Description
Product Overview
The GE IC200ALG260 is an 8-channel analog input module designed for industrial automation systems, part of GE Fanuc’s VersaMax series. Engineered to convert real-world analog signals into digital data for PLC or DCS processing, this module supports voltage (-10 to +10 V DC, 0–10 V DC) and current (4–20 mA) inputs with 12-bit resolution, balancing accuracy and cost-effectiveness for basic to moderate precision applications . Its channel-to-channel isolation (250V AC continuous) and robust diagnostics ensure reliable performance in high-noise environments, while hot-swappable capabilities enable maintenance without system downtime .
The GE IC200ALG260 is an 8-channel analog input module designed for industrial automation systems, part of GE Fanuc’s VersaMax series. Engineered to convert real-world analog signals into digital data for PLC or DCS processing, this module supports voltage (-10 to +10 V DC, 0–10 V DC) and current (4–20 mA) inputs with 12-bit resolution, balancing accuracy and cost-effectiveness for basic to moderate precision applications . Its channel-to-channel isolation (250V AC continuous) and robust diagnostics ensure reliable performance in high-noise environments, while hot-swappable capabilities enable maintenance without system downtime .
The GE IC200ALG260 features built-in LED indicators for power status (INT PWR) and backplane connectivity (OK), simplifying troubleshooting. It operates on 5V/3.3V power from the backplane, eliminating the need for external power supplies, and includes advanced fault detection for open wires, over/under-range conditions, and memory errors . With a compact form factor (110 mm × 66.8 mm × 50 mm) and vibration-resistant design, it is suitable for harsh industrial settings, including chemical plants, power generation facilities, and manufacturing lines .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200ALG260 |
| Manufacturer | General Electric (GE) |
| Product Type | 8-Channel 12-Bit Analog Input Module |
| Input Channels | 8 isolated, single-ended channels |
| Input Resolution | 12-bit |
| Voltage Range | -10V to +10V DC (bipolar), 0–10V DC (unipolar) |
| Current Range | 4–20 mA |
| Isolation | 250V AC continuous (channel-to-channel) |
| Diagnostics | Open wire, over/under-range, power loss |
| Power Supply | 5V/3.3V from backplane |
| Backplane Current | 130 mA (5V) |
| Update Rate | 0.4 ms (per module) |
| Input Filter | 5 ms response time |
| Operating Temperature | 0–60°C |
| Dimensions | 110 mm × 66.8 mm × 50 mm (4.3″ × 2.63″ × 1.96″) |
| Weight | 0.55 kg (1.21 lbs) |
| Mounting | Directly installed on VersaMax carrier |
Key Features and Advantages
Cost-Effective Precision: The GE IC200ALG260 delivers 12-bit resolution, making it ideal for applications where high accuracy is required but 16-bit modules (e.g., GE IC200ALG240) may be overspecified. Its dual-mode voltage/current input reduces the need for external signal converters, lowering system complexity .
Cost-Effective Precision: The GE IC200ALG260 delivers 12-bit resolution, making it ideal for applications where high accuracy is required but 16-bit modules (e.g., GE IC200ALG240) may be overspecified. Its dual-mode voltage/current input reduces the need for external signal converters, lowering system complexity .
Rugged Industrial Design: With 250V AC isolation and protection against transient voltage spikes, the module maintains stability in EMI-prone environments. The IP20-rated enclosure and extended temperature range (0–60°C) ensure reliable operation in harsh conditions, including offshore platforms and chemical processing plants .
Intelligent Diagnostics: Real-time fault monitoring via LED indicators and digital alerts helps identify sensor or wiring issues promptly, minimizing downtime. The module’s diagnostic capabilities include detection of open wires, power loss, and memory errors, supporting proactive maintenance strategies .
Flexible Integration: Compatible with GE’s VersaMax PLC platform, the GE IC200ALG260 integrates seamlessly with network interface modules (e.g., IC200EBI001 for Modbus/TCP) to connect with SCADA systems or cloud-based analytics. Its hot-swappable design allows module replacement without disrupting system operations .
