1. Product Overview
The Emerson EPRO CON021 converter paired with the PR6424/010-120 sensor represents a high-precision solution for Condition Monitoring of critical rotating machinery. This system is designed to measure the relative displacement between a stationary sensor and a rotating shaft without physical contact.
The PR6424 sensor (8mm tip diameter) captures high-frequency electromagnetic field changes caused by shaft movement, while the CON021 driver/converter transforms these changes into a linearized voltage signal. This output is directly proportional to the distance (d) between the sensor tip and the target surface. This setup is a staple in MMS6000 and CSI 6500 protection systems, adhering to API 670 standards for industrial safety and reliability.
Key Applications:
- Shaft Vibration: Real-time monitoring of radial vibration in high-speed turbines.
- Axial Position: Measuring the thrust/axial float of rotors to prevent mechanical contact.
- Speed & Keyphase Detection: Providing pulse signals for RPM calculation and phase analysis.
- Eccentricity: Monitoring shaft bow or thermal warping during turbine startup.
2. Technical Features
| Component | Technical Specification |
| Sensor Model | PR6424/010-120 (8mm Tip) |
| Converter Model | CON021 (Non-contact Signal Driver) |
| Measurement Range | Typically 2.0 mm or 4.0 mm (Depending on calibration) |
| Sensitivity | Standard 8.0 V/mm or 4.0 V/mm |
| Line Output | Linearized Voltage Signal (e.g., -2V to -18V DC) |
| Cable Length | 12.0 meters (Total system length indicated by /120) |
| Operating Temp | -35°C to +150°C (Sensor tip) |
| Hazardous Area | ATEX/IECEx certified for Zone 0/1 (with barriers) |
3. Procurement Process
- Technical Verification: We confirm the sensitivity settings and total cable length (1.0m, 5.0m, or 10.0m extensions) to ensure system calibration.
- Formal Quotation: You will receive a quote including price, lead time (usually in stock), and international courier options.
- Order Confirmation: Verification of target material (e.g., 42CrMo4 steel) for optimal eddy current linearity.
- Sales Agreement: Issuance of Proforma Invoice (PI).
- Secure Payment: Payment via T/T (Bank Wire Transfer).
- Quality Inspection: Physical check of the sensor tip, cable jacket, and converter housing integrity.
- Specialized Packaging: Double-layered anti-static protection to ensure the delicate electromagnetic coils remain calibrated.
- Global Distribution: Expedited shipping via DHL, FedEx, or UPS to power plants and refineries worldwide.
4. Products Showcase (Photos & Video)
5. Related Models
- Emerson PR6423 (10mm Sensor for larger ranges)
- Emerson CON041 (Updated digital-ready converter)
- Emerson MMS6110 (Dual-channel vibration monitor)
- Emerson PR9268 (Absolute vibration sensor/Velomitor)
6. Warranty & After-Sales
- 12-Month Global Warranty: Full replacement guarantee against signal drift or manufacturing defects.
- Calibration Support: Guidance on adjusting the “Gap Voltage” to center the sensor within its linear range during installation.
- Genuine Guarantee: We only supply 100% original Emerson EPRO parts with full traceability.
7. FAQ
Q: What does the “/120” in the sensor model signify?
The suffix 120 typically indicates a total system length of 12.0 meters (including the sensor’s integral cable and any required extension cable) to match the electrical characteristics required by the CON021 converter.
Q: Can I use a CON021 with a PR6423 sensor?
Yes, but the CON021 must be calibrated for the specific sensor type and tip diameter. Using a converter tuned for an 8mm probe (PR6424) with a 10mm probe (PR6423) will result in incorrect sensitivity and non-linear data.
Q: Why is the output voltage negative?
Most eddy current systems use a negative DC supply (e.g., -24V). The output moves toward zero as the gap decreases.
