Product Overview
The GE 350-E-P1-G1-H-E-S-C-P-2E-D-N is a high-performance feeder protection relay designed by GE Multilin, belonging to the advanced Multilin 3 Series platform. Engineered for medium to high voltage distribution systems, this relay delivers comprehensive protection, control, and monitoring for feeders, transformers, and capacitor banks in utility and industrial applications. Its modular design supports drawout or fixed mounting, making it suitable for both new installations and retrofitting existing switchgear.
Key functions include arc flash mitigation through zone inter-tripping and light sensor integration713, directional power protection, and thermal overload detection. The relay features programmable logic elements for custom control sequences, such as cold load pickup and autoreclose cycles13. With support for multiple communication protocols (IEC 61850, Modbus TCP/IP, DNP 3.0), it enables seamless integration into smart grid systems for real-time diagnostics and remote management714. The intuitive front-panel interface and configuration software simplify setup, while environmental monitoring tracks temperature and humidity to optimize maintenance schedules13.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 350-E-P1-G1-H-E-S-C-P-2E-D-N |
| Manufacturer | General Electric (GE Multilin) |
| Product Type | Feeder Protection Relay |
| Voltage Input | 120–240 VAC / 125–250 VDC (wide-range power supply)14 |
| Current Input | 1 A (universal CT inputs for phase and ground fault detection)13 |
| Communication Protocols | IEC 61850, Modbus TCP/IP, DNP 3.0, IEC 60870-5-104714 |
| Interfaces | Front USB, rear RS485, dual-port Ethernet (copper/fiber)14 |
| Protection Functions | Phase/ground overcurrent, directional power, thermal overload, arc flash detection13 |
| Environmental Range | Operating: -25°C to +60°C; Storage: -40°C to +85°C13 |
| Dimensions | 216 mm (H) x 140 mm (W) x 203 mm (D) (drawout design for easy maintenance)14 |
| Weight | ~4.1 kg (including chassis)14 |
| Certifications | IEC 61850, IEEE 1588 (PTP), CSA, UL713 |
Main Features and Advantages
Comprehensive Protection:
The GE 350-E-P1-G1-H-E-S-C-P-2E-D-N offers full-spectrum fault detection, including phase overcurrent, ground fault, and negative sequence protection. Its arc flash mitigation system reduces incident energy by 90% through coordinated tripping and light sensor activation13. The relay also monitors breaker health and detects CT/VT failures to prevent false tripping13.
The GE 350-E-P1-G1-H-E-S-C-P-2E-D-N offers full-spectrum fault detection, including phase overcurrent, ground fault, and negative sequence protection. Its arc flash mitigation system reduces incident energy by 90% through coordinated tripping and light sensor activation13. The relay also monitors breaker health and detects CT/VT failures to prevent false tripping13.
Advanced Control and Monitoring:
Equipped with programmable logic elements, the relay supports complex control schemes like cold load pickup and multi-shot recloser operations. It provides real-time metering of voltage, current, and power quality parameters, while the event recorder captures 256 events with 1 ms timestamping for forensic analysis13.
Equipped with programmable logic elements, the relay supports complex control schemes like cold load pickup and multi-shot recloser operations. It provides real-time metering of voltage, current, and power quality parameters, while the event recorder captures 256 events with 1 ms timestamping for forensic analysis13.
Flexible Integration:
With dual-port Ethernet and support for PRP/HSR redundancy protocols, the relay ensures zero failover time in critical networks713. Its universal CT inputs eliminate the need for CT ratio adjustments, simplifying commissioning. The drawout design allows quick replacement without rewiring, minimizing downtime14.
With dual-port Ethernet and support for PRP/HSR redundancy protocols, the relay ensures zero failover time in critical networks713. Its universal CT inputs eliminate the need for CT ratio adjustments, simplifying commissioning. The drawout design allows quick replacement without rewiring, minimizing downtime14.
Rugged Reliability:
Built with automotive-grade components and conformal coating (optional), the relay withstands harsh environments with high humidity, vibration, and EMI713. Its accelerated life cycle testing ensures >20 years of reliable operation in industrial settings.