Application Areas
- Manufacturing: Used to monitor temperature in injection molding machines, pressure in hydraulic systems, or flow rates in packaging lines. The GE IC200ALG260 ensures precise control over production parameters, optimizing efficiency and reducing waste .
- Oil & Gas: Deployed in refineries to measure pressure differentials in pipelines or monitor liquid levels in storage tanks. Its rugged construction and EMI resistance make it suitable for corrosive offshore environments .
- Power Generation: Integrates with turbine control systems to monitor vibration and fuel flow, supporting predictive maintenance and maximizing energy output. The module’s isolation features protect against voltage transients in power grids .
- Water/Wastewater: Used in treatment plants to measure pH levels, dissolved oxygen, and flow rates, enabling compliance with environmental standards and efficient resource management .
Related Products
Installation and Maintenance
Installation Preparation:
Mount the GE IC200ALG260 on a VersaMax carrier using DIN rail clips. Configure input modes (voltage/current) via dip switches or software, ensuring compatibility with sensor signal ranges. Use shielded cables and proper grounding to minimize EMI interference. For current inputs, connect a 24V power supply to terminals A17/A18 for optimal accuracy .
Installation Preparation:
Mount the GE IC200ALG260 on a VersaMax carrier using DIN rail clips. Configure input modes (voltage/current) via dip switches or software, ensuring compatibility with sensor signal ranges. Use shielded cables and proper grounding to minimize EMI interference. For current inputs, connect a 24V power supply to terminals A17/A18 for optimal accuracy .
Maintenance Advice:
Regularly inspect LED indicators for fault conditions (e.g., red “FAULT” light). Clean dust from the enclosure quarterly to maintain thermal performance. Calibrate the module annually using GE-certified equipment. Replace the module if physical damage or persistent signal drift is detected. The sensor’s modular design allows for field replacement without system downtime .
Regularly inspect LED indicators for fault conditions (e.g., red “FAULT” light). Clean dust from the enclosure quarterly to maintain thermal performance. Calibrate the module annually using GE-certified equipment. Replace the module if physical damage or persistent signal drift is detected. The sensor’s modular design allows for field replacement without system downtime .
Product Guarantee
GE offers a 12-month warranty for the GE IC200ALG260, covering defects in materials and workmanship. Global technical support is available 24/7 for installation guidance and troubleshooting. Premium service plans include priority repairs and onsite maintenance for mission-critical applications. The module undergoes rigorous testing to meet IEC 61000 and UL standards, ensuring industrial-grade reliability .
GE offers a 12-month warranty for the GE IC200ALG260, covering defects in materials and workmanship. Global technical support is available 24/7 for installation guidance and troubleshooting. Premium service plans include priority repairs and onsite maintenance for mission-critical applications. The module undergoes rigorous testing to meet IEC 61000 and UL standards, ensuring industrial-grade reliability .
Brand model: GE IC200ALG260
Product Name: 8-Channel 12-Bit Analog Input Module (VersaMax Series)
Warranty: 1 year
Size: 110 mm × 66.8 mm × 50 mm (4.3″ × 2.63″ × 1.96″)
Weight: 0.55 kg (1.21 lbs)
Origin: USA
Inventory: Available (spot/futures)
Delivery time: Dispatched within 3–5 business days for in-stock items
Order time: Dispatched within 1 month for pre-orders
Product Name: 8-Channel 12-Bit Analog Input Module (VersaMax Series)
Warranty: 1 year
Size: 110 mm × 66.8 mm × 50 mm (4.3″ × 2.63″ × 1.96″)
Weight: 0.55 kg (1.21 lbs)
Origin: USA
Inventory: Available (spot/futures)
Delivery time: Dispatched within 3–5 business days for in-stock items
Order time: Dispatched within 1 month for pre-orders
