Description
Product Overview
The GE IC200GBI001 is a high-performance Genius Network Interface Unit (NIU) designed for distributed industrial automation systems, belonging to GE Fanuc’s VersaMax™ series. Serving as the backbone for I/O module integration, this module acts as a controller for up to 64 I/O modules across 8 racks, supporting 1,024 discrete I/O points and 128 bytes of analog I/O memory per scan 16. Engineered for scalability and reliability, the GE IC200GBI001 enables seamless communication between GE’s Series 90-70 PLCs, PACSystems RX7i/RX3i, and other host systems via the Genius protocol, ensuring real-time data exchange in manufacturing, energy, and process industries 616.
The GE IC200GBI001 features dual Genius terminals for redundant bus connections and supports data rates up to 153.6 kbaud, making it suitable for both standard and extended network configurations 617. Its modular design allows hot-swappable I/O module replacement without system downtime, while built-in surge protection and IP20-rated enclosure ensure stable operation in harsh environments (0–60°C) 26. The module’s enhanced diagnostics mode (EDM) provides actionable insights for predictive maintenance, reducing operational risks in mission-critical applications like gas turbine control systems 69.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200GBI001 |
| Manufacturer | General Electric (GE) |
| Product Type | Genius Network Interface Unit (NIU) |
| Supported Protocols | Genius, Modbus TCP/IP (optional) 12 |
| Network Data Rate | 153.6 kbaud (extended), 153.6/76.8/38.4 kbaud (standard) |
| I/O Capacity | 1,024 discrete I/O points, 128 bytes analog I/O |
| Power Consumption | 5V @ 250 mA, 3.3V @ 10 mA 16 |
| Mounting | 35 mm DIN rail (horizontal/vertical) 10 |
| Dimensions | 133.4 mm × 85.9 mm × 42 mm (5.25″ × 3.38″ × 1.65″) 89 |
| Weight | 0.16 kg (0.35 lbs) 210 |
| Operating Temperature | 0–60°C (32–140°F) |
| Certifications | UL, CSA, CCC 1318 |
| Redundancy | Media and hardware redundancy support 69 |
| Firmware Requirement | Series 90-70 PLC: v5.4+; RX3i: v2.90+ 6 |
Key Features and Advantages
Scalable Distributed Architecture: The GE IC200GBI001 supports up to 64 I/O modules across 8 racks, enabling flexible expansion for large-scale automation systems. Its 1,024 discrete I/O points and 128-byte analog memory accommodate complex sensor/actuator networks in applications like water treatment and power generation 616.
Rugged Industrial Design: With IP20 protection and surge immunity, the module withstands dust, vibration, and voltage transients common in chemical plants and offshore platforms. Its extended temperature range (0–60°C) ensures reliability in extreme environments 26.
Redundancy and Diagnostics: Dual Genius terminals and hardware redundancy options minimize downtime, while EDM provides real-time health monitoring for proactive maintenance. This is critical in industries like oil refining, where continuous operation is essential 69.
Protocol Flexibility: While natively supporting the Genius protocol, the GE IC200GBI001 can integrate with Modbus TCP/IP networks via optional gateways, facilitating interoperability with third-party devices 1216.
Efficient Configuration: Rotary dials simplify address and baud rate setup, while GE’s Proficy Machine Edition software enables remote diagnostics and firmware updates, reducing commissioning time by up to 40% 920.
Application Areas
Power Generation: Used in gas turbine control systems to interface with temperature/pressure sensors and actuators, ensuring precise turbine speed regulation and fault detection 616.
Water/Wastewater Treatment: Integrates with pumps, valves, and analyzers in distributed control systems, enabling real-time process optimization and compliance with environmental standards 1516.
Manufacturing: Supports assembly lines by connecting PLCs to vision systems, robotic arms, and conveyor belts. The GE IC200GBI001’s high I/O capacity is ideal for automotive plants requiring dense sensor integration 1416.
Oil & Gas: Deployed in offshore platforms to monitor wellhead pressure and control subsea equipment. Its redundancy features ensure uninterrupted operation in high-risk environments 616.
Packaging Machinery: Enables centralized control of labeling, filling, and sealing machines by interfacing with stepper motors and HMIs, improving production line efficiency 1416.
Related Products
- GE IC200ALG320: 8-channel analog input module for voltage/current signals, pairs with GE IC200GBI001 for process monitoring 69.
- GE IC200MDL640: 16-channel 24 VDC digital input module, supports discrete sensor integration in distributed I/O systems 69.
- GE IC693BEM331: BUS communication module for Series 90-70 PLCs, acts as the master node for GE IC200GBI001 in Genius networks 19.
- GE IC695PBM300: Profibus master module for hybrid network setups, complements GE IC200GBI001 in multi-protocol environments 20.
- GE IC200EBI001: Ethernet interface module enabling Modbus/TCP connectivity, extends GE IC200GBI001’s network capabilities 616.
- GE IC200PWR001: 24 VDC power supply module for VersaMax systems, ensures stable power delivery to GE IC200GBI001 69.
Installation and Maintenance
Installation Preparation:
Mount the GE IC200GBI001 on a grounded 35 mm DIN rail, leaving 2″ vertical clearance for heat dissipation. Use shielded twisted pair (STP) or fiber optic cables for Genius bus connections, and torque terminals to 0.8 N·m 69. Configure the module’s serial address (0–31) and baud rate via front-panel dials, matching the settings of the master controller (e.g., Series 90-70 PLC) 619.
Mount the GE IC200GBI001 on a grounded 35 mm DIN rail, leaving 2″ vertical clearance for heat dissipation. Use shielded twisted pair (STP) or fiber optic cables for Genius bus connections, and torque terminals to 0.8 N·m 69. Configure the module’s serial address (0–31) and baud rate via front-panel dials, matching the settings of the master controller (e.g., Series 90-70 PLC) 619.
Maintenance Advice:
Inspect terminals quarterly for corrosion and verify network activity via diagnostic LEDs. Clean dust from the enclosure using compressed air. GE recommends annual firmware updates to address security patches and compatibility improvements. In case of hardware failure, the hot-swappable design allows field replacement without rewiring 69.
Inspect terminals quarterly for corrosion and verify network activity via diagnostic LEDs. Clean dust from the enclosure using compressed air. GE recommends annual firmware updates to address security patches and compatibility improvements. In case of hardware failure, the hot-swappable design allows field replacement without rewiring 69.
Product Guarantee
GE provides a 12-month warranty for the GE IC200GBI001, covering defects in materials and workmanship. Global technical support is available 24/7 for installation guidance and troubleshooting. Premium service plans include priority repairs and onsite maintenance for mission-critical applications. The module complies with UL, CSA, and CCC standards, ensuring industrial-grade reliability 21318.
Brand Model: GE IC200GBI001
Product Name: Genius Network Interface Unit (VersaMax Series)
Warranty: 1 year
Size: 133.4 mm × 85.9 mm × 42 mm (5.25″ × 3.38″ × 1.65″)
Weight: 0.16 kg (0.35 lbs)
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
Product Name: Genius Network Interface Unit (VersaMax Series)
Warranty: 1 year
Size: 133.4 mm × 85.9 mm × 42 mm (5.25″ × 3.38″ × 1.65″)
Weight: 0.16 kg (0.35 lbs)
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
