Description
GE HE700GEN200 is a VME form-factor communication module designed to connect VME-based controllers to the GE Genius industrial fieldbus network. It acts as a Genius bus master, supporting two separate Genius bus segments to expand distributed I/O capacity. The module enables cyclic process data transmission and fault diagnostics between the VME host system and remote Genius I/O blocks. It is widely deployed as replacement spare hardware for legacy power, oil & gas and process control systems.
Series
The uGENI series includes HE700GEN100 (single-channel) and HE700GEN200 (dual-channel) Genius VME interface modules, developed by Horner APG for GE Fanuc automation platforms. These modules integrate into standard VME racks to implement Genius bus networking without dedicated Genius Bus Controller (GBC) hardware.
Product Features
- Dual independent Genius communication channels for separate fieldbus segments, supporting network segmentation and improved communication reliability.
- Standard VME64x backplane interface for installation inside Series 90-70 VME racks.
- On-board DIP switches for address configuration, bus timing and operational mode setup.
- Front panel screw-type terminal connectors for Genius bus wiring, supporting daisy-chain field topology.
- LED status indicators for module power, bus activity and channel fault diagnosis.
- Low power consumption design, powered entirely from VME backplane 5 VDC supply.
- Rugged industrial PCB assembly suitable for cabinet-mounted control environments.
- End-of-life legacy hardware; not available for new project engineering.
Product Parameters
| Item | Details |
|---|---|
| Part Number | HE700GEN200 |
| Brand | GE Fanuc / Horner APG |
| Series | uGENI VME Interface |
| Module Type | Dual-channel Genius Bus Master |
| Backplane Interface | VME64x |
| Communication Protocol | GE Genius Fieldbus |
| Power Supply | 5 VDC via VME backplane |
| Current Draw | Approx. 200 mA |
| Configuration | On-board DIP switches |
| Field Connection | Screw terminal blocks |
| Operating Temperature | -20℃ ~ +60℃ |
| Storage Temperature | -40℃ ~ +85℃ |
| Humidity | 5–95% RH, non-condensing |
| Discontinued Status | Obsolete, spare-part only |
Product Specifications
- Installation: Standard VME single-height slot mount
- Certification: CE compliant
- Remark: Requires matching Genius bus wiring rules; not recommended for new system design.
Function
- Operate as Genius bus master to exchange cyclic input/output data with remote Genius I/O modules.
- Support two isolated Genius network segments to separate control zones and reduce bus load.
- Transmit real-time process data between VME CPU and distributed field I/O devices.
- Detect bus communication errors, short circuits and offline nodes and forward diagnostic alarms to the host controller.
- Maintain reliable deterministic communication for continuous industrial automation control tasks.
Purpose
VME interface gateway for GE Genius distributed I/O networks, used to expand remote I/O capability of legacy Series 90-70 VME control racks in process and power plant automation.
Application Fields
- Power generation plant legacy control system maintenance
- Oil & gas onshore production automation retrofit
- Petrochemical process control spare-part replacement
- Water treatment industrial control system repair
- Existing GE Fanuc Series 90-70 VME platform site equipment maintenance