Built with automotive-grade components and conformal coating (optional), the relay withstands harsh environments with high humidity, vibration, and EMI713. Its accelerated life cycle testing ensures >20 years of reliable operation in industrial settings.
Application Areas
The GE 350-E-P1-G1-H-E-S-C-P-2E-D-N excels in medium to high voltage distribution systems across diverse industries:
- Power Utilities: Primary protection for overhead/cable feeders, distribution transformers, and capacitor banks.
- Industrial Facilities: Protection for motor control centers, process equipment, and backup power systems in oil & gas, mining, and manufacturing plants.
- Renewable Energy: Grid-connected solar/wind farms, ensuring stable integration and fault isolation.
- Critical Infrastructure: Hospitals, data centers, and transportation systems requiring high availability.
Its arc flash mitigation and breaker failure protection make it ideal for environments where safety and continuity are paramount13. The relay’s IEC 61850 compliance also supports smart grid initiatives, enabling predictive maintenance and energy management.
Related Products
- GE 350-E-P1-G1-H-E-M-C-N-3E-D-N: Similar protection functions but with additional control options (e.g., breaker failure dropout level 97–98%)14.
- GE 350-E-P0-G0-H-E-E-N-N-SN-N-N: Basic feeder protection with extended overcurrent features and RS485 connectivity10.
- GE Multilin 369: High-voltage transmission relay for substation automation, complementary for grid-scale protection.
- GE IC693CPU350: Series 90-30 PLC controller for integration with GE’s industrial automation systems2.
- GE 350-E-P5-G5-H-E-S-N-M-1E-D-N: High-voltage variant with advanced metering and Modbus RTU support10.
- GE Multilin 329: Motor protection relay for low-voltage applications, suitable for distributed motor control.
Installation and Maintenance
Installation Preparation:
Before installing the GE 350-E-P1-G1-H-E-S-C-P-2E-D-N, ensure the switchgear compartment meets IP54 environmental standards and has adequate space for the drawout chassis14. Verify CT/VT wiring and power supply compatibility (120–240 VAC/125–250 VDC). Use the GE Multilin Configurator software to program protection settings and communication parameters13.
Before installing the GE 350-E-P1-G1-H-E-S-C-P-2E-D-N, ensure the switchgear compartment meets IP54 environmental standards and has adequate space for the drawout chassis14. Verify CT/VT wiring and power supply compatibility (120–240 VAC/125–250 VDC). Use the GE Multilin Configurator software to program protection settings and communication parameters13.
Maintenance Advice:
- Routine Checks: Inspect LED indicators monthly for fault signals. Clean dust from vents quarterly to maintain thermal performance.
- Firmware Updates: Regularly update firmware to access new features and security patches via GE’s online portal.
- Testing: Perform annual functional tests using a relay test set to validate protection thresholds and trip times.
- Environmental Monitoring: Use the relay’s temperature/humidity sensors to schedule proactive maintenance during optimal downtime13.
Product Warranty
GE provides a 1-year warranty for the GE 350-E-P1-G1-H-E-S-C-P-2E-D-N, covering defects in materials and workmanship. This includes free repair/replacement of faulty components and remote technical support. For extended coverage, GE offers premium service plans with priority diagnostics, onsite training, and lifecycle management.
Brand model: GE 350-E-P1-G1-H-E-S-C-P-2E-D-N
Product Name: Feeder Protection Relay
Warranty: 1 year
Size: 216 mm (H) x 140 mm (W) x 203 mm (D)
Weight: ~4.1 kg
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
Product Name: Feeder Protection Relay
Warranty: 1 year
Size: 216 mm (H) x 140 mm (W) x 203 mm (D)
Weight: ~4.1 kg
Origin: USA
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
This description is based on publicly available technical data for the GE Multilin 350 series, with parameters inferred from related models where exact specifications for 350-E-P1-G1-H-E-S-C-P-2E-D-N are unavailable. For detailed configuration, consult GE’s official datasheet or contact their technical support.
