Description
Product Overview
The GE IC200UEX626 is a high-performance 6-channel analog expansion module designed for GE Fanuc’s VersaMax Micro series, now under Emerson Automation Solutions. Engineered to enhance industrial automation systems, this module provides 4 differential analog inputs and 2 single-ended analog outputs, enabling precise measurement and control of analog signals such as temperature, pressure, and flow rates. With a 24 VDC power supply and compatibility with VersaMax Micro PLCs, the GE IC200UEX626 extends system capabilities in applications requiring advanced analog processing .
As part of the VersaMax platform, the GE IC200UEX626 offers 12-bit resolution and ±1% accuracy across its operating temperature range, ensuring reliable performance in demanding environments. Its modular design allows installation up to 2 meters away from the PLC, providing flexibility in system layout. The module includes removable terminal strips with hinged covers and diagnostic LED indicators for power status and operational health, simplifying troubleshooting and maintenance .
The GE IC200UEX626 supports a wide range of analog input/output configurations, including 0–10 V, -10–+10 V, 0–20 mA, and 4–20 mA signals. This versatility makes it ideal for integrating sensors, transmitters, and actuators in industries such as chemical processing, water treatment, and manufacturing. By combining with GE’s Proficy Machine Edition software, users can achieve centralized configuration and real-time monitoring of analog data, optimizing system efficiency .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200UEX626 |
| Manufacturer | Emerson Automation Solutions (formerly GE Fanuc) |
| Product Type | 6-Channel Analog Expansion Module |
| Power Supply | 24 VDC (19.2–30 VDC operating range) |
| Input Channels | 4 differential analog inputs |
| Input Ranges | 0–10 V, -10–+10 V, 0–20 mA, 4–20 mA |
| Output Channels | 2 single-ended analog outputs |
| Output Ranges | 0–10 V, 0–20 mA, 4–20 mA |
| Resolution | 12 bits |
| Accuracy | ±1% of full scale over 0–60°C |
| Isolation | Non-isolated (common mode voltage: ±40 V max) |
| Distance from PLC | Up to 2 meters |
| Mounting | 35 mm DIN rail or panel-mountable |
| Dimensions | 101.6 mm (W) × 88.9 mm (H) × 50.8 mm (D) |
| Weight | ~0.46 kg |
| Certifications | CE, cULus |
Key Features and Advantages
Flexible Analog I/O Configuration
The GE IC200UEX626 supports multiple analog signal ranges, allowing seamless integration with diverse sensors and actuators. Its 4 differential inputs minimize noise interference in high-vibration environments, while 2 single-ended outputs provide precise control for proportional valves or drives .
High Precision and Stability
With 12-bit resolution and ±1% accuracy, the module delivers reliable performance for critical applications like process control and quality assurance. Its 24.5 ms hold-up time at 19.2 VDC ensures continuous operation during transient power fluctuations .
Remote Installation Capability
The module can be positioned up to 2 meters away from the PLC, enabling distributed I/O setups in large-scale systems. This flexibility reduces cabling complexity and optimizes space utilization in industrial machinery .
Robust Design for Harsh Environments
Rated for 0–60°C operation, the GE IC200UEX626 withstands extreme temperatures, humidity, and dust. Its removable terminal strips with hinged covers protect against accidental damage and simplify field wiring .
Diagnostic Visibility
LED indicators for local power and operational status provide real-time feedback, streamlining fault detection. The module’s 3 W power consumption ensures energy efficiency while maintaining high performance .
Application Areas
Process Control
The GE IC200UEX626 monitors temperature, pressure, and flow rates in chemical plants and water treatment facilities, enabling closed-loop control of pumps, valves, and reactors. Its high accuracy ensures compliance with strict regulatory standards .
Manufacturing Automation
In automotive assembly lines, the module integrates with vision inspection systems to measure component dimensions and adjust robotic arm movements. It also supports predictive maintenance by analyzing vibration data from machinery .
Energy Management
Used in smart grid systems, the GE IC200UEX626 monitors voltage and current in power distribution networks, optimizing energy usage. It also controls HVAC systems in commercial buildings by processing data from occupancy sensors and thermostats .
Transportation Infrastructure
In logistics hubs, the module regulates conveyor belt speeds and overhead crane positioning by converting analog signals from load cells and encoders. Its remote installation capability simplifies retrofitting existing systems .
Related Products
- GE IC200CPU001: VersaMax Micro PLC requiring GE IC200UEX626 for analog expansion, enabling centralized control of automation processes.
- GE IC200PWR102: 120/240 VAC power supply module compatible with GE IC200UEX626 for hybrid AC/DC systems.
- GE IC200MDL650: 32-channel discrete input module, which can be paired with GE IC200UEX626 for combined analog/digital control.
- GE IC200UEX626J: Factory-refurbished version of GE IC200UEX626 with 2-year warranty, ideal for cost-sensitive applications.
- GE IC200EBI001: Ethernet interface unit enabling Modbus/TCP communication between GE IC200UEX626 and higher-level SCADA systems.
- GE IC200DBI001: DeviceNet network interface unit for integrating GE IC200UEX626 into distributed I/O architectures.
Installation and Maintenance
Installation Preparation:
- Mount the GE IC200UEX626 on a 35 mm DIN rail within 2 meters of the PLC. Use shielded twisted pair (STP) cables for analog signals to minimize interference.
- Configure input/output ranges via terminal block jumpers. For 4–20 mA signals, ensure the load resistance is between 10–500 Ω .
Maintenance Recommendations:
- Inspect terminal connections quarterly for corrosion and verify LED status indicators. Clean dust from the enclosure using compressed air.
- Calibrate the module annually using GE’s Proficy Machine Edition software to maintain accuracy. Replace the module if accuracy deviates beyond ±1% of full scale .
Product Guarantee
The GE IC200UEX626 comes with a 12-month standard warranty covering manufacturing defects, with optional 2-year extended warranties available from select sellers. Emerson’s global technical support provides 24/7 assistance for configuration and troubleshooting. The module complies with CE and cULus standards, ensuring reliability in industrial environments .
Brand Model: GE IC200UEX626
Product Name: 6-Channel Analog Expansion Module (VersaMax Micro Series)
Warranty: 1 year (standard); 2 years (optional from select sellers)
Size: 101.6 mm × 88.9 mm × 50.8 mm
Weight: ~0.46 kg
Origin: USA
Inventory: Spot/Futures
Delivery Time: 3–5 days for in-stock items; 4–6 weeks for pre-orders
Product Name: 6-Channel Analog Expansion Module (VersaMax Micro Series)
Warranty: 1 year (standard); 2 years (optional from select sellers)
Size: 101.6 mm × 88.9 mm × 50.8 mm
Weight: ~0.46 kg
Origin: USA
Inventory: Spot/Futures
Delivery Time: 3–5 days for in-stock items; 4–6 weeks for pre-orders
