Description
Product Overview
The GE IC200PWR002 is a 24 VDC input power supply module designed for GE Fanuc’s VersaMax™ series, now under Emerson Automation Solutions. Specializing in industrial automation systems, it provides stable power distribution to backplane devices such as CPUs, Network Interface Units (NIUs), and I/O modules. This module supports 18–30 VDC input voltage (nominal 24 VDC) and delivers 5 VDC and 3.3 VDC outputs with a total current capacity of 1.5 A 136. Its modular design enables hot-swappable replacement and includes built-in protections against short circuits, overloads, and reverse polarity, ensuring reliability in harsh industrial environments 16.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC200PWR002 |
| Manufacturer | Emerson Automation Solutions (formerly GE Fanuc) |
| Input Voltage Range | 18–30 VDC (nominal 24 VDC) |
| Output Voltage | 5 VDC (max 1.5 A) + 3.3 VDC (max 1.0 A) |
| Total Output Current | 1.5 A (sum of 5 VDC and 3.3 VDC outputs) |
| Input Power | 11 W |
| Hold-Up Time | 10 ms |
| Inrush Current | 20 A @ 24 VDC; 25 A @ 30 VDC (6 ms duration) |
| Isolation | 250 VAC continuous (channel-to-channel); 1,500 VAC for 1 minute (frame-to-ground) |
| Dimensions | 49 mm (W) × 133.4 mm (H) × 39 mm (D) |
| Weight | ~0.26 kg |
| Operating Temperature | 0–60°C (32–140°F) |
| Certifications | CE, cULus, UL |
| Mounting | 35 mm DIN rail or panel-mountable |
Key Features and Advantages
-
Dual Voltage Output:
- Simultaneously provides 5 VDC for logic circuits and 3.3 VDC for modern microprocessor-based modules, supporting hybrid industrial systems 16.
- Total output current limited to 1.5 A (e.g., 1.0 A at 3.3 VDC + 0.5 A at 5 VDC) 47.
-
Wide Input Voltage Range:
- Accepts 18–30 VDC input, accommodating unstable power sources common in manufacturing plants and remote locations 13.
-
Robust Protection:
- Built-in short circuit, overload, and reverse polarity protection safeguards connected devices from voltage transients 16.
-
Hot-Swap Capability:
- Modules can be replaced without system downtime, minimizing maintenance interruptions in continuous processes like water treatment and power generation 67.
-
Diagnostic Visibility:
- LED indicators for power status and fault conditions simplify troubleshooting in large-scale systems 6.
-
Flexible Configuration:
- Functions as main power supply when mounted on CPU/NIU or supplemental power on a booster carrier for high-power applications 16.
Application Areas
-
Manufacturing Automation:
- Powers PLCs, HMIs, and I/O modules in automotive assembly lines for conveyor control and robotic arm synchronization 620.
- Supports vision systems and quality control sensors in packaging machinery 20.
-
Process Control:
- Provides stable power to distributed I/O systems in chemical plants and water treatment facilities, ensuring reliable monitoring of pumps, valves, and actuators 26.
-
Energy Management:
- Integrates with smart grid systems to monitor circuit breakers and voltage sensors in power distribution networks 620.
- Optimizes HVAC systems in smart buildings by powering occupancy sensors and damper controls 6.
-
Transportation Infrastructure:
- Powers rail signaling systems and overhead crane controls in logistics hubs 620.
Related Products
- GE IC200CPU001: VersaMax CPU module for centralized control, requiring IC200PWR002 for backplane power 620.
- GE IC200GBI001: Genius network interface unit, compatible with IC200PWR002 for distributed I/O systems 6.
- GE IC200MDL650: 32-channel discrete input module, which can be powered by IC200PWR002 6.
- GE IC200PWR102: 120/240 VAC input power supply, serving as an alternative for AC-dominated environments 5.
Installation and Maintenance
Installation Steps:
-
Physical Setup:
- Mount on a 35 mm DIN rail with ≥2″ vertical clearance for heat dissipation 620.
- Connect shielded twisted pair (STP) cables to terminals, torque to 0.8–1.2 N·m (derived from similar GE modules) 626.
- Ensure DC- terminal is grounded to frame/earth ground for safety 36.
-
Configuration:
- Use GE’s Proficy Machine Edition software to verify backplane voltage (5 VDC/3.3 VDC) and assign power addresses 620.
- For supplemental power, install on a IC200PWB001 booster carrier 620.
Maintenance Recommendations:
- Regular Checks:
- Inspect terminal connections quarterly for corrosion and verify LED status indicators 620.
- Clean dust from the enclosure using compressed air 6.
- Firmware Updates:
- Update annually to enhance compatibility with newer Emerson systems 6.
- Spare Parts:
- Keep a replacement module (e.g., IC200PWR002J) on hand for critical applications, leveraging hot-swap capability 1520.
Product Guarantee
- Warranty:
- 12-month standard warranty covers manufacturing defects; third-party sellers (e.g., Radwell) may offer 2-year extended warranties 611.
- Technical Support:
- Global 24/7 support via Emerson for configuration guidance and troubleshooting 620.
- Compliance:
- Meets CE, cULus, and UL standards for industrial-grade reliability 613.
Brand Model: GE IC200PWR002
Product Name: 24 VDC Expanded Power Supply (VersaMax Series)
Warranty: 1 year (standard); 2 years (optional from select sellers)
Size: 49 mm × 133.4 mm × 39 mm
Weight: ~0.26 kg
Origin: USA
Inventory: Spot/Futures
Delivery Time: 3–5 days for in-stock items; 4–6 weeks for pre-orders
Order Notes: Verify compatibility with your PLC system (e.g., Series 90-30, RX3i) and ensure firmware requirements are met.
Product Name: 24 VDC Expanded Power Supply (VersaMax Series)
Warranty: 1 year (standard); 2 years (optional from select sellers)
Size: 49 mm × 133.4 mm × 39 mm
Weight: ~0.26 kg
Origin: USA
Inventory: Spot/Futures
Delivery Time: 3–5 days for in-stock items; 4–6 weeks for pre-orders
Order Notes: Verify compatibility with your PLC system (e.g., Series 90-30, RX3i) and ensure firmware requirements are met.
