Product Overview
The GE IC200PWR102 is a dual-output AC/DC power supply module designed for GE’s VersaMax series, providing reliable power distribution for industrial automation systems. This compact module delivers 5 VDC and 3.3 VDC outputs to energize backplanes, CPUs, Network Interface Units (NIUs), and I/O modules, supporting scalable I/O expansion in manufacturing, power generation, and process control applications 13.
The GE IC200PWR102 is a dual-output AC/DC power supply module designed for GE’s VersaMax series, providing reliable power distribution for industrial automation systems. This compact module delivers 5 VDC and 3.3 VDC outputs to energize backplanes, CPUs, Network Interface Units (NIUs), and I/O modules, supporting scalable I/O expansion in manufacturing, power generation, and process control applications 13.
Engineered with universal AC input compatibility (85–132 VAC or 176–264 VAC via jumper selection), the GE IC200PWR102 ensures flexibility in global power environments. Its 27 VA input power and 1.5 A total output current (1.0 A at 3.3 VDC; 0.5 A at 5 VDC) efficiently support multi-rack setups, while built-in short-circuit and overload protection safeguards against system failures 14. The module features two status LEDs for real-time monitoring of power (PWR) and output voltage stability, while its IP20-rated enclosure protects against dust and accidental contact in harsh industrial settings 36.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200PWR102 |
| Manufacturer | GE (General Electric) / GE Fanuc (current: Emerson Automation) |
| Product Type | AC/DC Power Supply Module |
| Input Voltage | 85–132 VAC (120 VAC nominal) with jumper / 176–264 VAC (240 VAC nominal) without jumper |
| Input Frequency | 47–63 Hz |
| Output Voltage | 5 VDC (0.5 A max) and 3.3 VDC (1.0 A max); total output ≤1.5 A |
| Input Power | 27 VA |
| Hold-Up Time | 20 ms (at nominal input voltage) |
| LED Indicators | Power (PWR), Output Voltage (OV) |
| Enclosure Rating | IP20 |
| Dimensions | 49 mm (W) × 133.4 mm (H) × 39 mm (D) |
| Weight | 0.5 kg |
| Mounting | DIN rail (7.5mm × 35mm) or panel-mounted |
| Operating Temperature | -20°C to +60°C |
Main Features and Advantages
Dual-Voltage Output: The GE IC200PWR102 provides both 5 VDC (for legacy modules) and 3.3 VDC (for modern low-power components), ensuring compatibility with mixed VersaMax systems 13. This dual output reduces the need for external converters, simplifying cabling and lowering costs.
Universal Input Compatibility: With selectable 120 VAC or 240 VAC input via a jumper, the module adapts to global power standards. Critical note: Do not use the jumper with 240 VAC input to avoid damage 29.
Reliable Protection: Built-in short-circuit and overload protection prevents damage to connected modules, while the conformal-coated circuitry resists vibration and temperature fluctuations 36. The 20 ms hold-up time ensures uninterrupted operation during brief power interruptions.
Flexible Configuration: The module can serve as a primary power supply for CPU/NIU stations or as a supplemental power source when mounted on a power supply booster carrier (e.g., IC200PWB001), enabling high-density I/O expansions 412.
Easy Integration: The DIN rail-mountable design and keyed connectors simplify installation, while the user manual (521 pages) provides detailed wiring guidelines and troubleshooting procedures 8. The module seamlessly integrates with GE’s VersaMax PLCs and I/O modules.
Application Areas
Manufacturing: Deployed in assembly lines and packaging machinery, the GE IC200PWR102 powers I/O modules controlling motors, solenoids, and sensors. Its dual-voltage output supports hybrid systems with legacy and modern components 29.
Power Generation: Used in power plants to energize PLCs and SCADA systems, the module ensures stable operation of generators, switchgear, and auxiliary equipment. Its universal input voltage suits diverse grid conditions 36.
Water/Wastewater Treatment: In pump stations and treatment plants, the GE IC200PWR102 powers flow meters, level sensors, and actuators. Its compact size and IP20 rating make it suitable for space-constrained control panels 412.
Building Automation: Integrates with HVAC systems and security networks to power temperature sensors, motion detectors, and access control devices. The module’s low power consumption aligns with energy-efficient building designs 69.
Related Products
Installation and Maintenance
Installation Preparation:
- Mount the GE IC200PWR102 on a grounded DIN rail using the provided hardware.
- Configure the input voltage via the jumper:
- Install the jumper for 120 VAC (85–132 VAC range).
- Remove the jumper for 240 VAC (176–264 VAC range) 29.
- Connect the AC input wires to the terminal block, ensuring proper torque (0.37–0.45 lb·ft).
- Attach the DC output cables to the backplane, ensuring polarity alignment.
Maintenance Recommendations:
- Monthly Checks: Verify LED status indicators and inspect cable connections for corrosion or looseness.
- Annual Inspections: Clean dust from the enclosure and test output voltages. Replace the backup battery (if applicable) every 5 years 8.
- Firmware Updates: Download the latest firmware from GE’s support portal to address compatibility issues and enhance stability.
Product Guarantee
The GE IC200PWR102 is backed by a 12-month warranty covering defects in materials and workmanship. GE’s global technical support team provides 24/7 troubleshooting and replacement parts. In-stock units typically ship within 3 business days, while custom configurations require 2–4 weeks 312. The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
