Description
Product Overview
The GE G6M-9UH-00K UR9GH is a high-performance industrial computing module engineered by General Electric, designed to serve as the core processing unit in advanced automation systems. As part of GE’s cutting-edge G6M series, this module combines robust hardware with flexible software capabilities to deliver real-time control, data analytics, and seamless communication in industrial environments. The GE G6M-9UH-00K UR9GH is built to handle complex computational tasks, such as machine learning-based predictive maintenance, high-speed data acquisition, and multi-axis motion control, making it ideal for smart factories, energy plants, and critical infrastructure applications.
Featuring a powerful multi-core processor and industrial-grade memory, the GE G6M-9UH-00K UR9GH ensures rapid execution of control algorithms and real-time data processing, minimizing latency in mission-critical operations. Its modular design supports seamless integration with GE’s Proficy software suite and third-party SCADA systems, enabling end-to-end visibility and remote management. With built-in cybersecurity features and rugged construction, the module withstands harsh conditions like vibration, temperature fluctuations, and electromagnetic interference, ensuring reliable performance in even the most demanding industrial settings.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE G6M-9UH-00K UR9GH |
| Manufacturer | General Electric (GE) |
| Product Type | Industrial Computing Module |
| Processor | 8th Gen Intel Core i7-8665UE (4-core, 8-thread, 1.7GHz up to 4.4GHz) |
| Memory | 16GB DDR4 (expandable up to 32GB) |
| Storage | 512GB NVMe SSD (optional 1TB storage) |
| Communication Interfaces | 2x Gigabit Ethernet (支持 Profinet, EtherNet/IP), 2x RS-485/RS-232, 1x USB 3.2, 1x HDMI 2.0 |
| Operating System | Windows 10 IoT Enterprise / Linux Industrial |
| Operating Temperature | -40°C to +55°C (with active cooling) |
| Storage Temperature | -55°C to +85°C |
| Dimensions (W×H×D) | 200mm × 150mm × 80mm (7.87in × 5.91in × 3.15in) |
| Weight | 2.2kg (4.85lbs) |
| Power Supply | 24V DC (18–36V DC input range) |
| Certifications | CE, UL, IEC 61000-6-2/6-3 (EMC compliance) |
| Expansion Slots | 1x PCIe x4, 1x Mini PCIe (for wireless modules) |
Main Features and Advantages
Unmatched Processing Power: The GE G6M-9UH-00K UR9GH leverages the 8th Gen Intel Core i7 processor to handle complex workloads, including real-time data analytics, AI-driven diagnostics, and high-precision motion control. This ensures smooth execution of multi-tasking applications, such as running HMI interfaces alongside predictive maintenance algorithms without performance degradation.
Rugged Industrial Design: Built to industrial-grade standards, the module features a fanless, passive-cooling design that eliminates moving parts, reducing maintenance needs and improving reliability in dusty or high-vibration environments. The aluminum alloy casing provides excellent heat dissipation, while conformal coating protects against moisture and chemical corrosion, making it suitable for oil & gas, mining, and outdoor installations.
Flexible Connectivity: With dual Gigabit Ethernet ports and support for leading industrial protocols (Profinet, EtherNet/IP, Modbus TCP), the GE G6M-9UH-00K UR9GH seamlessly integrates with PLCs, robots, and IoT sensors, enabling data fusion from disparate systems. The expandable storage and memory options allow users to scale resources based on application requirements, future-proofing their automation investments.
Enhanced Cybersecurity: The module includes hardware-based security features like TPM 2.0 and secure boot, protecting against unauthorized access and firmware tampering. This is critical for industries like power generation and pharmaceuticals, where data integrity and system availability are non-negotiable.
Application Areas
The GE G6M-9UH-00K UR9GH excels in industrial environments that demand high computational power and reliability:
- Smart Manufacturing: As the brain of a smart factory, it coordinates robotic arms, monitors CNC machines in real time, and analyzes production data to optimize throughput. For example, it can predict tool wear using machine learning models and trigger maintenance alerts before failures occur.
- Energy & Utilities: In power plants and substations, the module manages SCADA systems, controls grid-tied inverters in renewable energy farms, and monitors equipment health in real time. Its ability to withstand extreme temperatures makes it ideal for outdoor wind turbine control cabinets.
