Description
Product Overview
The GE IC200CPUE05 is a high-performance programmable logic controller (PLC) CPU module designed for industrial automation systems, part of GE’s VersaMax series. This compact controller integrates advanced processing capabilities with versatile communication options, making it ideal for applications requiring real-time control, data management, and seamless integration into modern automation architectures. With support for up to 64 I/O modules and 2,048 discrete I/O points, the GE IC200CPUE05 delivers scalable solutions for manufacturing, power generation, and process control industries .
The GE IC200CPUE05 is a high-performance programmable logic controller (PLC) CPU module designed for industrial automation systems, part of GE’s VersaMax series. This compact controller integrates advanced processing capabilities with versatile communication options, making it ideal for applications requiring real-time control, data management, and seamless integration into modern automation architectures. With support for up to 64 I/O modules and 2,048 discrete I/O points, the GE IC200CPUE05 delivers scalable solutions for manufacturing, power generation, and process control industries .
Featuring a 32-bit processor and 0.8 ms/k boolean execution speed, the GE IC200CPUE05 ensures rapid response to critical control tasks. Its 64 KB configurable memory supports ladder logic programming and stores application logic, hardware configurations, and diagnostic data. The module includes embedded RS-232, RS-485, and Ethernet ports, enabling direct connectivity to HMIs, SCADA systems, and cloud platforms via protocols like Modbus RTU, DNP3, and Ethernet Global Data (EGD) .
Engineered with non-volatile flash memory and battery-backed RAM, the GE IC200CPUE05 ensures program retention during power outages. Its NEMA 4X-rated enclosure (IP66 equivalent) protects against dust and moisture, while the DIN rail-mountable design (126mm × 128mm × 69.1mm) simplifies installation in crowded control panels. The module also supports IEEE-based mathematical models for advanced analytics, such as predictive maintenance and system health monitoring .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200CPUE05 |
| Manufacturer | GE (General Electric) |
| Product Type | Programmable Logic Controller (PLC) CPU Module |
| Processor | 32-bit microprocessor |
| Boolean Execution Speed | 0.8 ms/k (typical) |
| Memory | 64 KB configurable memory; system flash + battery-backed RAM |
| Communication Ports | – RS-232 (Port 1) – RS-485 (Port 2) – Ethernet (10 Mbps, RJ45) |
| Protocols Supported | Modbus RTU, DNP3, Ethernet Global Data (EGD), SNMP Slave, RTU Master/Slave |
| Power Supply | 24V DC (12–48V DC input range) |
| I/O Capacity | Up to 2,048 discrete I/O points via VersaMax I/O modules |
| Operating Temperature | -20°C to +60°C (ambient) |
| Enclosure Rating | IP20 (NEMA 4X optional) |
| Dimensions | 126mm (W) × 128mm (H) × 69.1mm (D) |
| Weight | 0.55 kg |
| Mounting | DIN rail (7.5mm × 35mm) or panel-mounted |
Main Features and Advantages
High-Speed Processing: The GE IC200CPUE05’s 32-bit processor and 0.8 ms/k boolean execution speed enable real-time control of complex processes, reducing latency in applications like robotics and conveyor systems . Its floating-point math capabilities support advanced calculations for analog signal processing and predictive analytics.
Flexible Communication: With embedded Ethernet, RS-232, and RS-485 ports, the module integrates seamlessly with legacy and modern systems. The Ethernet Global Data (EGD) feature allows up to 32 data exchanges with other devices, facilitating synchronized data sharing across the network .
Scalable Architecture: Supporting 64 I/O modules, the GE IC200CPUE05 adapts to small-scale machinery and large industrial plants. Its modular design allows incremental expansion, minimizing upfront costs while accommodating future system upgrades .
Reliable Operation: The non-volatile flash memory and battery-backed RAM ensure program retention for up to 6 months without power. The self-diagnostic LED indicators and overvoltage protection (300V AC transient) enhance system stability in harsh environments .
User-Friendly Programming: The module supports ladder logic and instruction list programming, compatible with GE’s Proficy Machine Edition software. The EZ Program Store Device (IC200ACC003) simplifies firmware updates and program backups .
Application Areas
Manufacturing: Deployed in assembly lines and packaging machinery, the GE IC200CPUE05 controls motors, sensors, and actuators for precise automation. Its Ethernet connectivity enables remote monitoring and diagnostics, reducing downtime .
Power Generation: Used in power plants and substations, the module interfaces with SCADA systems to manage generator control, switchgear monitoring, and energy distribution. Its Modbus RTU compatibility ensures compliance with industry standards .
Water/Wastewater Treatment: In pump stations and treatment facilities, the GE IC200CPUE05 regulates flow meters, valves, and disinfection systems. Its analog input/output support optimizes process efficiency and environmental compliance .
Building Automation: Integrates with HVAC systems and security networks to manage temperature, lighting, and access control. The SNMP Slave protocol allows centralized management via building management systems (BMS) .
Related Products
Installation and Maintenance
Installation Preparation:
Mount the GE IC200CPUE05 on a grounded DIN rail using the provided hardware. Connect 24V DC power and shielded Ethernet/serial cables per the wiring diagram. Ensure proper grounding to minimize electromagnetic interference. The module’s keying controls prevent incorrect module insertion, while the translucent cover protects terminals from physical damage .
Mount the GE IC200CPUE05 on a grounded DIN rail using the provided hardware. Connect 24V DC power and shielded Ethernet/serial cables per the wiring diagram. Ensure proper grounding to minimize electromagnetic interference. The module’s keying controls prevent incorrect module insertion, while the translucent cover protects terminals from physical damage .
Maintenance Recommendations:
- Monthly Checks: Verify LED status indicators for power, communication, and diagnostics. Compare runtime data against baseline performance metrics.
- Annual Calibration: Perform factory-recommended firmware updates to access new features and bug fixes. Replace the backup battery every 5 years to maintain memory retention .
- Environmental Inspections: Clean dust from the enclosure and inspect for signs of corrosion or physical damage, especially in high-humidity or corrosive environments .
Product Guarantee
The GE IC200CPUE05 is backed by a 12-month warranty against manufacturing defects, covering parts and labor. GE’s global technical support team provides 24/7 troubleshooting and remote diagnostics. In-stock units ship within 3 business days, while custom configurations require 4–6 weeks . The product meets international standards (CE, UL, CSA) and is manufactured in the United States, ensuring reliability and compliance with industrial requirements.
