GE IC200MDD844 Discrete Mixed I/O Module (VersaMax Series)(XIONGBA)

GE IC200MDD844 Discrete Mixed I/O Module (VersaMax Series)(XIONGBA)

Price:$999

Brand Model: GE IC200MDD844
Product Name: Discrete Mixed I/O Module (VersaMax Series)
Warranty: 1 year
Size: 110 mm × 66.8 mm × 50 mm
Weight: ~0.2 kg
Origin: USA
Inventory: Spot/Futures
Delivery Time: 3 days for in-stock items; 1 month for pre-orders
Order Notes: Ensure firmware compatibility with your PLC system

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

Product Overview

The GE IC200MDD844 is a high-performance Discrete Mixed I/O Module designed for GE Fanuc’s VersaMax™ series, catering to industrial automation systems requiring flexible input/output integration. Belonging to the robust IC200 product line, this module provides a total of 32 I/O points (16 discrete outputs and 16 discrete inputs), making it ideal for applications requiring a balanced combination of signal acquisition and control execution. The GE IC200MDD844 supports positive logic input and sourcing-type output, ensuring compatibility with a wide range of industrial sensors and actuators. Its compact design and modular architecture enable easy integration into distributed control systems, while built-in surge protection and EMC compliance ensure stable operation in harsh environments such as manufacturing plants and power stations.

Technical Specifications

Parameter Name Parameter Value
Product Model IC200MDD844
Manufacturer General Electric (GE)
Product Type Discrete Mixed I/O Module (VersaMax Series)
I/O Configuration 16 discrete outputs (sourcing type) + 16 discrete inputs (positive logic)
Input Voltage Range 0–30 VDC (nominal 24 VDC) 1319
Output Voltage Range 10.2–30 VDC (nominal 24 VDC) 319
Output Current 0.5 A per point at 30 VDC 319
Input Impedance ≤10 kΩ 319
Backplane Power 5 VDC @ 70 mA 319
External Power 18–30 VDC (nominal 24 VDC) 19
Response Time Input: 0.5 ms (base) + selectable filters (0/1/7 ms); Output: 1.5 ms typical 37
Dimensions 110 mm (W) × 66.8 mm (H) × 50 mm (D) 19
Weight Approximately 0.2 kg 9
Operating Temperature 0–60°C (32–140°F) 19
Certifications UL, CSA, CCC 9

Key Features and Advantages

  1. Versatile I/O Configuration: The GE IC200MDD844 combines 16 outputs and 16 inputs in a single module, reducing rack space and simplifying cabling in applications requiring mixed signal processing, such as conveyor control systems and packaging machinery 17.
  2. Enhanced Noise Immunity: Input filters (0/1/7 ms) mitigate interference from switch contact bounce or electromagnetic noise, ensuring reliable signal detection in noisy environments like automotive assembly lines 37.
  3. Flexible Logic Support: While defaulting to positive logic, the module can be upgraded to IC200MDD844C or newer versions to support negative logic and 12 VDC output, accommodating legacy systems or specialized equipment 1311.
  4. Hot-Swap Capability: Modules can be replaced without powering down the system, minimizing downtime during maintenance—a critical feature for continuous processes like oil refining 79.
  5. Diagnostic LEDs: Individual point status indicators (green for ON/OFF) and fault alerts (amber for overload) enable quick troubleshooting 79.

Application Areas

  1. Manufacturing Automation:
    • Controls robotic arms and conveyor belts in automotive plants by interfacing with proximity sensors and solenoid valves 715.
    • Monitors assembly line quality via vision systems and actuates reject mechanisms 15.
  2. Process Control:
    • Manages pump/motor 启停 and valve positioning in water treatment plants using analog-to-digital converters (e.g., GE IC200ALG320) 1315.
    • Regulates temperature and pressure in chemical reactors through discrete outputs to heaters and cooling systems 13.
  3. Energy Management:
    • Supervises power distribution networks by integrating with circuit breakers and voltage sensors 15.
    • Optimizes HVAC systems in smart buildings by controlling dampers and fans based on occupancy data 15.
  4. Packaging Machinery:
    • Coordinates labeling, filling, and sealing operations by synchronizing stepper motors and photoelectric sensors 715.

Related Products

  1. GE IC200CPU001/002: 90-30 series CPUs for data processing, compatible with IC200MDD844 for centralized control 717.
  2. GE IC200EBI001: Ethernet interface module enabling remote monitoring and Modbus TCP connectivity 14.
  3. GE IC200GBI001: Genius network interface unit for distributed I/O systems, expanding the module’s communication capabilities 14.
  4. GE IC200MDL640: 16-channel 24 VDC digital input module, complementing IC200MDD844 in high-density I/O setups 7.
  5. GE IC200PWR001: 24 VDC power supply module ensuring stable power delivery to the system 7.

Installation and Maintenance

Installation Steps:

  1. Physical Setup:
    • Mount the module on a 35 mm DIN rail, ensuring vertical clearance of ≥2″ for heat dissipation 719.
    • Connect shielded twisted pair (STP) cables for input/output signals, torque terminals to 0.8 N·m 719.
  2. Configuration:
    • Use GE’s Proficy Machine Edition software to set input filter times (default: 1 ms) and address assignments 718.
    • Verify compatibility with the backplane voltage (5 VDC) and external power supply (24 VDC) 19.

Maintenance Recommendations:

  • Regular Checks:
    • Inspect terminal connections quarterly for corrosion and verify LED status indicators 79.
    • Clean dust from the enclosure using compressed air 7.
  • Firmware Updates:
    • Update firmware annually to address security patches and enhance compatibility with newer GE systems 718.
  • Spare Parts:
    • Keep a replacement module (e.g., IC200MDD844C) on hand for critical applications, leveraging the hot-swap feature to minimize downtime 1119.

Product Guarantee

  • Warranty: GE provides a 12-month warranty against manufacturing defects, covering parts and labor 916.
  • Technical Support: Global 24/7 support is available for configuration guidance and troubleshooting 9.
  • Compliance: The module meets UL, CSA, and CCC standards, ensuring industrial-grade reliability 919.
