Product Overview
The GE IC200UDR064 is a high-performance VersaMax Micro Plus Controller designed for industrial automation applications, offering a compact yet powerful solution for distributed control systems. As a 64-point PLC, it integrates 40 discrete 24VDC inputs and 24 relay outputs (2A capacity at 24VDC/240VAC), making it ideal for applications requiring high-density I/O in manufacturing, power generation, and water treatment. This controller operates on 24VDC input (19.2–30VDC range) and features a DIN rail-mountable design weighing only 528 grams, ensuring stable performance in diverse power environments.
Engineered with versatile input logic configuration, the GE IC200UDR064 supports both positive and negative logic for inputs, allowing flexibility in sensor/switch compatibility. The module includes status LEDs for power (PWR) and output voltage (OV) monitoring, as well as high-speed counter options (4 Type A counters or combinations of Type A/B) for precision control in motion applications. Its 24 relay outputs support both 24VDC and 240VAC loads, with a resistive load rating of 2A per channel, making it suitable for controlling high-power devices like motors, solenoids, and contactors in harsh industrial settings.
The GE IC200UDR064 uses Proficy Machine Edition (PME) software for programming and configuration, supporting ladder logic and structured text. Optional Ethernet modules (e.g., IC200UEM001-DF) enable Modbus TCP or GE’s SRTP protocol for network communication, though they cannot handle both protocols simultaneously. This controller is part of GE’s VersaMax Micro series, known for its scalability and reliability in industrial automation systems. It can be expanded with VersaMax Micro expansion modules (e.g., IC200UEI008 for digital I/O, IC200UEX624 for analog I/O) to extend system functionality, making it a versatile choice for complex control scenarios.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200UDR064 |
| Manufacturer | GE (General Electric) / GE Fanuc (current: Emerson Automation) |
| Product Type | Programmable Logic Controller (PLC) |
| Input Voltage | 24VDC (19.2–30VDC range) |
| Input Type | 40 discrete 24VDC logic inputs |
| Output Type | 24 relay outputs (2A at 24VDC/240VAC) |
| Input Logic Configuration | Positive or negative logic |
| High-Speed Counters | 4 Type A counters or combinations of Type A/B |
| Communication Ports | 1 serial port (RS-485) + 1 optional Ethernet port (via IC200UEM001-DF) |
| Programming Software | Proficy Machine Edition (PME) |
| Expansion Capability | Supports VersaMax Micro expansion modules |
| Operating Temperature | -20°C to +60°C |
| Weight | 528 grams |
| Mounting | DIN rail (7.5mm × 35mm) |
Main Features and Advantages
Dual-Voltage Output Flexibility: The GE IC200UDR064’s 24 relay outputs support both 24VDC and 240VAC loads, providing flexibility for diverse industrial applications. This dual voltage capability eliminates the need for external converters, simplifying system design and reducing costs.
Reliable Protection and Monitoring: Built-in short-circuit and overload protection safeguards connected modules, while status LEDs for power and output voltage enable real-time system monitoring. The module’s 20 ms hold-up time ensures uninterrupted operation during brief power interruptions, enhancing reliability in critical environments.
Programming and Communication: With Proficy Machine Edition (PME), users can program the GE IC200UDR064 using ladder logic or structured text, facilitating seamless integration with existing systems. Optional Ethernet modules (e.g., IC200UEM001-DF) enable Modbus TCP or SRTP communication, though prioritization between protocols is required. This flexibility supports integration with remote I/O devices and HMIs for centralized control.
Compact Design and Easy Installation: Weighing just 528 grams and designed for DIN rail mounting, the GE IC200UDR064 is ideal for space-constrained environments. Its IP20-rated enclosure protects against dust and accidental contact, while keyed connectors simplify installation and reduce wiring errors.
Scalability and Compatibility: As part of the VersaMax Micro series, the GE IC200UDR064 can be expanded with additional I/O modules (e.g., IC200UEI008 for digital inputs, IC200UEX624 for analog I/O) to meet evolving control requirements. This scalability makes it suitable for applications ranging from small-scale machinery to large industrial systems.
Application Areas
Manufacturing: The GE IC200UDR064 is widely used in assembly lines and packaging machinery to control motor drives, solenoids, and sensors. Its 24 relay outputs efficiently manage high-power devices, while the 40 DC inputs handle signals from proximity switches and encoders, ensuring precise operation in fast-paced production environments.
Power Generation: In power plants, this controller monitors generator status, switchgear, and auxiliary equipment. Its universal input voltage compatibility (19.2–30VDC) suits diverse grid conditions, while the high-speed counters support turbine speed monitoring and synchronization with power grids.
Water/Wastewater Treatment: The GE IC200UDR064 manages pump stations, valves, and filtration systems by controlling actuators and monitoring flow meters. Its dual-voltage outputs accommodate both low-voltage sensors and high-voltage pumps, while the compact design fits into space-constrained control panels.
Building Automation: Integrating with HVAC systems and access control devices, the GE IC200UDR064 powers temperature sensors, motion detectors, and relays. Its energy-efficient operation aligns with modern building automation standards, while the easy programming via PME software simplifies system configuration.
Related Products
Installation and Maintenance
Installation Preparation:
- Mount the GE IC200UDR064 on a 7.5mm × 35mm DIN rail using the provided hardware, ensuring proper grounding.
- Connect 24VDC power to the terminal block, verifying voltage within the 19.2–30VDC range.
- Configure input logic (positive/negative) via front-panel switches and set expansion rack IDs if using additional modules.
- Install optional Ethernet modules (e.g., IC200UEM001-DF) and connect communication cables, following GE’s wiring guidelines.
Maintenance Recommendations:
- Monthly Checks: Inspect LED status indicators for power and output voltage stability. Verify cable connections for corrosion or looseness, tightening terminals to 0.37–0.45 lb·ft torque if necessary.
- Annual Inspections: Clean dust from the enclosure and test output voltages using a multimeter. Replace the backup battery (if applicable) every 5 years to ensure data retention.
- Firmware Updates: Download the latest firmware from GE’s support portal to address compatibility issues and enhance system stability. Regular updates ensure optimal performance with new software versions.
Product Guarantee
The GE IC200UDR064 is backed by a 12-month warranty covering defects in materials and workmanship. GE’s global technical support team provides 24/7 troubleshooting and replacement parts, ensuring minimal downtime. In-stock units typically ship within 3 business days, while custom configurations require 2–4 weeks. The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
For detailed wiring diagrams, programming guides, and safety information, refer to the GE VersaMax Micro Plus Controller User Manual or contact GE’s technical support. Always verify compatibility with your specific application requirements before deployment.
