Product Overview
The GE DS200TCPDGIBEC is a Power Distribution Board (PDB) designed for GE’s Mark V Speedtronic Turbine Control System, a legacy platform widely used in gas and steam turbine automation. This board plays a critical role in distributing power to various components within the Mark V architecture, ensuring stable operation of mission-critical industrial systems. It accepts a 125 V DC input and generates multiple regulated DC output voltages (e.g., 24 V DC, ±15 V DC, 5 V DC) to support processors, memory modules, and I/O devices 12.
The GE DS200TCPDGIBEC is a Power Distribution Board (PDB) designed for GE’s Mark V Speedtronic Turbine Control System, a legacy platform widely used in gas and steam turbine automation. This board plays a critical role in distributing power to various components within the Mark V architecture, ensuring stable operation of mission-critical industrial systems. It accepts a 125 V DC input and generates multiple regulated DC output voltages (e.g., 24 V DC, ±15 V DC, 5 V DC) to support processors, memory modules, and I/O devices 12.
Engineered for rugged industrial environments, the DS200TCPDGIBEC features advanced thermal management and overload protection mechanisms to minimize downtime and extend system lifespan. Its modular design allows seamless integration into Mark V cabinets, ensuring compatibility with terminal boards (e.g., TB QA, TB QC) and other modules like the DS200TCQAG1A analog I/O board 1. With diagnostic LED indicators and hot-swap capability, this board supports real-time status monitoring and maintenance without system shutdown, making it ideal for power generation, oil and gas, and heavy industry applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | DS200TCPDGIBEC |
| Manufacturer | General Electric (GE) |
| Product Type | Power Distribution Board |
| Series | Mark V Speedtronic |
| Input Voltage | 125 V DC (100–150 V DC) |
| Output Voltages | 24 V DC, ±15 V DC, 5 V DC |
| Power Rating | 50 W |
| Efficiency | ≥90% |
| Connectors | J1 (input), 2PL, JC, JP1, JP2 |
| Operating Temperature | -25°C to +60°C |
| Physical Dimensions | 330 mm (H) x 178 mm (W) x 100 mm (D) |
| Weight | 1.2 kg |
| Mounting | DIN rail (35 mm) |
| Protection | Overvoltage, overcurrent, short-circuit |
| Diagnostics | LED indicators for power status |
Main Features and Advantages
- Precision Power Management: Delivers stable DC voltages to support critical turbine control functions, including servo valve actuation and thermocouple signal conditioning 1.
- Multi-Output Design: Ensures compatibility with a wide range of Mark V modules, such as control processors (e.g., DS200TCPAG1AJD) and digital I/O boards (e.g., DS200TCDAG1B) 1.
- Rugged Reliability: Incorporates fuse protection and heat sinks to prevent damage from overloads or thermal stress. Its PCB coating provides immunity to electromagnetic interference (EMI) and environmental contaminants 1.
- Easy Integration: Features plug-and-play connectors and no software configuration requirements, reducing installation complexity. Hot-swap capability enables maintenance without system shutdown 1.
- Legacy Compatibility: Works seamlessly with GE’s Speedtronic Mark V programming tools, offering a cost-effective solution for retrofitting or expanding automation infrastructure 1.
Application Areas
- Power Generation: Supports turbine synchronization with the grid and monitors parameters like fuel pressure and exhaust temperature.
- Oil and Gas: Ensures reliable power for compressor control systems and distributed control architectures.
- Heavy Industry: Supplies power to motor drives and process control modules in machinery requiring high precision.
Related Products
- GE DS200TCPDG1BEC: A base power distribution board without the IBEC revision, suitable for standard Mark V applications 2.
- GE DS200TCPSGIACB: A DC input power supply board with similar voltage outputs and thermal management 1.
- GE DS200TCQAG1A: An analog I/O board that interfaces with the DS200TCPDGIBEC to condition turbine sensor signals 1.
- GE TU854 (3BSE069966R1): A termination unit that simplifies field wiring connections for power distribution 1.
Installation and Maintenance
- Installation: Secure the board on a 35 mm DIN rail, connect the 125 V DC input via the J1 connector, and route output cables to respective modules. Use shielded cables to minimize EMI 1.
- Maintenance: Regularly inspect for loose connections, clean dust from the PCB, and test input/output voltages. Replace fuses immediately if blown and ensure firmware updates are applied 1.
Product Warranty
GE guarantees the DS200TCPDGIBEC against defects in materials and workmanship for 1 year from the date of purchase. This warranty covers repair or replacement, provided the board is used in accordance with GE’s specifications 2.
GE guarantees the DS200TCPDGIBEC against defects in materials and workmanship for 1 year from the date of purchase. This warranty covers repair or replacement, provided the board is used in accordance with GE’s specifications 2.
