.g., Profibus-DP, DeviceNet), the module adapts to diverse industrial networks. Its 6303 microprocessor handles real-time data processing, ensuring low-latency control and diagnostics 78.
Rugged Industrial Design:
Built to withstand harsh environments (operating temperature: -20°C to 70°C), the module features robust electrical isolation (1500V AC between I/O and host) and EMI protection, making it suitable for manufacturing floors, power plants, and offshore platforms 16.
Built to withstand harsh environments (operating temperature: -20°C to 70°C), the module features robust electrical isolation (1500V AC between I/O and host) and EMI protection, making it suitable for manufacturing floors, power plants, and offshore platforms 16.
Cost-Effective Retrofit:
As a discontinued component, the IC660ELB912G is available through third-party suppliers at competitive prices. Refurbished units undergo rigorous testing to meet OEM standards, offering a cost-efficient alternative to full system upgrades 910.
As a discontinued component, the IC660ELB912G is available through third-party suppliers at competitive prices. Refurbished units undergo rigorous testing to meet OEM standards, offering a cost-efficient alternative to full system upgrades 910.
Diagnostic Capabilities:
LED indicators (GENI OK, COMMS OK) provide real-time status feedback, simplifying troubleshooting. The module also supports background message exchange for fault management and device initialization, reducing downtime 79.
LED indicators (GENI OK, COMMS OK) provide real-time status feedback, simplifying troubleshooting. The module also supports background message exchange for fault management and device initialization, reducing downtime 79.
Application Areas
The GE IC660ELB912G is widely deployed in industries requiring scalable and reliable automation:
- Manufacturing: Coordinates robotics, conveyors, and assembly lines by connecting PLCs to distributed I/O modules. Its ability to manage up to 30 devices ensures efficient synchronization of complex machinery 513.
- Process Control: Integrates with sensors and actuators in chemical, pharmaceutical, and food processing plants to monitor parameters like temperature, pressure, and flow. The module’s fast response time (<2ms) supports precision control 36.
- Energy and Utilities: Used in substation automation, water treatment, and renewable energy systems to enable remote monitoring and control. Its compatibility with legacy GE systems makes it ideal for retrofitting aging infrastructure 211.
- Transportation: Supports traffic management systems, railway signaling, and airport baggage handling by facilitating data exchange between control centers and field devices 35.
Related Products
- IC660ELB921/922 PCIM Modules: Serve as the host interface for the IC660ELB912G, providing single or dual-slot connectivity to IBM PC/AT/XT computers 9.
- IC660ELB912 MicroGENI Daughterboard: Base variant without the “G” suffix, sharing similar functionality but with potential differences in protocol support or memory configuration 12.
- IC660ELB921J Programmable I/O Module: Expands I/O capabilities for Genius systems, complementing the IC660ELB912G in large-scale automation setups 11.
- IS200TSVCH1A Servo I/O Terminal Board: Integrates with GE’s Speedtronic turbine control systems (though the IC660ELB912G itself is not typically used in this context) 13.
Installation and Maintenance
Installation Steps:
- PCIM Integration: Mount the IC660ELB912G onto a compatible PCIM module (e.g., IC660ELB921) using spacers and screws. Ensure proper alignment with the host computer’s bus interface 79.
- Power and Cabling: Connect 5V DC power and Genius bus cables, ensuring shielded wiring to minimize interference. Configure dip switches for baud rate and device addressing 78.
- Software Setup: Use GE Fanuc’s Genius Configuration Software to map I/O points, define communication parameters, and test connectivity. Allocate 16–32 KB of host memory for data buffering 9.
Maintenance Recommendations:
- Environmental Checks: Regularly inspect for dust, corrosion, or loose connections, especially in high-humidity or high-vibration environments.
- Firmware Updates: While GE no longer supports updates, third-party providers may offer patched firmware for compatibility with modern control systems.
- Spare Inventory: Maintain a spare IC660ELB912G for hot-swap replacement during scheduled downtime. Ensure backups of configuration files 910.
Product Warranty and Availability
The GE IC660ELB912G is backed by a 30-day to 1-year warranty from third-party suppliers (e.g., DO Supply, Triconex1), covering defects in materials and workmanship for refurbished units . Warranty exclusions include damage from improper installation or unauthorized modifications. For post-warranty support, suppliers often offer extended service contracts and rapid replacement modules.
Inventory Status: Typically available in refurbished condition, with lead times ranging from 3–10 business days depending on location (e.g., U.S. suppliers vs. international vendors) 1011.
