Description
Product Overview
The GE 469-P1-HI-A20-E-H is a high-performance Motor Management Relay engineered by GE Multilin to deliver advanced protection, monitoring, and control for medium to large industrial motors. As a cornerstone of the 469 series, this relay combines precision diagnostics, rugged durability, and flexible communication capabilities to ensure optimal motor performance in demanding environments. The GE 469-P1-HI-A20-E-H is specifically designed for high-voltage control power applications (90–300 VDC/70–265 VAC) and features a 1 A phase CT secondary input (denoted by “P1”), making it ideal for industries where accurate current measurement and motor health assessment are critical. Its enhanced LED display, conformal coating for harsh environments, and modular draw-out design position it as a reliable solution for sectors such as oil & gas, power generation, and manufacturing.
The relay’s advanced thermal model integrates RTD biasing and negative sequence current feedback to prevent overheating and predict stator winding faults. With 9 optically isolated digital inputs and 4 analog outputs (0–1 mA), it enables seamless integration with SCADA systems and PLCs, while Modbus RTU communication ensures real-time data exchange. The GE 469-P1-HI-A20-E-H also supports broken rotor bar detection through motor current signature analysis (MCSA), reducing downtime by identifying mechanical issues before they escalate. By combining comprehensive protection, intuitive diagnostics, and user-friendly configuration, this relay empowers industries to enhance motor reliability and operational efficiency.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE 469-P1-HI-A20-E-H |
| Manufacturer | GE Multilin |
| Product Type | Motor Management Relay |
| Control Power Range | 90–300 VDC / 70–265 VAC (48–62 Hz) |
| Phase Current Inputs | 1 A CT secondary (P1 designation) |
| Analog Outputs | 4 channels (0–1 mA, fully isolated) |
| Digital Inputs | 9 optically isolated inputs |
| Display | Enhanced 40-character LCD |
| Communication Protocols | Modbus RTU (RS232/RS485), optional Ethernet/DeviceNet |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Conformal Coating | Yes (for chemical/humid environments) |
| Dimensions | 263 mm × 58 mm × 28 mm |
| Weight | 4.3 kg |
| IP Rating | IP40 (front), IP20 (rear) |
| Pollution Degree | 2 |
Main Features and Advantages
Precision Motor Protection
The GE 469-P1-HI-A20-E-H offers voltage-dependent overload curves that adjust dynamically based on motor acceleration and system voltage, critical for high-inertia applications. Its dual overload curves support two-speed motors, while stator differential protection and underfrequency monitoring guard against abnormal operating conditions. The relay’s thermal memory retains real-time thermal capacity data, ensuring accurate protection even after power interruptions.
Advanced Diagnostics
Equipped with motor current signature analysis (MCSA), the relay detects early signs of broken rotor bars or bearing degradation, enabling predictive maintenance. The oscillography feature records up to 128 cycles of waveform data during faults, simplifying root-cause analysis. With 12 RTD inputs (optional), it monitors stator temperature directly, enhancing thermal protection accuracy.
Rugged Design
The conformal coating safeguards internal components from dust, moisture, and chemical corrosion, making it suitable for hazardous environments. The draw-out case design allows quick module replacement without rewiring, minimizing downtime. The relay’s -40°C to +60°C operating range ensures reliable performance in extreme temperatures.
Seamless Integration
Featuring Modbus RTU and optional Ethernet/DeviceNet connectivity, the GE 469-P1-HI-A20-E-H integrates effortlessly with existing automation systems. The Enervista™ software provides remote configuration, data logging, and waveform analysis, streamlining commissioning and ongoing management.
Application Areas
Industrial Machinery
The GE 469-P1-HI-A20-E-H excels in protecting motors for pumps, compressors, and conveyors in manufacturing plants. Its start supervision function ensures safe motor acceleration, while mechanical jam detection prevents damage from blocked equipment.
Power Generation
In power plants, this relay monitors turbine-driven pumps and fans, providing voltage-compensated acceleration to maintain stable operations. Its undervoltage protection prevents motor damage during grid fluctuations.
Oil & Gas
For pipeline compressors and offshore platforms, the relay’s corrosive environment resistance and high-voltage compatibility ensure reliable performance. The phase unbalance protection mitigates risks from uneven loading in critical processes.
Water/Wastewater
In wastewater treatment facilities, the GE 469-P1-HI-A20-E-H controls aeration blowers and sludge pumps, using torque metering to optimize energy efficiency and prevent overloads.
Related Products
- GE 469-P5-HI-A20-E: Similar relay with 5 A CT inputs, ideal for higher current applications.
- GE 869 Motor Management Relay: Next-generation upgrade with expanded I/O and advanced analytics.
- GE 369-HI: High-impedance input module for complementary signal conditioning.
- GE 370-OUT: Analog output module for closed-loop control integration.
- GE 350-CPU: Control processor unit for system-wide automation.
- GE 380-PWR: Power supply module ensuring stable voltage delivery.
- GE 369-RTD: RTD input module for temperature measurement in parallel systems.
Installation and Maintenance
Installation 前准备
Verify the control power supply matches the 90–300 VDC/70–265 VAC range. Clean the mounting panel and ensure proper grounding. Use 1 A CTs for current measurement and connect RTD sensors (if used) following the wiring diagram. Secure the relay using the draw-out case rails and tighten terminal screws to 0.8 N·m.
维护建议
- Daily: Check the enhanced LED display for fault indicators and monitor motor load trends.
- Monthly: Inspect conformal coating for cracks or contamination. Clean dust from vents using compressed air.
- Annually: Calibrate analog outputs and verify CT input accuracy using a multimeter. Update firmware via Enervista™ software to access new features.
Product Guarantee
The GE 469-P1-HI-A20-E-H is backed by a 1-year warranty covering defects in materials or workmanship. GE provides global technical support for installation guidance, troubleshooting, and firmware updates. For mission-critical applications, optional extended warranties and priority repair services are available. With a focus on durability and performance, GE ensures the GE 469-P1-HI-A20-E-H delivers long-term reliability in even the harshest industrial settings.
Brand model: GE 469-P1-HI-A20-E-H
Product Name: Motor Management Relay
Warranty: 1 year
Size: 263 mm × 58 mm × 28 mm
Weight: 4.3 kg
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
Warranty: 1 year
Size: 263 mm × 58 mm × 28 mm
Weight: 4.3 kg
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