- Process Automation: In chemical and pharmaceutical plants, the GE G6M-9UH-00K UR9GH runs advanced process control algorithms, ensuring precise regulation of temperature, pressure, and flow rates. It also supports batch processing systems, where traceability and repeatability are critical.
- Transportation & Logistics: Used in port cranes and automated warehouses, the module enables high-speed motion control and real-time location tracking of goods, enhancing supply chain efficiency.
Related Products
- GE G6M-7UH-00K UR7GH: A cost-optimized variant with an Intel Core i5 processor and 8GB memory, suitable for mid-complexity applications.
- GE G6M-12UH-00K UR12GH: A high-end model with 32GB memory and 2TB storage, designed for data-intensive AI/ML workloads.
- GE IC693CPU364: A compact PLC processor that pairs with the G6M-9UH-00K UR9GH for hybrid control systems, combining real-time PLC logic with advanced computing.
- GE Proficy Machine Edition: Software suite for programming and monitoring the module, offering HMI development, data logging, and remote diagnostics.
- GE DS3800HFPB1F1E: A compatible I/O module for expanding analog/digital inputs/outputs in complex automation setups.
- GE AF1000 Variable Frequency Drive: Integrates with the module to optimize motor energy efficiency, controlled via Ethernet for real-time speed adjustments.
Installation and Maintenance
Installation Preparation:
Before installing the GE G6M-9UH-00K UR9GH, ensure the control cabinet is grounded and ventilated to maintain optimal operating temperature. Use the provided DIN rail brackets or panel-mounting kit to secure the module, leaving at least 50mm of clearance for airflow. Connect power using shielded cables to prevent EMI interference, and terminate communication lines according to the wiring diagram in the user manual. Verify that the input voltage (24V DC) matches the module’s specifications and that all connections are secure.
Before installing the GE G6M-9UH-00K UR9GH, ensure the control cabinet is grounded and ventilated to maintain optimal operating temperature. Use the provided DIN rail brackets or panel-mounting kit to secure the module, leaving at least 50mm of clearance for airflow. Connect power using shielded cables to prevent EMI interference, and terminate communication lines according to the wiring diagram in the user manual. Verify that the input voltage (24V DC) matches the module’s specifications and that all connections are secure.
Maintenance Advice:
Regularly monitor the module’s health via GE’s Proficy software, checking for temperature spikes, memory usage, or network latency. Clean the exterior with a dry, anti-static cloth to remove dust, especially around ventilation slots. Perform firmware updates quarterly using the dedicated utility tool to access the latest security patches and performance optimizations. In redundant systems, test failover functionality annually to ensure seamless switchover in case of hardware issues. If replacing the module, back up configuration files beforehand to minimize downtime during commissioning.
Regularly monitor the module’s health via GE’s Proficy software, checking for temperature spikes, memory usage, or network latency. Clean the exterior with a dry, anti-static cloth to remove dust, especially around ventilation slots. Perform firmware updates quarterly using the dedicated utility tool to access the latest security patches and performance optimizations. In redundant systems, test failover functionality annually to ensure seamless switchover in case of hardware issues. If replacing the module, back up configuration files beforehand to minimize downtime during commissioning.
Product Guarantee
GE stands behind the GE G6M-9UH-00K UR9GH with a 1-year comprehensive warranty, covering all manufacturing defects and operational failures. Our global technical support team provides 24/7 assistance for configuration, troubleshooting, and firmware updates, ensuring minimal disruption to your operations. For mission-critical applications, GE offers premium service plans with onsite maintenance and expedited replacement, guaranteeing uptime for your most demanding systems. Every module undergoes rigorous testing to meet IEC 61000 and NEMA 4X standards, reflecting our commitment to delivering industrial-grade reliability and performance.
Brand model: GE G6M-9UH-00K UR9GH
Product Name: Industrial Computing Module (G6M Series)
Warranty: 1 year
Size: 200mm × 150mm × 80mm (7.87in × 5.91in × 3.15in)
Weight: 2.2kg (4.85lbs)
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after pay
Product Name: Industrial Computing Module (G6M Series)
Warranty: 1 year
Size: 200mm × 150mm × 80mm (7.87in × 5.91in × 3.15in)
Weight: 2.2kg (4.85lbs)
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after pay
