Product Overview
The GE HYDRAN M2 is a compact, high-precision dissolved gas-in-oil analyzer (DGA) designed for continuous monitoring of power transformers. Engineered to detect dissolved gases (hydrogen, carbon monoxide, acetylene, ethylene) and moisture in transformer oil, the GE HYDRAN M2 provides real-time health diagnostics to identify early signs of thermal or electrical faults, such as partial discharge or overheating 27. As part of GE’s HYDRAN® series, this device combines patented fuel cell technology with advanced analytics to support predictive maintenance strategies, minimizing unplanned outages in critical power generation, oil & gas, and industrial applications.
The GE HYDRAN M2 is a compact, high-precision dissolved gas-in-oil analyzer (DGA) designed for continuous monitoring of power transformers. Engineered to detect dissolved gases (hydrogen, carbon monoxide, acetylene, ethylene) and moisture in transformer oil, the GE HYDRAN M2 provides real-time health diagnostics to identify early signs of thermal or electrical faults, such as partial discharge or overheating 27. As part of GE’s HYDRAN® series, this device combines patented fuel cell technology with advanced analytics to support predictive maintenance strategies, minimizing unplanned outages in critical power generation, oil & gas, and industrial applications.
The GE HYDRAN M2 features a rugged IP66-rated enclosure and operates across a wide temperature range (-40°C to +85°C), ensuring reliable performance in harsh outdoor environments, including offshore installations 15. It supports Modbus RTU/RS-485 and optional Ethernet communication, enabling seamless integration with SCADA systems, GE’s Proficy software, and Perception™ fleet management platforms for remote data visualization and trend analysis 710. The device’s composite gas sensor—100% responsive to hydrogen and sensitive to carbon monoxide, acetylene, and ethylene—aligns with IEEE C57.104 standards for transformer health assessment 28. With built-in transformer mathematical models (e.g., winding hot-spot temperature, insulation aging), the GE HYDRAN M2 converts raw sensor data into actionable insights for asset managers 812.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE HYDRAN M2 |
| Manufacturer | General Electric (GE) |
| Product Type | Dissolved Gas-in-Oil Transmitter |
| Power Supply | 110–240V AC (50/60 Hz) |
| Communication | RS-485 Modbus RTU, Optional Ethernet |
| Measurement Range | 0–2000 ppm (hydrogen equivalent) |
| Accuracy | ±10% of reading ±25 ppm (hydrogen) |
| Alarm Outputs | 2 relay contacts (high gas, system fault) |
| Data Logging | Stores 1 year of gas trends/events |
| Operating Temperature | -40°C to +85°C |
| Enclosure Rating | IP66 (weatherproof) |
| Dimensions | 150mm × 240mm × 350mm (5.91in × 9.45in × 13.78in) |
| Weight | 5.6kg (12.35lbs) |
| Mounting | Directly installed on transformer oil valve |
| Certifications | CE, UL, CSA |
Key Features and Advantages
Continuous Fault Detection: The GE HYDRAN M2 offers 24/7 monitoring of dissolved gases and moisture, detecting early-stage insulation degradation. Its “Hydran Gas Value” technology aggregates gas readings into a single metric, simplifying fault diagnosis and compliance with IEEE standards 28. The sensor’s modular design eliminates moving parts, reducing maintenance costs and extending service life to over 10 years 812.
Continuous Fault Detection: The GE HYDRAN M2 offers 24/7 monitoring of dissolved gases and moisture, detecting early-stage insulation degradation. Its “Hydran Gas Value” technology aggregates gas readings into a single metric, simplifying fault diagnosis and compliance with IEEE standards 28. The sensor’s modular design eliminates moving parts, reducing maintenance costs and extending service life to over 10 years 812.
Rugged Industrial Design: With an IP66-rated enclosure and vibration-resistant construction, the GE HYDRAN M2 withstands extreme temperatures, saltwater corrosion, and high electromagnetic interference. Its compact form factor (150mm × 240mm × 350mm) optimizes space in transformer yards, while the direct valve-mounting design eliminates the need for external pumps or piping 113.
Flexible Integration: Compatible with GE’s HYDRAN 201i controllers and Perception™ software, the GE HYDRAN M2 supports networked monitoring of up to 32 units via RS-485, ideal for large transformer fleets. Optional analog inputs for oil temperature, load, and ambient conditions enable correlation of DGA data with operational parameters for holistic asset analysis 712.
Advanced Data Management: Built-in memory logs gas concentrations, trends, and alarms for historical analysis. Remote access via PC software allows real-time data visualization, firmware updates, and configurable alarm thresholds (alert/alarm levels) to adapt to specific equipment requirements 710.
Application Areas
- Power Generation: Critical for monitoring power transformers in thermal, nuclear, and renewable energy plants, the GE HYDRAN M2 prevents catastrophic failures by detecting insulation degradation. It supports predictive maintenance strategies to optimize grid reliability 28.
- Oil & Gas: Deployed in subsea and onshore transformer systems, the device detects gas leaks or degradation, ensuring stable operation in harsh offshore environments. Its IP66 rating protects against saltwater corrosion and extreme temperatures 15.
- Industrial Manufacturing: Used in chemical, pharmaceutical, and food processing facilities, the GE HYDRAN M2 monitors critical transformers to maintain production continuity. Configurable alarm thresholds adapt to varying equipment requirements 710.
- Smart Grid: Enables utilities to implement condition-based maintenance, reducing unplanned outages and extending transformer lifespans. Data feeds into AI-driven analytics for proactive asset management 812.
