Description

Product Overview
The GE IC200ETM001 is a high-speed expansion transmitter module designed for GE’s VersaMax series, enabling scalable I/O expansion in industrial automation systems. As a critical component of the VersaMax architecture, this module interfaces with Programmable Logic Controllers (PLCs) or Network Interface Units (NIUs) to extend system capabilities, supporting up to 7 additional expansion racks with 8 I/O modules per rack 16. Its 26-pin female D-shell connector facilitates daisy-chaining or single-ended configurations, making it ideal for distributed control systems in manufacturing, power generation, and process control industries .

Engineered with 5V backplane compatibility, the GE IC200ETM001 delivers 44 mA maximum current consumption and supports 250 kbps to 1 Mbps data transfer rates, optimizing performance based on cable length (15 meters for isolated modules; 750 meters for non-isolated modules) 58. The module features two status LEDs for real-time monitoring of power (5V DC from CPU/NIU) and expansion bus communication (EXP TX), ensuring rapid diagnostics in harsh environments 19. Its DIN rail-mountable design (37mm × 128mm) simplifies installation, while the 16-pin serial programming port enables firmware updates to adjacent NIUs 68.

Technical Specifications

Parameter Name	Parameter Value
Product Model	GE IC200ETM001
Manufacturer	GE (General Electric)
Product Type	Expansion Transmitter Module
Expansion Capacity	Up to 7 racks; 8 I/O modules per rack
Backplane Voltage	5V DC
Current Consumption	44 mA (max)
Data Transfer Rate	250 kbps (default, 15m cable) / 1 Mbps (adjustable, <250m cable) 8
Cable Length Limits	Isolated: ≤15 meters; Non-isolated: ≤750 meters
Communication Ports	1 × 26-pin female D-shell (expansion port); 1 × 16-pin male (serial programming)
LED Indicators	Power (PWR), Expansion Bus (EXP TX)
Enclosure Rating	IP20
Dimensions	37mm (W) × 128mm (H) × 139.7mm (D)
Weight	1.2 kg
Mounting	DIN rail (7.5mm × 35mm) or panel-mounted
Operating Temperature	-20°C to +60°C (ambient, inferred from VersaMax series standards)

Main Features and Advantages

Scalable I/O Architecture: The GE IC200ETM001 supports modular expansion, allowing users to add up to 56 I/O modules (7 racks × 8 modules) for high-density applications. This scalability reduces upfront costs by enabling phased system upgrades .

High-Speed Data Transfer: With adjustable data rates (250 kbps to 1 Mbps), the module ensures minimal latency in critical control processes, making it suitable for real-time applications like robotics and conveyor systems 8. Its non-isolated design (compatible with ERM002) offers cost-effective long-distance expansion (up to 750 meters) .

Reliable Performance: The self-diagnostic LEDs and conformal-coated circuitry simplify troubleshooting and resist vibration/temperature fluctuations. The non-volatile flash memory ensures program retention during power outages 19.

Flexible Configuration: The module adapts to both multi-rack (long-distance) and single-ended (short-distance) setups, with configurable expansion rack IDs (1–7) for precise system management 8. Its keyed D-shell connectors prevent mismatched installations .

User-Friendly Programming: The 16-pin serial port simplifies firmware updates to adjacent NIUs, while the EZ Program Store Device (IC200ACC003) supports quick program backups 69. The module seamlessly integrates with GE’s Proficy Machine Edition software .

Application Areas

Manufacturing: Deployed in assembly lines and packaging machinery, the GE IC200ETM001 expands I/O capacity for controlling motors, solenoids, and sensors. Its long-distance capability supports distributed control systems in large factories .

Power Generation: Used in power plants to interface PLCs with SCADA systems, the module monitors and controls generators, switchgear, and auxiliary equipment. Its high-speed data transfer ensures real-time response to grid fluctuations 1.

Water/Wastewater Treatment: In pump stations and treatment plants, the GE IC200ETM001 manages I/O signals from flow meters, level sensors, and actuators. Its non-isolated configuration suits compact control panels in remote locations 6.

Building Automation: Integrates with HVAC systems and security networks to expand I/O for temperature sensors, motion detectors, and access control devices. The module’s IP20 rating makes it suitable for indoor control rooms 9.

Installation and Maintenance

Installation Preparation:

Mount the GE IC200ETM001 on a grounded DIN rail using the provided hardware.
Connect the inbound expansion cable to the 26-pin female D-shell port and terminate the chain with a plug or daisy-chain the next rack 8.
Set the expansion rack ID (1–7) via the rotary switch under the access door 8.
Ensure proper grounding to minimize electromagnetic interference.

Maintenance Recommendations:

Monthly Checks: Verify LED status indicators for power and communication. Inspect cable connections for wear or corrosion.
Annual Inspections: Clean dust from the enclosure and test power supply voltage outputs. Replace the backup battery (if applicable) every 5 years 4.
Firmware Updates: Download the latest firmware from GE’s support portal to address compatibility issues and enhance functionality 9.

Product Guarantee

The GE IC200ETM001 is backed by a 12-month warranty against manufacturing defects, covering parts and labor. GE’s global technical support team provides 24/7 troubleshooting and remote diagnostics. In-stock units ship within 3 business days, while custom configurations require 2–4 weeks 69. The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
